K-POE-4BAY PoE Shelf
Hardware Installation Guide
P/N 9034570-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K-Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Enterasys K-Series

  • Page 1 Enterasys K-Series K-POE-4BAY PoE Shelf Hardware Installation Guide P/N 9034570-01...
  • Page 3 Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
  • Page 4 Regulatory Compliance Information Federal Communications Commission (FCC) Notice This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly treated. For information about the available collection system, please go to www.enterasys.com/support/ or contact Enterasys Customer Support at 353 61 705586 (Ireland). Battery Notice This product contains a battery used to maintain product information.
  • Page 6 SJ/T 11363-2006 standard. This table shows where these substances may be found in the supply chain of Enterasys’ electronic information products, as of the date of sale of the enclosed product. Note that some of the component types listed above may or may not be a part of the enclosed product.
  • Page 7 Safety Information Class 1 Laser Transceivers The single mode interface modules use Class 1 laser transceivers. Read the following safety information before installing or operating these modules. The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments.
  • Page 8 EC Directive 2006/95/EC EN 60950-1:2006 A11:2009 A1:2010 EN 60825-1:2007 EN 60825-2:2004 A1:2007 Equipment Type/Environment: Information Technology Equipment, for use in a Commercial or Light Industrial Environment. Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives.
  • Page 9 CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc., on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program/firmware (including any accompanying documentation, hardware or media) (“Program”) in the package...
  • Page 10 Agreement. 12. WAIVER. A waiver by Enterasys of a breach of any of the terms and conditions of this Agreement must be in writing and will not be construed as a waiver of any subsequent breach of such term or condition. Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your breach or prevent enforcement on any other occasion.
  • Page 11 14. TERMINATION. Enterasys may terminate this Agreement immediately upon Your breach of any of the terms and conditions of this Agreement. Upon any such termination, You shall immediately cease all use of the Program and shall return...
  • Page 13: Table Of Contents

    Unpacking a K-Series AC Power Supply ......................3-1 Connecting the K-POE-4BAY PoE Shelf to a K-Series Chassis ..............3-2 Installing a K-Series AC Power Supply in the K-POE-4BAY PoE Shelf ............3-3 Connecting a K-Series AC Power Supply to AC Power ................. 3-5 Appendix A: Specifications and Regulatory Compliance K-POE-4BAY Shelf Specifications ........................A-1...
  • Page 14 Removing the Cover from the PoE Connector on a K-Series Chassis..........3-2 Connecting a K-Series AC Power Supply to a K-Series Chassis ............3-3 Installing a K-Series AC Power Supply in the K-POE-4BAY PoE Shelf ..........3-4 Removing a Cover Plate from the K-POE-4BAY PoE Shelf ............... 3-5 Tables Contents of the K-POE-4BAY PoE Shelf....................
  • Page 15: About This Guide

    About This Guide This guide explains how to install a K-POE-4BAY PoE shelf for use with a K10 or K6 chassis. This guide also provides information on how to contact Enterasys Networks for additional help. Who Should Use This Guide Electrical Hazard: Only qualified personnel should install or service this unit.
  • Page 16: Conventions Used In This Guide

    A description of any action(s) already taken to resolve the problem (for example, changing mode switches or rebooting the unit) • The serial and revision numbers of all involved Enterasys Networks products in the network • A description of your network environment (such as layout, cable type, other relevant...
  • Page 17: Registering Your Product

    Registering your K-POE-4BAY PoE shelf is an important part of the warranty process. Registering tells Enterasys that the warranty or maintenance agreement is active, as well as other important information that ensures Enterasys can provide support in a fast, efficient, and effective manner.
  • Page 18 Registering Your Product xvi About This Guide...
  • Page 19: Chapter 1: Introduction

    K-POE-4BAY PoE shelf. You must purchase the K-Series AC power supplies and K-POE-CBL-2M cables separately. You can connect one K-Series AC power supply to a K6 chassis. You can connect two K-Series AC power supplies to a K10 chassis. Enterasys K-Series K-POE-4BAY PoE Shelf Hardware Installation Guide 1-1...
  • Page 20: Precautions

    K-POE-4BAY PoE shelf. Warning: Install the Enterasys K-POE-4BAY PoE shelf in a Restricted Access Location only. Access to the equipment by users must be restricted through the use of a tool or lock and key or other means of security and is controlled by the authority responsible for the location.
  • Page 21: Chapter 2: Installing The Poe Shelf

    Remove and set aside the anti-static wrist strap. Verify the contents of the carton as listed in the Table 2-1. Table 2-1 Contents of the K-POE-4BAY PoE Shelf Item K-POE-4BAY PoE shelf Anti-static wrist strap Installation Guide Enterasys K-Series K-POE-4BAY PoE Shelf Hardware Installation Guide 2-1...
  • Page 22: Installing The Poe Shelf On Top Of A K-Series Chassis

    “Getting Help” on page xiv for details. Installing the PoE Shelf The default method of installing the PoE shelf is directly on top of a K-Series chassis. See Installing the PoE Shelf on Top of a K-Series Chassis If you purchase the K-POE-4BAY-RAIL rail kit, you can also install the PoE shelf by itself in a four- post or two-post rack.
  • Page 23: Installing The Poe Shelf On Top Of The K-Series Chassis

