Designed for Fan and Pump Applications
Thank you for purchasing our FRENIC-Eco series of inverters.
• This product is designed to drive a three-phase induction motor. Read through this instruction manual and
be familiar with the handling procedure for correct use.
• Improper handling might result in incorrect operation, a short life, or even a failure of this product as well as
the motor.
• Deliver this manual to the end user of this product. Keep this manual in a safe place until this product is
discarded.
• For how to use an optional device, refer to the installation and instruction manuals for that optional device.
Fuji Electric Co., Ltd.
Fuji Electric Corp. of America
Instruction Manual
for DY model
INR-SI47-1484a-E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRN005F1S-2DY and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fuji Electric FRN005F1S-2DY

Summary of Contents for Fuji Electric FRN005F1S-2DY

  • Page 1 • Deliver this manual to the end user of this product. Keep this manual in a safe place until this product is discarded. • For how to use an optional device, refer to the installation and instruction manuals for that optional device. Fuji Electric Co., Ltd. Fuji Electric Corp. of America INR-SI47-1484a-E...
  • Page 2 Copyright © 2010-2011 Fuji Electric Co., Ltd. All rights reserved. No part of this publication may be reproduced or copied without prior written permission from Fuji Electric Co., Ltd. All products and company names mentioned in this manual are trademarks or registered trademarks of their respective holders.

  • Page 3: Preface

    Preface Thank you for purchasing our FRENIC-Eco series of inverters. This product is designed to drive a three-phase induction motor for fan and pump applications. Read through this instruction manual and be familiar with proper handling and operation of this product. Improper handling might result in incorrect operation, a short life, or even a failure of this product as well as the motor.
  • Page 4 Application • FRENIC-Eco is designed to drive a three-phase induction motor. Do not use it for single-phase motors or for other purposes. Fire or an accident could occur. • FRENIC-Eco may not be used for a life-support system or other purposes directly related to the human safety.
  • Page 5 Wiring • When wiring the inverter to the power source, insert a recommended molded case circuit breaker (MCCB) residual-current-operated protective device (RCD)/a ground fault circuit interrupter(GFCI)(with overcurrent protection) in the path of power lines. Use the devices within the recommended current range. •...
  • Page 6 Operation • Be sure to install the terminal block cover and the front cover before turning the power ON. Do not remove the covers while power is applied. Otherwise electric shock could occur. • Do not operate switches with wet hands. Doing so could cause electric shock.
  • Page 7 • Do not turn the main circuit power (circuit breaker) ON or OFF in order to start or stop inverter operation. Doing so could cause failure. • Do not touch the heat sink because they become very hot. Doing so could cause burns. •...
  • Page 8 Conformity with Low Voltage Directive in the EU If installed according to the guidelines given below, inverters marked with CE can be considered to be compliant with the Low Voltage Directive 73/23/EEC. 1. Be sure to earth the grounding terminal z G. Use an earth wire sized more than that of the power wires used in the power dispatch system.
  • Page 9 MCCB or Main power Control circuit RCD/GFCI input Rated current [L1/R, L2/S, L3/T] Inverter type Inverter’s grounding [ Europe type terminal block FRN001F1S-2DY FRN002F1S-2DY FRN003F1S-2DY FRN005F1S-2DY FRN007F1S-2DY FRN010F1S-2DY FRN015F1S-2DY 0.25 FRN020F1S-2DY FRN025F1S-2DY 0.75 FRN030F1S-2DY FRN040F1S-2DY FRN050F1S-2DY 25x2 50x2 25x2 25x2...
  • Page 10 Conformity with UL standards and CSA standards (cUL-listed for Canada) UL/cUL-listed inverters are subject to the regulations set forth by the UL standards and CSA standards (cUL-listed for Canada) by installation within precautions listed below. 1. Solid state motor overload protection (motor protection by electronic thermal overload relay) is provided in each model.
  • Page 11 R1, T1 terminal terminal R0, T0 Cat.No R0, T0 block block FRN001F1S-2DY FRN002F1S-2DY 14 (2.1) 15.9 FRN003F1S-2DY (1.8) FRN005F1S-2DY 10 (5.3) FRN007F1S-2DY 8 (8.4) 33.6 (3.8) FRN010F1S-2DY 100 100 6 (13.3) FRN015F1S-2DY 150 125 51.3 FRN020F1S-2DY 175 150 4 (21.2) (5.8)
  • Page 12 Conformity with UL standards and CSA standards (cUL-listed for Canada) (continued) When applying the single-phase to the three-phase drive, the applied motor must fulfill the table below and specifications other than table below are the same as those "Three-phase 208V ratings"...

  • Page 13: Precautions For Use

    Avoid such operation. Synchronous It is necessary to take special measures suitable for this motor type. motors Contact your Fuji Electric representative for details. Single-phase Single-phase motors are not suitable for inverter-driven variable speed motors operation. Use three-phase motors.
  • Page 14 Install a recommended molded case circuit breaker (MCCB) or Installing an residual-current-operated protective device (RCD)/a ground fault circuit MCCB or interrupter (GFCI) (with overcurrent protection) in the primary circuit of the RCD/GFCI inverter to protect the wiring. Ensure that the circuit breaker rated current is equivalent to or lower than the recommended rated current.
  • Page 15 Select an inverter according to the applicable motor ratings listed in the standard specifications table for the inverter. Driving general-purpose When high starting torque is required or quick acceleration or deceleration Selecting motor is required, select an inverter with a capacity one size greater than the inverter standard.

  • Page 16: How This Manual Is Organized

    How this manual is organized This manual is made up of chapters 1 through 10. Chapter 1 BEFORE USING THE INVERTER This chapter describes acceptance inspection and precautions for transportation and storage of the inverter. Chapter 2 MOUNTING AND WIRING OF THE INVERTER This chapter provides operating environment, precautions for installing the inverter, wiring instructions for the motor and inverter.

  • Page 17: Table Of Contents

    Table of Contents Preface ............... i 4.1.1 Inspection and preparation prior to Safety precautions ............. i powering on ........... 4-1 Precautions for use ............xi 4.1.2 Turning ON power and checking....4-1 How this manual is organized ..........xiv 4.1.3 Preparation before running the motor for a test--Setting function code data .....

  • Page 18: Chapter 1 Before Using The Inverter

    1st week of January. The 1st week of January is indicated as '01'. Production year: Last digit of year If you suspect the product is not working properly or if you have any questions about your product, contact your Fuji Electric representative.

  • Page 19: External View And Terminal Blocks

    1.2 External View and Terminal Blocks (1) Outside and inside views (a) FRN015F1S-2DY (b) FRN040F1S-2DY (c) FRN350F1S-4DY Figure 1.2 Outside and Inside Views of Inverters...
  • Page 20 (2) Warning plates and label Warning Plate Warning Plate Warning Label (a) FRN015F1S-2DY (b) FRN040F1S-2DY Figure 1.3 Warning Plates and Label (3) Terminal block location (a) FRN015F1S-2DY (b) FRN040F1S-2DY (c) FRN350F1S-4DY Figure 1.4 Terminal Blocks and Keypad Enclosure Location...

  • Page 21: Transportation

    1.3 Transportation • When carrying an inverter, always support its bottom at the front and rear sides with both hands. Do not hold covers or individual parts only. You may drop the inverter or break it. • When hoisting an inverter with hoisting holes, hook or rope the 4 holes evenly. 1.4 Storage Environment 1.4.1 Temporary storage Store the inverter in an environment that satisfies the requirements listed in Table 1.1.

  • Page 22: Operating Environment

    Chapter 2 MOUNTING AND WIRING OF THE INVERTER 2.1 Operating Environment Install the inverter in an environment that satisfies the requirements listed in Table 2.1. Table 2.1 Environmental Requirements Table 2.2 Output Current Derating Factor in Relation to Altitude Item Specifications Output Site location...
  • Page 23 When mounting two or more inverters Horizontal layout is recommended when two or more inverters are to be installed in the same unit or enclosure. If it is necessary to mount the inverters vertically, install a partition plate or the like between the inverters so that any heat radiating from an inverter will not affect the one/s above.
  • Page 24 To utilize external cooling for inverters with a capacity of 40HP for 208V, 50HP for 460V or above, change the position of the top and bottom mounting bases from the edge to the center of the inverter as illustrated in Figure 2.3.
  • Page 25 Figure A Figure B Figure 2.3 Relocating the Top and Bottom Mounting Bases When moving the top and bottom mounting bases, use only the specified screws. A fire or an accident may be caused.
  • Page 26 (3) Mounting direction Mount the inverter vertically to the mounting surface and fix it securely with four screws or bolts so that the logo "FRENIC-Eco" can be seen from the front. Do not mount the inverter upside down or horizontally. Doing so will reduce the heat dissipation efficiency of the inverter and cause the overheat protection function to operate, so the inverter will not run.

