Eaton Cooper Power Series Operation Instructions Manual
Visible break connector system, deadbreak apparatus connectors
Hide thumbs
Also See for Cooper Power Series:
- Installation, operation and maintenance manual (189 pages) ,
- Installation, operation and maintenance instructions (128 pages) ,
- Installation and operation instruction manual (52 pages)
Related Manuals for Eaton Cooper Power Series
Summary of Contents for Eaton Cooper Power Series
- Page 1 COOPER POWER Deadbreak Apparatus Connectors SERIES Effective March 2016 MN650022EN Supersedes S600-14-1 June 2010 600 A U-OP visible break connector system operation instructions...
- Page 2 CONTENTS OF THIS DOCUMENT SHALL NOT BECOME PART OF OR MODIFY ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or other- wise for any special, indirect, incidental or consequential damage or loss whatsoever, including but not limited to damage or...
-
Page 3: Table Of Contents
Contents SAFETY INFORMATION Safety information ................iv PRODUCT INFORMATION Introduction . -
Page 4: Safety Information
FOR LIFE FOR LIFE Eaton meets or exceeds all applicable industry standards relating to product safety in its Cooper Power™ series products. We actively promote safe practices in the use and maintenance of our products through our service literature, instructional training programs, and the continuous efforts of all Eaton employees involved in product design, manufacture, marketing, and service. -
Page 5: Product Information
Product information Introduction These instructions are applicable for Eaton's Cooper Power™ series U-OP connector configurations shown in Figure 1. Other configurations are possible with the U-OP connector. For other configurations, other or additional steps may be needed to operate the U-OP connector. -
Page 6: Installation Procedure
U CONNECTOR APPARATUS BUSHING PARKING STAND CURRENT PATH THROUGH U-OP CONNECTOR SYSTEM ( 2 BUSHING 600 A DEADBREAK JUNCTION T-OP II CONNECTOR Figure 3. The U-OP connector system in a typical pad-mounted switchgear application. Installation procedure Equipment required (3) 200 A Grounding Elbows •... -
Page 7: Isolating And Grounding A Cable Requiring Repair
Isolating and grounding a cable requiring repair WARNING De-energize cables High Voltage. Do not proceed until cable is de-energized. A. Open switches at both ends of cable to be isolated. Failure to company may result in death, serious personal Refer to Figure 4. injury and equipment damage. - Page 8 D. Rotate the clampstick counterclockwise until U-OP G. Rotate the clampstick clockwise until the operating operating shaft is completely disengaged from the shaft is completely seated on the mating stud. mating stud. Refer to Figure 7 . H. Verify that the U connector is completely seated by ensuring that the operating shaft is on far enough to cover the indentation in the mating stud.
-
Page 9: Reconnecting The Circuit From The Cable To The Apparatus Bushing
Reconnecting the circuit from the cable to the E. Reorient the “U” as shown in Figure 12, with the long leg over the apparatus bushing, the short leg apparatus bushing over the exposed deadbreak junction interface, and A. Remove U-OP protective cap’s drain wire from the operating shaft over the mating stud. - Page 10 This page intentionally left blank. 600 A U-OP VISIBLE BREAK CONNECTOR SYSTEM OPERATION INSTRUCTIONS MN650022EN March 2016...
- Page 11 This page intentionally left blank. 600 A U-OP VISIBLE BREAK CONNECTOR SYSTEM OPERATION INSTRUCTIONS MN650022EN March 2016...
- Page 12 Eaton.com/cooperpowerseries © 2016 Eaton All Rights Reserved Eaton is a registered trademark. Printed in USA For Eaton's Cooper Power series product Publication No. MN650022EN Rev 00 information call 1-877-277-4636 or visit: All trademarks are property www.eaton.com/cooperpowerseries. (Replaces S600141 Rev. 00)