    Figure 2-2 Installing the PoE Shelf on Top of the K-Series Chassis If you have loosened the back screws on the K-Series chassis, ensure that the tabs at the back of the PoE shelf slide onto the loosened screws. See Figure 2-3.
  • Page 24: Installing The Poe Shelf In A Four-Post Rack

    Secure the front of the PoE shelf to the rack rails with two customer-supplied screws through each mounting ear. You have completed the installation of the PoE shelf. You can now connect the PoE shelf to the K-Series chassis and install power supplies in the PoE shelf. See Chapter Installing a Power Supply.
  • Page 25: Securing The Poe Shelf In A Four-Post Rack

    Securing the PoE Shelf in a Four-post Rack You have completed the installation of the PoE shelf. You can now connect the PoE shelf to the K-Series chassis and install power supplies in the PoE shelf. See Chapter Installing a Power Supply.
  • Page 26: Installing The Poe Shelf In A Two-Post Rack

    Installing the PoE Shelf Installing the PoE Shelf in a Two-post Rack Using the short rails included with the K-POE-4BAY-RAIL rail kit, you can install the PoE shelf in two-post racks with 3-inch rails or 7-inch rails. Note: The K-POE-4BAY-RAIL rail kit, for free standing or mid-mount installation of the K-POE-4BAY PoE shelf, is available for purchase separately.
  • Page 27: Mid-Mounting The Poe Shelf In A Two-Post Rack (3-Inch Rails)

    See Figure 2-7. You have completed the installation of the PoE shelf. You can now connect the PoE shelf to the K-Series chassis and install power supplies in the PoE shelf. See Chapter Installing a Power Supply.
  • Page 28 See Figure 2-9. You have completed the installation of the PoE shelf. You can now connect the PoE shelf to the K-Series chassis and install power supplies in the PoE shelf. See Chapter Installing a Power Supply.
  • Page 29: Front Mounting The Poe Shelf In A Two-Post Rack (7-Inch Rails)

    Attaching the Short Rails to the PoE Shelf for Front Mounting in a Two-post Rack (7-inch Rails) Place the PoE shelf in the rack as shown in Figure 2-11. Figure 2-11 Front Mounting the PoE Shelf in a Two-post Rack (7-inch Rails) Enterasys K-Series K-POE-4BAY PoE Shelf Hardware Installation Guide 2-9...
  • Page 30 See Figure 2-11. You have completed the installation of the PoE shelf. You can now connect the PoE shelf to the K-Series chassis and install power supplies in the PoE shelf. See Chapter Installing a Power Supply.
  • Page 31: Chapter 3: Installing A Power Supply

    Connecting a K-Series AC Power Supply to AC Power Unpacking a K-Series AC Power Supply The K-Series AC power supply is shipped separately from other K-Series hardware. To unpack a power supply: Unpack the power supply by removing it from the shipping box and sliding the two foam end caps off the unit.
  • Page 32: Connecting The K-Poe-4Bay Poe Shelf To A K-Series Chassis

    K-POE-CBL-2M cable for each power supply that you plan to install in the K-POE-4BAY PoE shelf. You can connect up to two K-Series AC power supplies to a K10 chassis for PoE power. You can connect a single K-Series AC power supply to a K6 chassis for PoE power.
  • Page 33: Installing A K-Series Ac Power Supply In The K-Poe-4Bay Poe Shelf

    3-2. Each connector at the rear of the K-POE-4BAY PoE shelf corresponds to slot in the front of the shelf. Connect and secure the other end of the cable to the PoE connector on the K-Series chassis. See Figure 3-2.
  • Page 34: Installing A K-Series Ac Power Supply In The K-Poe-4Bay Poe Shelf

    Installing a K-Series AC Power Supply in the K-POE-4BAY PoE Shelf The front panel should be flush with the face of the K-Series chassis. If significant resistance is encountered before the front panel is flush, remove and reinsert the power supply. Do not force the power supply into place.
  • Page 35: Connecting A K-Series Ac Power Supply To Ac Power

    Note: If multiple power supplies are installed, repeat the following procedure for each supply. For redundancy using multiple K-Series AC power supplies, each of the power cords from the power supplies must be connected to dedicated 15 A AC power circuits.
  • Page 36 Connecting a K-Series AC Power Supply to AC Power 3-6 Installing a Power Supply...
  • Page 37: Appendix A: Specifications And Regulatory Compliance

    Specifications and Regulatory Compliance This appendix provides operating specifications for the K-POE-4BAY PoE shelf and the K-Series AC power supplies. Enterasys Networks reserves the right to change the specifications at any time without notice. For specifications for the K-Series multi-slot chassis, refer to the Enterasys K-Series Chassis Hardware Installation Guide for your chassis.
  • Page 38: Torque Values

    Torque Values K-AC-PS-1400W Table A-3 K-AC-PS-1400W Power Supply Specifications Item Specification Electrical Input Frequency 50 to 60 Hz Input 100 to 120Vac 12A @ 12Vdc 50A/54Vdc14.8A 200 to 240Vac 10A @ 12Vdc 50A/54Vdc14.8A Physical Weight 1.66 kg (3.65 lb) Torque Values Table A-4 describes the recommended torque values to use when using standard threaded fastener machine screws and bolts.
