Generac Power Systems 006852 Owner's Manual page 12

Section 3: Installation
Remove the lower left screw that secures the
5.
divider plate in the transfer switch (B in
Install the new automatic back plate in the transfer
6.
switch and secure to the transfer switch enclosure
(C in Figure 3-4).
Figure 3-3.
C
B
Figure 3-4.
Remove the neutral conductor from the main lug
7.
on the neutral bar.
Terminate the normal power neutral to the main lug
8.
on the neutral bar (D in
8
Figure 3-4).
A
000976
000976
Figure 3-5).
Terminate the neutral conductor from the generator
9.
power feeder onto the neutral terminal bar in the
transfer switch (E in
Terminate the normal power feeder conductors to N1
10.
and N2 on the transfer mechanism (F in
Terminate the panelboard feeder conductors to T1
11.
and T2 on the transfer mechanism (G in
Terminate the generator feeder conductors to E1
12.
and E2 on the transfer mechanism (H in
Terminate generator control wiring to the N1, N2,
13.
T1, 23 and 194 terminals in the transfer switch (J in
Figure 3-5).
Install the new panelboard cover and properly label
14.
all branch circuits.
See Section 4 Checking Automatic Operation
15.
(Automatic HSB Generator Only)
transfer switch and generator operation.
H
F
G
J
Figure 3-5.
Homelink Upgradeable Manual Transfer Switch Owner's Manual
Figure 3-5).
Figure
Figure
Figure
to verify proper
000989
3-5).
3-5).
3-5).
D
E
