- Page 1 1x2 HDMI Splitter/Repeater over Cat.X with HDBaseT-Lite, 4K2K & local Out User Manual rev: 140212 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the SP-5022V should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
● DTS-HD Master Audio and Dolby TrueHD high bit rate audio support ● Pure unaltered uncompressed 7.1ch digital HDMI over Cat.X cable transmission ● Allows cascading ● Wall mounting housing design for easy and robust installation PACKAGE CONTENTS ● 1x SP-5022V ● 1x DC 5V 4A ● 1x User Manual... -
Page 4: Specifications
SPECIFICATIONS Model Name SP-5022V Technical Role of usage 1x2 Distribution Amplifier Transmitter [TX] HDMI compliance HDMI Deep Color, full 3D & 4K2K@30 HDCP compliance Video bandwidth Single-link 340MHz [10.2Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 up to 36-bit color Transmission over 1080p@60 60m (198ft) [CAT.X]... - Page 5 Power LED RS-232 IR blaster IR receiver Dip Switch HDMI Signal IN Stereo audio ou HDMI OUT HDMI Signal OUT +5V DC Link LED...
-
Page 6: Notice
NOTICE 1. If the DVI or HDMI device requires the EDID information, please use EDID Reader/Writer to retrieve and provide DVI or HDMI display EDID information. 2. All HDMI over Cat.X transmission distances are measured using Belden 1583A CAT5e 125MHz UTP cable and ASTRODESIGN Video Signal Generator VG-859C &... -
Page 7: Pin Definition
PIN DEFINITION HDMI Type A (Receptacle) HDMI Pin 1 TMDS Data2+ Pin 8 TMDS Data0 Shield Pin 15 Pin 2 TMDS Data2 Shield Pin 9 TMDS Data0– Pin 16 Pin 3 TMDS Data2– Pin 10 TMDS Clock+ Pin 17 DDC/CEC Ground Pin 4 TMDS Data1+ Pin 11... -
Page 8: Warranty
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the SP-5022V features and specifications is subject to change without further notice.
