- Page 1 User Manual SP-5028E 2x8 HDMI Splitter To avoid EMI issue, complete STP Cat6 cable is strongly recommended! 7.1 CH 7.1 CH AUDIO AUDIO rev: 110225 Made in Taiwan...
-
Page 2: Table Of Contents
However, like all electronic equipments, the SP-5028E should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit. -
Page 3: Introduction
8 different locations without losing quality. With built-in USB firmware update mechanism, the compatibility among countless HDMI sources and receivers can be further guaranteed. With 12 bit deep color video and high definition audio support, SP-5028E is suitable for high quality A/V broadcasting, digital signage and education applications! FEATURES ●... -
Page 4: Specifications
SPECIFICATIONS Model Name SP-5028E Technical HDMI compliance High Speed HDMI - Deep Color & full 3D support DVI compliance DVI 1.0 HDCP compliance Video bandwidth Single-link 225MHz [6.75Gbps] Video support 480i / 480p / 720p / 1080i / 1080p60 up to 36-bit color... -
Page 5: Package Contents
PACKAGE CONTENTS ● 1x SP-5028E ● 1x IR Remote control ● 1x DC 5V 4A in-line with C7 power cord ● 1x Rack-mounting ear set ● 1x User Manual PANEL DESCRIPTIONS Rear Panel 4 5 6 HDMI Input Select: Push button for selecting between HDMI input 1 and input 2... -
Page 6: Installation
INSTALLATION Broadcasts HDMI signal to 8 HDMI displays! 1. Switch off all devices, including monitors. 2. Connect to the receivers. 3. Connect HDMI sources (such as a Blu-ray Disc player) to the HDMI In. 4. Plug in 5V DC power supply. 5. -
Page 7: Notice
NOTICE 1. While connecting a new monitor to the splitter, experiencing a short period of time no display may be expected. Automatic EDID learning will analyze the newly connected monitor to see if the EDID for the HDMI input is necessary to update! 2. -
Page 8: Warranty
SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the SP-5028E features and specifications is subject to change without further notice.