  • Page 27: Wiring

    Fixing the keypad (for models of 30HP for 208V, 40HP for 460V or below) Remove the terminal block (TB) cover and the front cover. (For the procedure, refer to 2.3.1 “Removing and mounting the terminal block (TB) cover and the front cover.”) To fix the front cover and keypad, hold the front cover and the keypad together and tighten the two attached screws (provided as accessories) from the back of the keypad.
  • Page 28 Mounting the covers Put the front cover to the inverter case while fitting the edge of the front cover between the both hinges provided on the inverter case. Slide it upward until the front cover latches. Fit the latches on the terminal block (TB) cover in the holes provided to the front cover and push it towards the inverter case.
  • Page 29 (2) For inverters with a capacity of 40HP for 208V, 50HP for 460V to 125HP for 208V, 200HP for 460V Removing and mounting the covers To remove the front cover, loosen the four fastening screws on it, hold it with both hands, and slide it upward.
  • Page 30 (3) For inverters with a capacity of 250HP to 900HP Removing and mounting the covers To remove the lower front cover, loosen the five fastening screws on it, and hold it with both hands, and then slide it upward. You can do wiring works just removing the lower front cover. To remove the upper front cover, loosen the five screws on it while supporting it with a hand.

  • Page 31: Removing And Mounting The Cable Guide Plate (For Models Of 1 To 25Hp For 208V And 1 To 30Hp For 460V)

    2.3.2 Removing and mounting the cable guide plate (for models of 1 to 25HP for 208V and 1 to 30HP for 460V) For inverters of 25HP for 208V, 30HP for 460V or below use the cable guide plate to secure IP20 protective structure.

  • Page 32: Terminal Arrangement Diagram And Screw Specifications

    Tightening torque Inverter type Refer to: voltage motor(HP) screw size lb-in(N·m) screw size lb-in (N·m) FRN001F1S-2DY FRN002F1S-2DY 15.9(1.8) 15.9(1.8) Figure A FRN003F1S-2DY FRN005F1S-2DY FRN007F1S-2DY 33.6(3.8) 33.6(3.8) Figure B FRN010F1S-2DY FRN015F1S-2DY Three- phase FRN020F1S-2DY 51.3(5.8) 51.3(5.8) Figure C 208 V FRN025F1S-2DY...
  • Page 33 (2) The control circuit terminals (common to all models) Max. lug width 0.29inch (7.4mm) Max. lug width 1.47inch (37.4mm) Screw size: M3 Tightening torque: 4.4 to 5.3lb-in(0.5 to 0.6 (N·m)) Table 2.7 Control Circuit Terminals Screwdriver to be used Bared wire length Dimension of openings in the (Head style) control circuit terminals...
  • Page 34 (2) The control circuit terminals (common to all models) Screw size: M3 Tightening torque: 4.4 to 5.3lb-in(0.5 to 0.6 (N·m)) Table 2.7 Control Circuit Terminals Dimension of openings in the control circuit terminals Bared wire length Screwdriver type Allowable wire size Flat screw driver AWG26 to AWG16 0.10 (W) x 0.11 (H) inch...

  • Page 35: Recommended Wire Sizes

    Europe Power (HP) terminal Supply type Supply R1, T1 terminal R0, T0 block FRN001F1S-2DY FRN002F1S-2DY 14 (2.1) FRN003F1S-2DY FRN005F1S-2DY 10 (5.3) FRN007F1S-2DY 8 (8.4) FRN010F1S-2DY 6 (13.3) FRN015F1S-2DY FRN020F1S-2DY 4 (21.2) (2.1) (0.5) FRN025F1S-2DY 3 (26.7) FRN030F1S-2DY 2 (33.6) FRN040F1S-2DY 3x2 (26.7)

  • Page 36: Wiring Precautions

    2.3.5 Wiring precautions Follow the rules below when performing wiring for the inverter. (1) Make sure that the source voltage is within the rated voltage range specified on the nameplate. (2) Be sure to connect the three-phase power wires to the main circuit power input terminals L1/R, L2/S and L3/T of the inverter.
  • Page 37 Follow the procedure below for wiring and configuration of the inverter. Figure 2.12 illustrates the wiring procedure with peripheral equipment. Wiring procedure Grounding terminals ( G) Inverter output terminals (U, V, W, and DC reactor connection terminals (P1 and P(+)) * Switching connectors * (For the models of 208 V 50HP or above, for 460 V 75HP or above.
  • Page 38 Grounding terminals ( G) Be sure to ground either of the two grounding terminals for safety and noise reduction. The inverter is designed to use with a safety grounding to avoid electric shock, fire and other disasters. Grounding terminals should be grounded as follows: 1) Ground the inverter in compliance with the national or local electric code.
  • Page 39 DC reactor terminals, P1 and P (+) Remove the jumper bar from terminals P1 and P(+). Connect a DC reactor (option) to terminals P1 and P(+). • The wiring length should be 33ft(10 m) or below. • Do not remove the jumper bar if a DC reactor is not going to be used. •...
  • Page 40 Fan power supply switching connectors (CN R) and (CN W) (for models of 208 V 50HP or above, for models of 460 V 75HP or above.) The standard FRENIC-Eco series of inverters also accept DC-linked power input in combination with a power regenerative PWM converter (RHC series).
  • Page 41 Setting up the jumpers for the connectors (CN UX), (CN R) and (CN W) These switching connectors are located on the power printed circuit board (power PCB) mounted at the right hand side of the control printed circuit board (control PCB) as shown below. Switching Connectors for Power Input (CN UX)
  • Page 42 Figure 2.16 shown below illustrates how the configuration jumpers of the connectors (CN UX), (CN R) and (CN W) are setup by factory defaults, and to change their settings for a new power configuration. Setting up the power switching connector (CN UX) (for the models of 460 V 75HP or above) (CN UX) (Red)
  • Page 43 These are provided for the DC link bus powered system. Connect these terminals with terminals P(+) and N (-) of other inverters. Consult your Fuji Electric representative if these terminals are to be used. Main circuit power input terminals, L1/R, L2/S, and L3/T (three-phase input) 1) For safety, make sure that the molded case circuit breaker (MCCB) or magnetic contactor (MC) is turned off before wiring the main circuit power input terminals.
  • Page 44 When connecting a PWM converter with an inverter, do not connect the power supply line directly to terminals R0 and T0. If a PWM is to be connected, insert an insulation transformer or auxiliary B contacts of a magnetic contactor at the power supply side. For connection examples at the PWM converter side, refer to the PWM Converter Instruction Manual.
  • Page 45 2.3.7 Wiring for control circuit terminals In general, sheaths and covers of the control signal cables and wires are not specifically designed to withstand a high electric field (i.e., reinforced insulation is not applied). Therefore, if a control signal cable or wire comes into direct contact with a live conductor of the main circuit, the insulation of the sheath or the cover might break down, which would expose the signal wire to a high voltage of the main circuit.
  • Page 46 Table 2.10 Symbols, Names and Functions of the Control Circuit Terminals Symbol Name Functions [13] Potenti- Power supply (+10 VDC) for the potentiometer that gives the frequency command ometer (Potentiometer: 1 to 5kΩ) power Allowable output current: 10 mA supply [12] Voltage (1) The frequency is commanded according to the external analog input voltage.
  • Page 47 Table 2.10 Continued Symbol Name Functions - Since low level analog signals are handled, these signals are especially susceptible to the external noise effects. Route the wiring as short as possible (within 66ft(20 m)) and use shielded wires. In principle, ground the shielded sheath of wires; if effects of external inductive noises are considerable, connection to terminal [11] may be effective.
  • Page 48 Table 2.10 Continued Symbol Name Functions [X1] Digital (1) The various signals such as coast-to-stop, alarm from external equipment, and input 1 multistep frequency commands can be assigned to terminals [X1] to [X5], [FWD] and [REV] by setting function codes E01 to E05, E98, and E99. For details, refer to [X2] Digital Chapter 5, Section 5.2 "Overview of Function Codes."...
  • Page 49 Table 2.10 Continued Symbol Name Functions Using a relay contact to turn [X1], [X2], [X3], [X4], [X5], [FWD], or [REV] ON or OFF Figure 2.23 shows two examples of a circuit that uses a relay contact to turn control signal input [X1], [X2], [X3], [X4], [X5], [FWD], or [REV] ON or OFF.
  • Page 50 Table 2.10 Continued Symbol Name Functions The monitor signal for analog DC voltage (0 to +10 V) or analog DC current (+4 to +20 [FMA] Analog mA) is output. You can select either one of the output switching the slide switch SW4 on monitor the control PCB (Refer to Section 2.3.8.), and changing data of the function code F29.
  • Page 51 Table 2.10 Continued Symbol Name Functions [Y1] Transistor (1) Various signals such as inverter running, speed/freq. arrival and overload early output 1 warning can be assigned to any terminals, [Y1] to [Y3] by setting function code E20, E21 and E22. Refer to Chapter 5, Section 5.2 "Overview of Function Codes" for details.
  • Page 52 Table 2.10 Continued Symbol Name Functions [Y5A/C] General (1) A general-purpose relay contact output usable as well as the function of the purpose transistor output terminal [Y1], [Y2] or [Y3]. Contact rating: 250 VAC 0.3 A, cos φ = 0.3, 48 VDC, 0.5 A relay output (2) Switching of the normal/negative logic output is applicable to the following two contact output modes: "Active ON"...
  • Page 53 Table 2.10 Continued Symbol Name Functions RS-485 (1) This extends the functions of inverter to the below in addition to the RJ-45 communications [DX+] connector to communicate on FRENIC-Eco . data (+) terminal - The inverter can be controlled as a subordinate device (slave) by connecting it to an upper level device (host (master)) such as a PLC or RS-485 communications...

