Ins-30003 PROXIMITY P series compact reader
Technical Support
01273 811011
Technical help is available:
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
Suitability
Security-sensitive doors
Mounted on metal surface
Quickstart guide
This supplement is a brief guide to installing a P series compact system. Further information is available for
download at:
http://www.paxton.co.uk/
Exit button
(push to make)
+12V
Electric release
12V DC release current rating must be less than 1A.
or call the communications team on: 01273 811011.
Exit
0V
0V
support@paxton.co.uk
Monday - Friday from 07:00 - 19:00 (GMT)
Saturday from 09:00 - 13:00 (GMT)
Readers mounted together
+12V
Wet environments
between readers
12V DC power
supply
0V
P75 Screw connector option
The unit should be mounted in conjunction with
an electrical backbox to achieve the required
clearance for the connector.
If an adaptor plate (310-750) is fitted, the
mountings on the backbox can also be used.
Indoor use only
Paxton
300 mm
