- Page 1 Ins-30003 PROXIMITY P series compact reader...
-
Page 2: Technical Support
Monday - Friday from 07:00 - 19:00 (GMT) Saturday from 09:00 - 13:00 (GMT) Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/ Quickstart guide This supplement is a brief guide to installing a P series compact system. Further information is available for download at: http://www.paxton.co.uk/... -
Page 3: Factory Reset
Factory reset 1. Power down the unit. 2. Press and hold the exit button. 3. Power up the unit. It will give several quick beeps. 4. Wait for a further beep and then release and press the exit button twice more within 3 seconds. 5. - Page 4 Enrolment Card - must be presented when the system is first powered on 1. Take the enrolment card from the new pack of user cards. 2. Present the enrolment card to the reader. 3. The reader beeps and the LED's light up as the enrolment card is acknowledged. 4.
-
Page 5: Silent Operation
Fail open release card - Compact systems are fail closed as default FUNCTION CARD fail open release This card is used with systems where a fail open electric release is used for the safe operation in the event of a fire. Present the card to the reader to drive a fail open release or a maglock. - Page 6 Additional covers are available in black, white, grey, blue and silver. Registered installers can order these free of charge by logging onto the secure installer extranet: http://paxton.info/1035 or if you are not a registered installer please call us on: 01273 811011 for more information.
-
Page 7: Technical Help
The output from the entry phone system is used to simulate an exit button on the Paxton equipment. No voltage should be applied to the exit input wires (Blue / Mauve) of a compact unit. Most phone systems will provide a voltage pair to release the door lock; this voltage must be used to drive an independent relay. - Page 8 Fitting Kit Pozi pan self tapping screw - zinc Wall Plugs Pozi pan self tapping screw - small Cable clips © Paxton Access Ltd 2018 The declaration of conformity is available on request. Contact details are provided at: http://paxton.info/596 06/01/2013...