  • Page 54: Wiring For Control Circuit Terminals

    Wiring for control circuit terminals For models of FRN200F1S-4DY to FRN900F1S-4DY Route the control circuit cable in keeping with the left side panel of the inverter as shown in Figure 2.28. Fasten the control circuit cable to the cable tie support with a cable tie (insulation lock) as shown in Figure 2.28.

  • Page 55: Setting Up Slide Switches And Handling Control Circuit Terminal Symbol Plate

    2.3.8 Setting up slide switches and handling control circuit terminal symbol plate Before changing the switches or touching the control circuit terminal symbol plate, turn OFF the power and wait more than five minutes for models of 30HP for 208V, 40HP for 460V or below, or ten minutes for models of 40HP for 208V, 50HP for 460V or above.

  • Page 56: Mounting And Connecting A Keypad

    Figure 2.29 shows the location of slide switches for the input/output terminal configuration. Switching example SINK SOURCE RS-485 comm. port terminator SW103 RS-485 comm. port terminator Figure 2.29 Location of the Slide Switches 2.4 Mounting and Connecting a Keypad 2.4.1 Mounting style and parts needed for connection (1) Mounting style You can mount a keypad in any style described below.

  • Page 57: Mounting/Installing Steps

    (2) Parts needed for connection To mount/install a keypad on a place other than an inverter, parts listed below are needed. Parts name Model Remarks Less than 66ft(20m). Extension cable (Note 1) 10 BASE-T/100BASE-TX straight type cable compliant to US ANSI TIA/EIA-568A Category 5.
  • Page 58 Remove the keypad mounted on the inverter (see Figure 2.32) and, using a Remote Operation Extension Cable, interconnect the Keypad and the Inverter (insert one end of the cable into the RS-485 port with RJ-45 connector on the Keypad and the other end into that on the inverter) (See Figure 2.34.). Figure 2.34 Connecting a Keypad to the Inverter with Remote Operation Extension Cable...

  • Page 59: Cautions Relating To Harmonic Component, Noise, And Leakage Current

    2.5 Cautions Relating to Harmonic Component, Noise, and Leakage Current (1) Harmonic component Input current to an inverter includes a harmonic component, which may affect other loads and power factor correcting capacitors that are connected to the same power source as the inverter. If the harmonic component causes any problems, connect a DC reactor (option) to the inverter.

  • Page 60: Chapter 3 Operation Using The Keypad

    Chapter 3 OPERATION USING THE KEYPAD 3.1 Key, LED, and LCD Monitors on the Keypad The keypad allows you to start and stop the motor, view various data including maintenance information and alarm information, set function codes, monitor I/O signal status, copy data, and calculate the load factor. 7-segment LED monitor LED indicator...
  • Page 61 Table 3.1 Overview of Keypad Functions Monitor, LED Item Functions indicator or Key Five-digit, 7-segment LED monitor which displays the following according to the operation modes: In Running Mode: Running status information (e.g., output frequency, current, and voltage) In Programming Mode: same as above In Alarm Mode: Alarm code, which identifies the cause of alarm if the...
  • Page 62 Items Displayed on LED Indicators Type Item Description (information, condition, status) Output frequency, frequency command Output current Output voltage Calculated torque, load factor, speed r/min Motor speed, set motor speed, load shaft speed, set load shaft speed Unit of Number m/min Line speed, set line speed (Not applicable to FRENIC-Eco) Displayed on...

  • Page 63: Overview Of Operation Modes

    3.2 Overview of Operation Modes FRENIC-Eco features the following three operation modes: Running Mode: This mode allows you to enter run/stop commands in regular operation. You can also monitor the running status in real time. Programming Mode: This mode allows you to set function code data and check a variety of information relating to the inverter status and maintenance.

  • Page 64: Running Mode

    3.3 Running Mode When the inverter is turned on, it automatically enters Running Mode. In Running Mode, you can: [ 1 ] Run or stop the motor; [ 2 ] Set the frequency command and others; [ 3 ] Monitor the running status (e.g., output frequency, output current) 3.3.1 Running/stopping the motor By factory default, pressing the key starts running the motor in the forward direction and pressing the...
  • Page 65 (2) When function code E45 (LCD Monitor (optional)) is set to "1," the LCD Monitor displays the output frequency, output current, and calculated torque in a bar chart. (The indicators above the LCD Monitor indicate the unit of the number displayed on the LED Monitor; the indicators underneath the LCD Monitor indicate the running status and the source of Run command.) The full scale (maximum value) for each parameter is as follows: Output frequency:...
  • Page 66 r/min m/min Running Running Sub-Status Status ＲＵＮ ＳＬＥＥＰ ＰＶ　＋１３５．００ＭＰａ ＳＶ　＋１３５．００ＭＰａ FWD REV STOP REM LOC COMM HAND Figure 3.6 Display of Running Status Status Description RUN: The Run command is present, or the inverter is driving the motor. Running Status STOP: The Run command is not present, or the inverter is in stopped state.
  • Page 67 Table 3.3 Run Commands from the Keypad in the Local Operation Mode Setting means of the run command If function code F02 is set Keypad You can run/stop the motor using the key on the keypad. External signal Keypad (forward) You can run/stop the motor using the key on the keypad.

  • Page 68: Setting Up The Frequency And Pid Process Commands

    3.3.2 Setting up the frequency and PID process commands You can set up the desired frequency command and PID process command by using keys on the keypad. You can also view and set up the frequency command as load shaft speed by setting function code E48. Setting the frequency command Using keys (factory default)
  • Page 69 • The frequency setting can be saved either automatically as mentioned above or by pressing the key. You can choose either way using function code E64. • When you start specifying or changing the frequency command or any other parameter with the key, the lowest digit on the display will blink and start changing.
  • Page 70 Make setting under PID control To enable PID control, you need to set function code J01 to 1 or 2. Under the PID control, the items that can be set or checked with keys are different from those under regular frequency control, depending upon the current LED monitor setting. If the LED monitor is set to the speed monitor, you may access manual speed commands (frequency command) with keys;...
  • Page 71 • Even if multistep frequency is selected as the PID process command ((SS4) = ON), you still can set the process command using the keypad. • When function code J02 is set to any value other than 0, pressing the key displays, on the 7-segment LED monitor, the PID command currently selected, while you cannot change the setting.

  • Page 72: Led Monitor (Monitoring The Running Status)

    3.3.3 LED monitor (Monitoring the running status) The eleven items listed below can be monitored on the LED Monitor. Immediately after the inverter is turned ON, the monitor item specified by function code E43 is displayed. In Running Mode, press the key to switch between monitor items.

  • Page 73: Monitoring Light Alarms

    3.3.4 Monitoring light alarms The FRN-F1-DY identifies abnormal states in two categories--Heavy alarm and Light alarm. If the former occurs, l-al the inverter immediately trips; if the latter occurs, the inverter shows the on the LED monitor and blinks the "L-ALARM" indication in the operation guide area on the LCD monitor but it continues to run without tripping. Which abnormal states are categorized as a light alarm ("Light alarm"...

  • Page 74: Programming Mode

    3.4 Programming Mode Programming Mode provides you with the functions of setting and checking function code data, monitoring maintenance information and checking input/output (I/O) signal status. The functions can be easily selected with a menu-driven system. Table 3.7 lists menus available in the Programming Mode. Table 3.7 Menus Available in Programming Mode Menu # Menu...

  • Page 75: Setting Function Codes - "1. Data Setting

    3.4.1 Setting function codes – "1. Data Setting" Menu #1 "Data Setting" in Programming Mode allows you to set function codes according to your needs. Table 3.8 lists the function codes available on the FRENIC-Eco. Table 3.8 Function Codes Available on FRENIC-Eco Function Code Group Function Code Function...
  • Page 76 Basic key operation This section will give a description of the basic key operation, following the example of the function code data changing procedure shown in Figure 3.15. This example shows you how to change function code F03 data (maximum frequency) from 58.0 Hz to 58.1 Hz. (1) When the inverter is powered ON, it automatically enters Running Mode.
  • Page 77 Press key to enter Menu. Select desired menu by shifting the pointer with key. Press key to finalize desired menu. Press key to return to Menu. Select desired function code by moving the cursor with key. Press key to finalize desired function code. Press key to change function code data.

  • Page 78: Setting Up Function Codes Quickly Using Quick Setup - "0. Quick Set

    3.4.2 Setting up function codes quickly using Quick setup – "0. QUICK SET" Menu #0 "QUICK SET" in Programming Mode allows you to quickly set up a fundamental set of function codes that you specify beforehand. Whereas at shipment from factory, only a predetermined set of function codes is registered, you can add or delete some function codes using "10.

