Zip InLine CEX-O Installation, Maintenance And User Instructions

Electronically controlled instantaneous water heaters
Hide thumbs Also See for InLine CEX-O:
Table of Contents

Advertisement

Quick Links

See also: User Manual and Installation Instructions
The terms 'Zip' and 'InLine'
are registered trademarks
Zip Heaters (UK) Ltd
14 Bertie Ward Way
Dereham
Norfolk
NR19 1TE
Telephone:
0845 6 005 005
Fax:
01362 692448
Web:
www.zipheaters.co.uk
9120-2546 April 2014 V1.02
Installation, Maintenance and User Instructions
Zip InLine
Electronically Controlled Instantaneous
Water Heaters
Models: CEX-O & CEX-U
Issued April 2014
Please read these instructions carefully before commencing installation of the InLine water heater.
Please leave these instructions with the end user after installation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the InLine CEX-O and is the answer not in the manual?

Questions and answers

Related Manuals for Zip InLine CEX-O

Summary of Contents for Zip InLine CEX-O

  • Page 1 Installation, Maintenance and User Instructions Zip InLine Electronically Controlled Instantaneous Water Heaters Models: CEX-O & CEX-U Issued April 2014 The terms ‘Zip’ and ‘InLine’ are registered trademarks Zip Heaters (UK) Ltd 14 Bertie Ward Way Dereham Norfolk NR19 1TE 9120-2546 April 2014 V1.02...

  • Page 3: Table Of Contents

    To ensure you have the latest revision of this instruction manual, please visit www.zipheaters.co.uk to download the latest copy. In order to preserve our environment we ask that you dispose of this product correctly. Please contact Zip Customer Service for advice on 0845 6 005 005.

  • Page 4: Description

    The maximum inlet temperature of 70°C is suitable for use with preheated water e.g. from solar heating systems. Approvals Zip InLine CEX-O and CEX-U are VDE approved to the LVD and EMC directives and are CE endorsed. Zip InLine CEX-O and CEX-U have been examined, tested and found when correctly fitted to comply with the requirements of the United Kingdom Water Regulations / Byelaws (Scotland).

  • Page 5: Safety Information

    • The appliance, its wiring and piping must not be modified in any way. • In case of malfunction isolate the power supply immediately. In case of leaks also isolate the water supply. Repairs must only be carried out by Zip Heaters (UK) Ltd or an authorised Zip service engineer.

  • Page 6: Caution

    • Incoming water temperature must not exceed 70°C. • The Zip InLine is intended for mains supply only. In any other case please contact Zip on 0845 6 005 005 for advice. • Zip Heaters (UK) Ltd cannot be held liable for any damages caused by failure to observe these instructions.

  • Page 7: Technical Data

    Technical data Model CEX-O CEX-U Application Over-sink Under-sink Nominal supply voltage 1/N/PE 230V~ Power Rating (kW) 6.6 / 8.8 Rated Current (A) 29 (6.6kW) / 38 (8.8kW) Element type Bare wire Rated pressure 1 MPa (10 bar) Temperature adjustment range C - 55 Maximum inlet temperature Factory set flow rate at 3 bar (l/min)

  • Page 8: Dimensions

    Dimensions Spare Parts When ordering spare parts, please always specifythe appliance model and serial number. IN82813 ½” Water Connection IN89589 CEX-U IN89588 CEX-O Front Cover IN82802 Inlet Pipe IN82812 CEX-U IN82816 CEX-O Control Panel IN82512 Temperature Sensor Set IN82811 Main PCB IN82246 Non-return Valve...

  • Page 9: Installation

    • The electrical installation including earthing and cross bonding should comply with current IEE regulations and any Local Authority requirements. • Zip InLine water heaters must be installed according to the specification on the rating plate and the technical specifications.

  • Page 10: Installing The Appliance

    Fig. 1 Installing the appliance 1. Thoroughly flush the water supply pipes before installation to remove any water borne debris. 2. Hold the appliance on the wall and mark the drill lines at top and bottom, left and right, corresponding to the small notches at the edge of the front cover (see Fig 1).

  • Page 11: Electrical Connection / Wiring Diagram

    Electrical connection The electrical installation including earthing and cross bonding should comply with current IEE regulations and any Local Authority requirements. The appliance must be installed according to the specification on the rating plate and the technical specifications. The appliance must be earthed. The appliance must be permanently connected to the Wiring Diagram electrical supply through an isolation switch having a...

  • Page 12: Commissioning

    Commissioning Fig. 6 CAUTION To prevent damage to the appliance, the instantaneous water heater must be purged of air before using it for the first time. PURGING Before connecting the electrical supply, open and close the hot water tap until the water runs smoothly and no more air emerges.
  • Page 13 7. Open the hot water tap and check the appliance is functioning correctly. 8. Explain operation of the appliance to the end user and leave the operating instructions for their reference. 9. Complete the product registration card and return it to Zip Heaters or register the product on line at www.zipheaters.co.uk Reinstallation...

  • Page 14: Service Menu

    Service menu Fig. 10 The service menu can be used for diagnostics and to view and configure appliance settings. Press program keys 1 and 2 simultaneously for Press >2 secs at least 2 seconds to enter the service menu confirmed by the display “FL” and flashing point (see Fig 10).
  • Page 15 “Er”: Diagnostics The last ten diagnostic messages can be displayed. Pressing program key 1 displays the current error code. A key explaining the error codes can be found inside the front cover of the appliance. The arrow up and arrow down keys can be used to view the last ten error codes displayed in chronological order from “0”...

  • Page 16: Operation

    Operation Set temperature The appliance switches on automatically when the hot water tap is opened and switches off -1°C +1°C automatically when the hot water tap is closed. Temperature setting 35.0 - 42.0°C The required outlet temperature can be adjusted gradually to a higher or lower value -0.5°C +0.5°C with the up arrow and down arrow keys.
  • Page 17 Temperature limitation Temperature limitation on Units are supplied with the temperature limitation function deactivated. To activate, select the limit temperature then press the program 1 and up arrow function Press >3 keys simultaneously for at least 3 seconds. seconds “HI” is displayed briefly to confirm activation. To deactivate, press the program 1 and down arrow function keys simultaneously for at least 3 seconds.

  • Page 18: Maintenance And Cleaning

    Power limit If the maximum power available from the appliance is insufficient to heat the volume of hot water being drawn off to the required temperature this will be indicated by “MAX” on the display. Reducing the flow rate will enable the required temperature to be delivered.

  • Page 19: Fault Finding

    Repairs should only be carried out by competent persons familiar with electric instantaneous water heaters. All service work should be performed by an authorized Zip service engineer – for details of the full range of services available call Zip Service on 0845 6 005 005.

  • Page 20: Warranty

    Furthermore, this warranty does not displace any statutory warranty, but, to the extent to which Zip is entitled to do so, the liability of Zip under any statutory warranty will be limited at Zip’s option to the replacement of the appliance or supply of equivalent appliance, the payment of the cost of replacing the appliance or acquiring an equivalent appliance, or the payment of the cost of having the appliance repaired or the repair of the appliance.