  • Page 79: Monitoring The Running Status

    3.4.4 Monitoring the running status –"3. OPR MNTR" Menu #3 "OPR MNTR" allows you to check the running status during maintenance and test running. The display items for "Drive Monitoring" are listed in Table 3.9. Table 3.9 Drive Monitoring Display Items Symbol Item Description...

  • Page 80: Opr Mntr

    ０ ．Q U I C K 　 S E T １ ．D A T A 　S E T ２ ．D A T A　 C H E C K ３ ．O P R　 M N T R ∧∨ M E N U　 S H I F ▼ Select desired menu by moving the pointer with key.
  • Page 81 Basic key operation (1) When the inverter is powered ON, it automatically enters Running Mode. In Running Mode, press the key to enter Programming Mode. The menu for function selection will be displayed. (2) Select "3. OPR MNTR" by using keys (moving (3) Press the key to display the screen for Operation Monitor (1 page out of a total of 5 pages).

  • Page 82: Checking I/O Signal Status

    3.4.5 Checking I/O signal status – "4. I/O CHECK" Menu #4 "I/O CHECK" in Programming mode allows you to check the digital and analog input/output signals coming in/out of the inverter. This menu is used to check the running status during maintenance or test run. Table 3.10 lists check items available.

  • Page 83: I/O Check

    ０ ．Q U I C K 　 S E T １ ．D A T A 　S E T ２ ．D A T A　 C H E C K ３ ．O P R　 M N T R ∧∨ M E N U　 S H I F ▼ Select desired menu by moving the pointer with key.
  • Page 84 Hexadecimal expression Each I/O terminal is assigned to one of the 16 binary bits (bit 0 through bit 15). The bit to which no I/O terminal is assigned is considered to have a value of "0." The I/O signals are thus collectively expressed as a hexadecimal number (0 through F).

  • Page 85: Maintenanc

    3.4.6 Reading maintenance information – "5. MAINTENANC" Menu #5 "MAINTENANC" in Programming Mode allows you to view information necessary for performing maintenance on the inverter. Table 3.12 lists the maintenance information display items. Table 3.12 Display Items for Maintenance Symbol Item Description Shows the cumulative run time during which the inverter was powered...
  • Page 86 Basic key operation (1) When the inverter is powered ON, it automatically enters Running Mode. In Running Mode, press the key to enter Programming Mode. The menu for function selection will be displayed. (2) Select "5. MAINTENANC" by using keys (moving (3) Press the key to display the screen for Maintenance (1 page out of a total of 7 pages).
  • Page 87 No. of errors & Error content for RS-485-1 No. of errors & Error content for RS-485-2 No. of errors & Error code for Option communication ROM version of the inverter ROM version of the keypad Common operation: To confirm data, call the desired ROM version of the option page using...

  • Page 88: Reading Alarm Information - "6. Alm Inf

    3.4.7 Reading alarm information – "6. ALM INF" Menu #6 "ALM INF" in Programming Mode allows you to view the information on the four most recent alarm conditions that triggered protective functions (in alarm code and the number of occurrences). It also shows the status of the inverter when the alarm condition occurred.
  • Page 89 Basic key operation (1) When the inverter is powered ON, it automatically enters Running Mode. In Running Mode, press the key to enter Programming Mode. The menu for function selection will be displayed. (2) Select "6. ALM INF" by using keys (moving (3) Press the key to get the Alarm list screen, which displays information on the four most recent alarm...
  • Page 90 Press key to finalize desired alarm info. Output frequency Output current Output voltage Calculated torque Frequency command Running direction/status Cumulative run time No. of startups DC link circuit voltage Temperature inside inverter Max. temperature of heat sink Common operation: Input signal status at terminal block To confirm data, of control circuit call the desired...

  • Page 91: Alm Cause

    3.4.8 Viewing cause of alarm – "7. ALM CAUSE" Menu #7 "ALM CAUSE" in Programming Mode allows you to view the information on the four most recent alarm conditions that triggered protective functions (in alarm code and the number of occurrences). It also shows the cause of each alarm.
  • Page 92 Select desired menu by moving the pointer with key. Press key to finalize desired menu. Cause & No. of occurrences of most recent alarm Cause & No. of occurrences of 2 most recent alarm Cause & No. of occurrences of 3 most recent alarm Cause &...

  • Page 93: Data Copying - "8. Data Copy

    3.4.9 Data copying – "8. DATA COPY" Menu #8 "Data Copying" in Programming Mode allows you to read function code data out of an inverter for which function codes are already set up and then to write such function code data altogether into another inverter, or to verify the function code data held in the keypad with the one in the inverter.
  • Page 94 2) Read Operation List of data copy operations Select desired operation by moving the cursor with key. Press key to finalize desired operation. Data selection screen Select desired data by moving the cursor with key. To go back to List of data copy operations, press key.
  • Page 95 3) Write operation List of data copy operations Select desired operation by moving the cursor with key. Press key to finalize desired operation. Data selection screen Select desired data by moving the cursor with key. To go back to List of data copy operations, press key.
  • Page 96 The function code data held in the keypad is incompatible with that in the inverter. (Either data may be non-standard; or a version upgrade performed in the past may have made the keypad or the inverter incompatible. Contact your Fuji Electric representative.) Figure 3.25 Menu Transition for "WRITE" (continued) If an ERROR screen or an ERROR Ver.
  • Page 97 4) Verify operation List of data copy operations Select desired operation by moving the cursor with key. Press key to finalize desired operation. Data selection screen Select data to be verified by moving the cursor with key. To go back to List of data copy operations, press key.
  • Page 98 The function code data held in the keypad is incompatible with that in the inverter. (Either data may be non-standard; or a version upgrade performed in the past may have made the keypad or the inverter incompatible. Contact your Fuji Electric representative.) Figure 3.26 Menu Transition for "VERIFY" (continued) If an ERROR screen or an ERROR Ver.
  • Page 99 5) Check operation List of data copy operations Select desired operation by moving the cursor with key. Press key to finalize desired operation. Data selection screen Select data to be checked by moving the cursor with key. To go back to List of data copy operations, press key.

  • Page 100: Measuring Load Factor - "9. Load Fctr

    3.4.10 Measuring load factor – "9. LOAD FCTR" Menu #9 "LOAD FCTR" in Programming Mode allows you to measure the maximum output current, the average output current, and the average braking power. There are two modes of measurement: "hours," in which the measurement takes place for a specified length of time, and "start to stop,"...
  • Page 101 2) Selecting "hours set" mode Mode selection screen Select desired mode of measurement by moving the cursor with key. Select desired mode of measurement with key. Press key to finalize desired mode of measurement. Set time duration (Default: 1 hour) To go back to Mode selection, press key.
  • Page 102 3) Selecting "start to stop" mode Mode selection screen Select desired mode of measurement by moving the cursor with key. Confirmation screen If OK, press key. To go back to Mode selection, press key. Press key to signal "Ready." Waiting for Run command (Standby for measurement) Upon receiving Run command, the measurement will start.

  • Page 103: User Set

    3.4.11 Changing function codes covered by Quick setup – "10. USER SET" Menu #10 "USER SET" in Programming Mode allows you to change the set of function codes that are covered by Quick setup. Basic key operation (1) When the inverter is powered ON, it automatically enters Running Mode. In Running Mode, press the key to enter Programming Mode.

  • Page 104: Comm Debug

    3.4.12 Performing communication debugging – "11. COMM DEBUG" Menu #11 "COMM DEBUG" in Programming Mode allows you to view the data of communication-related function codes (S, M, W, X, and Z codes) to help debug programs for communication with an upper-level device. Basic key operation (1) When the inverter is powered ON, it automatically enters Running Mode.

  • Page 105: Alarm Mode

    3.5 Alarm Mode When a protective function is triggered, resulting in an alarm, the inverter automatically enters the alarm mode, displaying the alarm code on the LED Monitor and the details of the alarm on the LCD Monitor as shown below. If there is no overlapping alarm Most recent cause;...
  • Page 106 Display of running status information at the time of alarm By pressing the key while an alarm code is displayed, you can view the output frequency, output current, and other data concerning the running status. The data you can view is the same as with "6. ALM INF." Use keys for scrolling pages within the menu.

  • Page 107: Other Precautions

    3.6 Other Precautions 3.6.1 Function code setting for F02 (Run and operation) key on the keypad controls to run forward/reverse the motor without inputting any rotation command or stop it. The function code F02 specifies the run command source to drive the motor. F02 data Run command source 0: Keypad...

  • Page 108: Tuning Motor Parameters

    3.6.3 Tuning motor parameters The LCD monitor of a keypad shows the lead-through screen for tuning of motor parameters. To tune motor parameters follow screens below. Entering into tuning motor parameters Set data 1 or 2 into the function code P04 and press the key.

  • Page 109: Chapter 4 Running The Motor

    Chapter 4 RUNNING THE MOTOR 4.1 Running the Motor for a Test 4.1.1 Inspection and preparation prior to powering on Check the following prior to starting powering on. (1) Check if connection is correct. Especially check if the power wires are connected to the inverter input terminals L1/R, L2/S and L3/T, and output terminals U, V and W respectively and that the grounding wires are connected to the ground electrodes correctly.
  • Page 110 Table 4.1 Settings of Function Code Data before Driving the Motor for a Test Function code Name Function code data Factory setting f 04 Base frequency 60.0 (Hz) 208 (V) Rated voltage f 05 (at base frequency) 460 (V) Motor parameter Motor ratings (printed on the p 02 Applicable motor rated capacity...
  • Page 111 If any of these conditions has occurred, either eliminate the abnormal or error factor(s) and perform tuning again, or contact your Fuji Electric representative. If an output circuit filter is connected to the inverter’s output (secondary) circuit, the result of tuning can be unpredictable.

  • Page 112: Test Run

    4.1.4 Test run If the user set the function codes wrongly or without completely understanding this Instruction Manual and the FRENIC-Eco User's Manual, the motor may rotate with a torque or at a speed not permitted for the machine. Accident or injury may result. Follow the descriptions of the previous Section 4.1.1, "Inspection and preparation prior to powering on"...
  • Page 113 Chapter 5 FUNCTION CODES This chapter contains overview lists of seven groups of function codes available for the FRENIC-Eco (TYPE: -DY) series of inverters and details of each function code. Contents 5.1 Function Code Tables ........................5-1 5.2 Overview of Function Codes ...................... 5-26 5.2.1 F codes (Fundamental functions) ..................

  • Page 114: Function Code Tables

    5.1 Function Code Tables Function codes enable the FRENIC-Eco (TYPE: -DY) series of inverters to be set up to match your system requirements. Each function code consists of a 3-letter alphanumeric string. The first letter is an alphabet that identifies its group and the following two letters are numerals that identify each individual code in the group.
  • Page 115 Using negative logic for programmable I/O terminals The negative logic signaling system can be used for the digital input and output terminals by setting the function code data specifying the properties for those terminals. Negative logic refers to the inverted ON/OFF (logical value 1 (true)/0 (false)) state of input or output signal. An ON-active signal (the function takes effect if the terminal is short-circuited.) in the normal logic system is functionally equivalent to OFF-active signal (the function takes effect if the terminal is opened.) in the negative logic system.
  • Page 116 The following tables list the function codes available for the FRENIC-Eco (TYPE: -DY) series of inverters F codes: Fundamental Functions Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Data Protection 0: Disable data protection —...
  • Page 117 (F code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Electronic Thermal 1: For general-purpose motors with built-in self-cooling — — 5-37 Overload Protection for Motor (Select motor 2: For inverter-driven motors or high-speed motors with characteristics) forced-ventilation fan (Overload detection level) 0.00: Disable...
  • Page 118 (F code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Analog Output [FMA] Select a function to be monitored from the followings. — — 5-52 (Function) 0: Output frequency 2: Output current 3: Output voltage 4: Output torque 5: Load factor...
  • Page 119 E codes: Extension Terminal Functions Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Command Assignment to: Selecting function code data assigns the corresponding — — 5-55 function to terminals [X1] to [X5] as listed below. 5-97 [X1] 5-146...
  • Page 120 (E code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Status Signal Assignment Selecting function code data assigns the corresponding — — 5-78 function to terminals [Y1] to [Y3], [Y5A/C], and [30A/B/C] 5-160 (Transistor signal) [Y1]...
  • Page 121 (E code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Frequency Detection 0.0 to 120.0 60.0 5-87 (FDT) (Detection level) (Hysteresis width) 0.0 to 120.0 Overload Early Warning 0: (Disable) 0.01 Refer to /Current Detection...
  • Page 122 (E code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Display Coefficient 0.000: (Cancel/reset) 0.001 — 0.010 5-94 Input Watt-hour Data 0.001 to 9999 Reserved. *2 0 to 2 — —...
  • Page 123 (E code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Command Assignment to: Selecting function code data assigns the corresponding — — 5-55 function to terminals [FWD] and [REV] as listed below. 5-97 [FWD] Setting the value of 1000s in parentheses ( ) shown...
  • Page 124 C codes: Control Functions of Frequency Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Jump Frequency 1 0.0 to 120.0 5-98 (Band) 0.0 to 30.0 Multistep Frequency 1 0.00 to 120.00 *1 0.01 0.00 5-99...
  • Page 125 (C code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Bias for PID command 1 -100.0 to 100.00 *1 0.01 0.00 5-101 (Bias value) (Bias reference point) 0.00 to 100.00 *1 0.01 0.00 Selection of Normal/...
  • Page 126 P codes: Motor Parameters Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Motor (No. of poles) 2 to 22 Pole 5-102 (Rated capacity) 0.01 to 1000 (where, the data of function code P99 is 0, 3, 0.01 Refer to or 4.)
  • Page 127 H codes: High Performance Functions Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Data Initialization 0: Disable initialization — — 5-105 1: Initialize all function code data to the factory defaults 2: Initialize motor parameters Auto-resetting 0: Disable...
  • Page 128 (H code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Communications Link Frequency command Run command — — 5-117 Function 5-170 0: F01/C30 (Mode selection) 1: RS485 link 2: F01/C30 RS485 link 3: RS485 link RS485 link...
  • Page 129 (H code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: Alarm Auto-reset 0 to 127 — — 5-122 (Selection) Display data on the keypad's LCD monitor in each bit, "0" for disabled, "1"...
  • Page 130 J codes: Application Functions Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: PID Control 1 0: Disable — — 5-128 (Mode selection) 1: Enable (normal operation) 2: Enable (inverse operation) (Remote process 0: Enable keys on keypad —...
  • Page 131 (J code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: PID Start Frequency 0 to 120 5-156 (Mount) 999: Depends on setting of J36 (Unmount) 0 to 120 999: Depends on setting of J34 Pump Control 0: Disable —...
  • Page 132 (J code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: PID Control Startup Disable 5-160 Frequency 1 to 120 999: Depends on the setting of J36 Motor Mount Switching 0 to 100 5-156 Level 999: Depends on the setting of J41...
  • Page 133 (J code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: PID Control 1 0: Disable — — 5-140 (Slow flowrate level 1: PID process output (MV) selection) 3: Output current 4: PID feedback value (PV) (Stop level for slow -999 to 0.00 to 999 *1...
  • Page 134 (J code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: PID Control 2 0: Disable — — 5-162 (Mode selection) 1: Enable (normal operation) 2: Enable (inverse operation) (Remote process 0: Set value by J72’...
  • Page 135 (J code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: PID Control 2 0: Disable — — 5-162 (Slow flowrate level 1: PID process output (MV) selection) 3: Output current 4: PID feedback value (PV) (Stop level for slow -999 to 0.00 to 999 *1...
  • Page 136 y codes: Link Functions Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: RS485 Communication 1 to 255 — 5-168 (Standard) (Station address) (Communications error 0: Immediately trip and alarm — — processing) 1: Trip and alarm after running for the period...
  • Page 137 (y code continued) Change Refer Incre- Data Default Code Name Data setting range Unit when ment copying setting running page: RS485 Communication 1 to 255 — 5-168 (Extension port) (Station address) (Communications error 0: Immediately trip and alarm — — processing) 1: Trip and alarm after running for the period...
  • Page 138 10.32 0.20 FRN002F1S-2DY 6.16 6.16 2.00 6.16 2.53 5.04 9.09 0.20 FRN003F1S-2DY 8.44 8.44 3.00 8.44 3.23 3.72 24.58 0.20 FRN005F1S-2DY 13.60 13.60 5.00 13.60 4.32 3.99 28.13 0.20 FRN007F1S-2DY 20.19 20.19 7.50 20.19 5.63 3.18 34.70 0.20 FRN010F1S-2DY 27.42 27.42 10.00...

  • Page 139: Overview Of Function Codes

    5.2 Overview of Function Codes This section provides a detailed description of the function codes available for the FRENIC-Eco (TYPE: -DY) series of inverters. In each code group, its function codes are arranged in an ascending order of the identifying numbers for ease of access. Note that function codes closely related each other for the implementation of an inverter's operation are detailed in the description of the function code having the youngest identifying number.
  • Page 140 Certain source settings (e.g., communications link and multistep frequency) have priority over the one specified by F01. • You can modify the reference frequency anywhere you choose using the gain and bias settings, to these analog inputs (voltages entered via terminals [12] and [V2]; the current entered via terminal [C1]).
  • Page 141 In addition to the run command (F02) described, there are several other sources available with priority over F02: Remote/Local switching, Communications link, Run forward command 2 (FWD2), and Run reverse command 2 (REV2). The table below shows relationship between keying and run commands in running per standard keypad (F02 = 0, rotation direction is defined by the digital inputs).
  • Page 142 Maximum Frequency F03 specifies the maximum frequency at which the motor can run. Specifying the frequency out of the range rated for the equipment driven by the inverter may cause damage or a dangerous situation. Set a maximum frequency appropriate for the equipment. - Data setting range: 25.0 to 120.0 (Hz) The inverter can easily accept high-speed operation.
  • Page 143 Non-linear V/f Pattern for Voltage (H51) Sets the voltage component at an arbitrary point of the non-linear V/f pattern. Data for H51 Function 0 to 240 (V) Output the voltage AVR-controlled for 208 V series 0 to 500 (V) Output the voltage AVR-controlled for 460 V series If the rated voltage at base frequency (F05) is set to 0, settings of function codes H50 and H51 will be ignored.
  • Page 144 Example: Normal (linear) V/f pattern V/f Pattern with Non-linear Point below the Base Frequency V/f Pattern with Non-linear Point above the Base Frequency 5-31...
  • Page 145 Acceleration Time 1 Deceleration Time 1 Acceleration Time 2 Deceleration Time 2 Acceleration Time 3 Deceleration Time 3 Acc./Dec. Time Change Frequency F07 specifies the acceleration time, the length of time the frequency increases from 0 Hz to the maximum frequency. F08 specifies the deceleration time, the length of time the frequency decreases from the maximum frequency down to 0 Hz.
  • Page 146 <E14＝0.0Hz> E12 specifies the acceleration time, the length of time the frequency increases from 0 Hz to the Frequency Limiter (Low) (F16). E13 specifies the deceleration time, the length of time the frequency decreases from F16 down to 0 Hz. Output frequency Setting frequency 『FWD』...
  • Page 147 H07 for details. • If you specify an improperly long acceleration/deceleration time, the current limiting function or the automatic deceleration function (regenerative bypass function) may be activated, resulting in an actual acceleration/deceleration time longer than the specified one. Torque Boost Refer to F37.
  • Page 148 FRENIC-Eco inverter, the inverter’s current limit function may be activated or an insufficient torque situation may result, and you would need to reduce the inverter output. For details, contact your Fuji Electric representative. V/f characteristics The FRENIC-Eco series of inverters offers a variety of V/f patterns and torque boosts, which include V/f patterns suitable for non-linear torque load such as general fans and pumps or for special pump load requiring high start torque.
  • Page 149 Torque boost • Manual torque boost (F09) In torque boost using F09, constant voltage is added to the basic V/f pattern, regardless of the load, to give the output voltage. To secure a sufficient start torque, manually adjust the output voltage to optimally match the motor and its load by using F09.
  • Page 150 Auto energy saving operation This feature automatically controls the supply voltage to the motor to minimize the total power consumption of motor and inverter. (Note that this feature may not be effective depending upon the motor or load characteristics. Check the advantage of energy saving before actually apply this feature to your power system.).
  • Page 151 The figure below shows operating characteristics of the electronic thermal overload protection when F10 = 1. The characteristic factors α1 through α3 as well as their corresponding switching frequencies f2 and f3 vary with the characteristics of the motor. The tables below lists the factors of the motor selected by P99 (Motor Selection).
  • Page 152 Overload detection level (F11) F11 specifies the level at which the electronic thermal overload protection becomes activated. - Data setting range: 1 to 135% of the rated current (allowable continuous drive current) of the inverter In general, set F11 to the rated current of motor when driven at the base frequency (i.e. 1.0 to 1.1 multiple of the rated current of motor (P03)).
  • Page 153 Restart Mode after Momentary Power Failure (Mode selection) Refer to H13, H14, H15, H16, H92 and H93. F14 specifies the action to be taken by the inverter such as trip and restart in the event of a momentary power failure. Restart mode after momentary power failure (Mode selection) (F14) Data for F14 Mode...
  • Page 154 Restart mode after momentary power failure (Basic operation) The inverter recognizes a momentary power failure upon detecting the condition that DC link bus voltage goes below the undervoltage level, while the inverter in running. If the load of the motor is light and the duration of the momentary power failure is extremely short, the voltage drop may not be great enough for a momentary power failure to be recognized, and the motor may continue to run uninterrupted.
  • Page 155 When the power is recovered, the inverter will wait 2 seconds for input of a run command. However, if the allowable momentary power failure time (H16) elapses after the power failure was recognized, even within the 2 seconds, the waiting time for a run command is canceled.
  • Page 156 Restart mode after momentary power failure (Allowable momentary power failure time) (H16) Specifies the maximum allowable duration (0.0 to 30.0 seconds) from a momentary power failure (undervoltage) occurrence until the inverter is to be restarted. Specify the maximum length of time that can be tolerated in terms of the machine system and facility during which the motor can coast to stop.
  • Page 157 Auto-restart after momentary power failure (Waiting time) (H13) This function specifies the time period from momentary power failure occurrence until the inverter reacts for restarting process. If the inverter starts the motor while motor’s residual electricity is still in a high level, an overvoltage alarm may be recognized due to a high inrush current or temporary regeneration occurrence.
  • Page 158 Restart after momentary power failure (Frequency fall rate) (H14) During restart after a momentary power failure, if the inverter output frequency and the motor rotation cannot be synchronized with each other, an overcurrent will flow, activating the overcurrent limiter. If it happens, the inverter reduces the output frequency to match the motor rotation according to the reduction rate (Frequency fall rate: Hz/s) specified by H14.
  • Page 159 Even if you select the continuous running control, the inverter may not be able to continue operation when the load's inertia is small or the load is heavy, due to undervoltage caused by a control delay. Even in such a case, however, the output frequency when the undervoltage alarm occurred is saved and the inverter will restart at the saved frequency after a recovery from the momentary power failure.
  • Page 160 Frequency Limiter (High) Frequency Limiter (Low) Refer to H63. F15 and F16 specify the upper and lower limits of the output frequency, respectively. H63 specifies the operation to be carried out when the output frequency drops below the frequency limiter (Low) specified by F16 as follows: •...
  • Page 161 Bias (Frequency command 1) Refer to C50, C32, C34, C37, C39, C42 and C44. When any analog input for frequency command 1 (F01) is used, it is possible to define the relationship between the analog input and the reference frequency by multiplying the gain and adding the bias specified by F18.
  • Page 162 Example: Setting the bias, gain and its reference points when the reference frequency 0 to 100% follows the analog input of 1 to 5 VDC to terminal [12] (in frequency command 1). (Point A) To set the reference frequency to 0 Hz for an analog input being at 1 V, set the bias to 0% (F18 = 0). Since 1 V is the bias reference point and it is equal to 10% of 10 V, set the bias reference point to 10% (C50 = 10).
  • Page 163 Braking time (F22) F22 specifies the braking period that activates DC injection braking. - Data setting range: 0.01 to 30.00 (sec.) (Note that setting 0.00 disables DC injection braking.) Braking response mode (H95) H95 specifies the DC injection braking response mode. Data for H95 Characteristics Note...
  • Page 164 Starting Frequency Stop Frequency At the startup of an inverter, the initial output frequency is equal to the starting frequency. The inverter stops its output at the stop frequency. Set the starting frequency to a level that will enable the motor to generate enough torque for startup. Generally, set the motor's rated slip frequency at the starting frequency F23.
  • Page 165 Specifying a too low carrier frequency will cause the output current waveform to have a large amount of ripples (many harmonics components). As a result, the motor loss increases, causing the motor temperature to rise. Furthermore, the large amount of ripples tends to cause a current limiting alarm.
  • Page 166 Output adjustment (F30) F30 allows you to adjust the output voltage or current representing the monitored data selected by function code F31 within the range of 0 to 200%. - Data setting range: 0 to 200 (%) Function (F31) F31 specifies what is output to the analog output terminal [FMA]. Data for Function Meter scale...
  • Page 167 Analog Output [FMI] (Output adjustment) Analog Output [FMI] (Function) These function codes allow you to output to terminal [FMI] monitored data such as the output frequency and the output current in the form of an analog current. The magnitude of such analog current is adjustable.

  • Page 168: E Codes (Extension Terminal Functions)

    5.2.2 E codes (Extension terminal functions) E01 to E05 Command Assignment to [X1] to [X5] Refer to E98 and E99. Function codes E01 to E05, E98 and E99 allow you to assign commands to terminals [X1] to [X5], [FWD], and [REV] which are general-purpose, programmable input terminals. These function codes may also switch the logic system between normal and negative to define how the inverter logic interprets either ON or OFF status of each terminal.
  • Page 169 1033 Reset PID integral and differential components (PID-RST) 1034 Hold PID integral component (PID-HLD) 1035 Select local (keypad) operation (LOC) 1038 Enable to run (RE) － Protect motor from dew condensation (DWP) Enable integrated sequence to switch to commercial (ISW50) －...
  • Page 170 Terminal function assignment and data setting Select multistep frequency (1 to 15 steps) – (SS1), (SS2),(SS4) and (SS8) (Function code data = 0, 1, and 2) The combination of ON/OFF states of digital input signals (SS1), (SS2),(SS4) and (SS8) selects one of eight different frequency commands defined beforehand by seven function codes C05 to C19 (Multistep frequency 1 to 15).
  • Page 171 Select ACC/DEC time -- (RT1) (Function code data = 4) This terminal command switches between ACC/DEC time 1 (F07 or F08) or ACC/DEC time 2 (E10 or E11). If no (RT1) command is assigned, ACC/DEC time 1 (F07/F08) takes effect by default. Input terminal command(FWD) Acceleration/deceleration time Acceleration/deceleration time 1 (F07/F08)
  • Page 172 Enable external alarm trip -- (THR) (Function code data = 9) Turning this terminal command OFF immediately shuts down the inverter output (so that the motor coasts to stop), displays the alarm 0h2, and outputs the alarm relay (for any fault) (ALM). The (THR) is self-held, and is reset when an alarm reset takes place.
  • Page 173 Operation Scheme • When the motor speed remains almost the same during coast-to-stop: • When the motor speed decreases significantly during coast-to-stop: 5-60...
  • Page 174 • Secure more than 0.1 second after turning ON the "Switch to commercial power" signal before turning ON a run command. • Secure more than 0.2 second of an overlapping period with both the "Switch to commercial power" signal and run command being ON. •...
  • Page 175 Example of Sequence Circuit Note 1) Emergency switch Manual switch provided for the event that the motor drive source cannot be switched normally to the commercial power due to a serious problem of the inverter Note 2) When any alarm has occurred inside the inverter, the motor drive source will automatically be switched to the commercial power.
  • Page 176 Example of Operation Time Scheme Alternatively, you may use the integrated sequence by which some of the actions above are automatically performed by the inverter itself. For details, refer to the description of (ISW50) and (ISW60). 5-63...
  • Page 177 UP and DOWN commands -- (UP) and (DOWN) (Function code data = 17, 18) • Frequency setting When the UP/DOWN control is selected for frequency setting with the run command ON, turning the (UP) or (DOWN) command ON causes the output frequency to increase or decrease, respectively, within the range from 0 Hz to the maximum frequency as listed below.
  • Page 178 Initial settings of UP/DOWN control when the frequency command source is switched: When the frequency command source is switched to UP/DOWN control from other sources, the initial frequency of the UP/DOWN control is as follows: Frequency command Switching command Initial frequency of UP/DOWN control source Frequency command 2/1 Reference frequency given by the...
  • Page 179 Enable write from keypad -- (WE-KP) (Function code data = 19) Turning this terminal command OFF disables changing of function code data from the keypad. Only when this command is ON, you can change function code data from the keypad according to the setting of function code F00 as listed below.
  • Page 180 • When the inverter is driven by an external analog frequency command sources (terminals [12], [C1], and [V2]): The "Switch normal/inverse operation" command (IVS) can apply only to the analog frequency command sources (terminals [12], [C1] and [V2]) in frequency command 1 (F01) and does not affect frequency command 2 (C30) or UP/DOWN control.
  • Page 181 Interlock -- (IL) (Function code data = 22) In a configuration where a magnetic contactor (MC) is installed in the power output (secondary) circuit of the inverter, the momentary power failure detection feature provided inside the inverter may not be able to accurately detect a momentary power failure by itself. Using a digital signal input with the interlock command (IL) assures the accurate detection.
  • Page 182 Select starting characteristics -- (STM) (Function code data = 26) This digital terminal command determines, at the start of operation, whether or not to search for idling motor's speed and follow it. For details of auto search for idling motor's speed, refer to H09 and H17 (Select starting characteristics).
  • Page 183 Usage Example Listed below is a typical example of starting sequence: (1) A run command (FWD) is issued to the inverter. (2) Upon receipt of the run command, the inverter readies itself for running and outputs the status signal "Run command activated" (AX2). (3) Upon receipt of the (AX2) signal, the host equipment starts preparation for the peripheral devices such as opening the mechanical damper/brake.
  • Page 184 Circuit Diagram and Configuration Main Circuit Configuration of Control Circuit Summary of Operation Output Input (Status signal and magnetic contactor) Inverter operation (SW52-1) (SW52-2) (SW88) (ISW50) or (ISW60) Run command 52-1 52-2 (Commercial power) (Inverter) 5-71...
  • Page 185 Timing Scheme Switching from inverter operation to commercial-power operation (ISW50)/(ISW60): ON → OFF (1) The inverter output is shut off immediately (Power gate IGBT OFF) (2) The inverter primary circuit (SW52-1) and the inverter secondary side (SW52-2) are turned off immediately.
  • Page 186 Selection of Commercial Power Switching Sequence Function code J22 specifies whether or not to automatically switch to commercial-power operation when an inverter alarm occurs. Data for J22 Sequence (for occurrence of an alarm) Keep inverter-operation (Stop due to alarm.) Automatically switch to commercial-power operation •...
  • Page 187 Sequence with an emergency switching function 5-74...
  • Page 188 Sequence with an emergency switching function --Part 2 (Automatic switching by the alarm output issued by the inverter) 5-75...
  • Page 189 Clear periodic switching time -- (MCLR) (Function code data = 50) For details, refer to the description of J32. Enable Pump Drive (Motor 1) -- (MEN1) Enable Pump Drive (Motor 2) -- (MEN2) Enable Pump Drive (Motor 3) -- (MEN3) Enable Pump Drive (Motor 4) -- (MEN4) (Function code data = 51, 52, 53 and 54) For details, refer to the description of J26 to J29.
  • Page 190 Switch run command 2/1 -- (FR2/FR1) Run forward 2 and Run reverse 2 -- (FWD2) and (REV2) (Function code data = 87, 88 or 89) These terminal commands switch the run command source. They are useful to switch the source between the digital input and the local keypad when the "Enable communications link"...
  • Page 191 E20 to E22 Status Signal Assignment to [Y1] to [Y3] (Transistor signal) E24, E27 Status Signal Assignment to [Y5A/C] and [30A/B/C] (Relay contact signal) E20 to E22, E24, and E27 assign output signals (listed on the next page) to general-purpose, programmable output terminals [Y1], [Y2], [Y3], [Y5A/C], and [30A/B/C].
  • Page 192 The table below lists functions that can be assigned to terminals [Y1], [Y2], [Y3], [Y5A/C], and [30A/B/C]. To make the explanations simpler, the examples shown below are all written for the normal logic (Active ON.) Function code data Functions assigned Symbol Active ON Active OFF 1000...
  • Page 193 1059 Terminal [C1] wire break (C1OFF) 1060 Mount motor 1, inverter-driven (M1_I) 1061 Mount motor 1, commercial-power-driven (M1_L) 1062 Mount motor 2, inverter-driven (M2_I) 1063 Mount motor 2, commercial-power-driven (M2_L) 1064 Mount motor 3, inverter-driven (M3_I) 1065 Mount motor 3, commercial-power-driven (M3_L) 1067 Mount motor 4, commercial-power-driven...
  • Page 194 Inverter output limiting -- (IOL) (Function code data = 5) This output signal comes ON when the inverter is limiting the output frequency by activating any of the following actions (minimum width of the output signal: 100 ms). • Current limiting by software (F43 and F44: Current limiter (Mode selection) and (Level)) •...
  • Page 195 Cooling fan in operation -- (FAN) (Function code data = 25) Under the cooling fan ON/OFF control enabled (H06 = 1), this output signal is ON when the cooling fan is in operation, and OFF when it is stopped. This signal can be used to make the cooling system of peripheral equipment interlocked for an ON/OFF control.
  • Page 196 Service life alarm -- (LIFE) (Function code data = 30) This output signal comes ON when it is judged that the service life of any one of capacitors (reservoir capacitor in the DC link bus and electrolytic capacitors on the printed circuit board) and cooling fan has expired.
  • Page 197 PID alarm -- (PID-ALM) (Function code data = 42) Assigning this output signal enables PID control specified by function codes J11/J81 through J16/J86 to output absolute-value alarm and deviation alarm. For details of the PID alarm, refer to the descriptions of function codes J11/J81 through J16/J86.
  • Page 198 PID feedback 1 alarm -- (FB1-ALM) (Function code data = 50) Assigning this output signal enables PID control 1 specified by function codes J11 through J16 to output absolute-value alarm and deviation alarm. For details of the PID alarm, refer to the descriptions of function codes J11 through J16. Refer to H82.
  • Page 199 Mount motor 1, inverter-driven -- (M1_I) Mount motor 1, commercial-power-driven -- (M1_L) Mount motor 2, inverter-driven -- (M2_I) Mount motor 2, commercial-power-driven -- (M2_L) Mount motor 3, inverter-driven -- (M3_I) Mount motor 3, commercial-power-driven -- (M3_L) Mount motor 4, commercial-power-driven -- (M4_L) (Function code data = 60 to 67) Specify "Mount pump motor"...
  • Page 200 Frequency Detection (FDT) (Detection level) Frequency Detection (FDT) (Hysteresis width ) When the output frequency has exceeded the frequency detection level specified by E31, the FDT signal comes ON; when it has dropped below the "Frequency detection level minus Hysteresis width specified by E32,"...
  • Page 201 Low Current Detection (Level) Low Current Detection (Timer) Low level current detection This signal is turned ON when the output current drops below the operation level specified by function code E37 and stays in this status for the duration specified by function code E38 (on delay timer).
  • Page 202 Output Frequency Output current H82 bit 1 = 0 (Disable Light Alarm) Low Current Detection E37 『IDL』 signal LED display i d l 『ALM』 signal Output current H82 bit 1 = 1 (Enable Light Alarm) Low Current Detection E37 『IDL』 signal LED display l - a l 『ALM』...
  • Page 203 PID Display Units PID Display Coefficient A PID Display Coefficient B These function codes provide display coefficients to convert the PID process command, PID feedback value, or analog input monitor in easy-to-understand mnemonic physical quantities to display. - Data setting range: 0 to 82 for the PID display units. - Data setting range: -999 to 0.00 to 9990 for the display coefficients A and B.
  • Page 204 Example You wish to maintain the pressure around 16 kPa (sensor voltage 3.13 V) while the pressure sensor can detect 0 - 30 kPa over the output voltage range of 1 - 5 V. Select the terminal [12] as the feedback terminal and set the gain to 200% so that 5V corresponds to 100%.
  • Page 205 LED Monitor (Item selection) Refer to E48. E43 specifies the monitoring item to be displayed on the LED monitor. Data for E43 Function Description (Displays the following.) Speed monitor Selected by the sub item of function code E48 Output current Inverter output current expressed in RMS (A) Output voltage Inverter output voltage expressed in RMS (V)
  • Page 206 LCD Monitor (Item selection) E45 specifies the mode of the LCD display during Running mode using the multi-function keypad. Data for E45 Function Running status, rotational direction and operation guide Bar charts for output frequency, current and calculated torque Running status, running sub-status, PID process command (SV) and PID process output (MV) Running status, running sub-status, PID feedback value (PV) and PID process command (SV)
  • Page 207 Example of display for E45 = 2 (during running) r/min m/min Running Running Sub-Status Status ＳＬＥＥＰ ＲＵＮ ＳＶ　＋１３５．００ＭＰａ ＭＶ　　１２０．００Ｈｚ　 FWD REV STOP REM LOC COMM HAND Example of display for E45 = 3 (during running) r/min m/min Running Running Sub-Status Status ＳＬＥＥＰ...
  • Page 208 LCD Monitor (Language selection) E46 specifies the language to display on the multi-function keypad as follows: Data for E46 Language Japanese English LCD Monitor (Contrast control) Adjusts the contrast of the LCD monitor on the multi-function keypad as follows: Data for E47 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 Contrast High...
  • Page 209 Analog Input for [12] (Extension function selection) Analog Input for [C1] (Extension function selection) Analog Input for [V2] (Extension function selection) E61, E62, and E63 define the function of the terminals [12], [C1], and [V2], respectively. There is no need to set up these terminals if they are to be used for frequency command sources. Data for E61, Input assigned to [12], [C1] Description...
  • Page 210 Saving Digital Reference Frequency E64 specifies how to save the reference frequency specified in digital formats by the keys on the keypad as shown below. Data for E64 Function Auto saving (at the time of main power turned off) The reference frequency will be automatically saved when the main power is turned off.
  • Page 211 Detect Low Torque (Detection level) Detect Low Torque (Timer) The signal (U-TL) turns on when the torque calculated by the inverter with reference to its output current has dropped below the level specified by E80 for the time longer than the one specified by E81.

  • Page 212: C Codes (Control Functions Of Frequency)

    5.2.3 C codes (Control functions of frequency) C01 to C03 Jump Frequency 1, 2 and 3 Jump Frequency (Band) These function codes enable the inverter to jump over three different points on the output frequency in order to skip resonance caused by the motor running frequency and natural frequency of the driven machinery.
  • Page 213 C05 to C19 Multistep Frequency 1 to 15 C56 to C58 Multistep PID command 1 to 3 These function codes specify 15 frequencies required for driving the motor at frequencies 1 to 15. Turning terminal commands (SS1), (SS2), (SS4) and (SS8) ON/OFF selectively switches the reference frequency of the inverter in 15 steps.
  • Page 214 To enable PID control (J01/J70 = 1 or 2) You can set the process command in PID control as the preset value (multistep PID command 3). You can also use multistep frequency (multistep frequency 3) for manual speed command during disabling of PID control ((Hz/PID) = ON).
  • Page 215 Analog Input Adjustment for [12] (Filter time constant) Analog Input Adjustment for [C1] (Filter time constant) Analog Input Adjustment for [V2] (Filter time constant) These function codes provide the filter time constants for the voltage and current of the analog input at terminals [12], [C1], and [V2].

  • Page 216: P Codes (Motor Parameters)

    5.2.4 P codes (Motor parameters) Motor (No. of poles) P01 specifies the number of poles of the motor. Enter the value shown on the nameplate of the motor. This setting is used to display the motor speed on the LED monitor (refer to function code E43).
  • Page 217 Motor (No-load current) Motor (%R1) Motor (%X) These function codes specify no load current, %R1, and %X. Obtain the appropriate values from the test report of the motor or by calling the manufacturer of the motor. If you perform auto tuning, these parameters are automatically set as well.
  • Page 218 Motor Selection P99 specifies the motor to be used. Data for P99 Motor type Fuji standard motors, 8- and 9-series GE motors Fuji standard motors, 6- and 9-series Other motors Automatic control (such as auto-torque boost and auto-energy saving) or electronic thermal motor overload protection uses the motor parameters and characteristics.

  • Page 219: H Codes (High Performance Functions)

    5.2.5 H codes (High performance functions) Data Initialization H03 initializes the current function code settings to the factory defaults or initializes the motor parameters. To change the H03 data, it is necessary to press keys or keys simultaneously. Data for H03 Function Disable initialization (Settings manually made by the user will be retained.)
  • Page 220 When HP motors (P99 = 1) is selected, the motor parameters for P02 through P08 are as listed in following tables. For 208 V series motors shipped for FRN-F1-DY No-load Motor capacity Rated current Applicable current (HP) motor rating (HP) 1.00 to 1.99 3.16 1.39...
  • Page 221 For 460 V series motors shipped for FRN-F1-DY No-load Applicable Motor capacity Rated current current motor (HP) rating (HP) 1.00 to 1.99 1.50 0.77 3.96 8.86 2.00 to 2.99 2.90 1.40 4.29 7.74 3.00 to 4.99 4.00 1.79 3.15 20.81 5.00 to 7.49 6.30 2.39...
  • Page 222 Auto-resetting (Times) Auto-resetting (Reset interval) While the auto-resetting feature is specified, even if the protective function subject to retry is activated and the inverter enters the forced-to-stop state (tripped state), the inverter will automatically attempt to reset the tripped state and restart without issuing an alarm (for any faults). If the protection function works in excess of the times specified by H04, the inverter will issue an alarm (for any faults) and not attempt to auto-reset the tripped state.
  • Page 223 Reset interval (H05) - Data setting range: 0.5 to 20.0 (sec.) H05 specifies the interval time to attempt performing auto-resetting the tripped state. Refer to the timing scheme diagram below. <Operation timing scheme> <Timing scheme for failed retry (No. of retry times: 3)> - The retry operation state can be monitored by external equipment via the inverter’s output terminal [Y1] through [Y3], [Y5A/C], or [30A/B/C].
  • Page 224 Acceleration/Deceleration Pattern H07 specifies the acceleration and deceleration Data for H07 Accl./Decel. pattern patterns (Patterns to control output frequency). Linear (default) S-curve (Weak) S-curve (Strong) Curvilinear Linear acceleration/deceleration The inverter runs the motor with the constant acceleration and deceleration. S-curve acceleration/deceleration To reduce the impact on the inverter-driven motor and/or its mechanical load during acceleration/deceleration, the inverter gradually accelerates/decelerates the motor in both the acceleration/deceleration...
  • Page 225 Curvilinear acceleration/deceleration Acceleration/deceleration is linear below the base frequency (linear torque) but slows down above the base frequency to maintain a certain level of load factor (constant output). This acceleration/deceleration pattern allows the motor to accelerate or decelerate with the maximum performance of the motor.
  • Page 226 Select Starting Characteristics (Auto search for idling motor's speed) Refer to H17. H09 and H17 specify the auto search mode for idling motor's speed and its frequency, respectively, to run the idling motor without stopping it. The auto search mode can be switched by assigning the (STM) terminal command to one of digital input terminals (E01 to E05, function code data = 26).
  • Page 227 Auto search for idling motor's speed (H09) H09 specifies the starting rotational direction (forward/reverse) of the auto search and the starting pattern (patterns 1 to 4). If the motor is idling in the reverse direction that is against the specified direction because of natural convection, it is necessary to start it in the direction opposite to the rotational direction of the original reference frequency.
  • Page 228 Deceleration Mode H11 specifies the mode of deceleration when a run command is turned OFF. Data for H11 Function Normal deceleration The inverter decelerates and stops the motor according to deceleration commands specified by H07 (Acceleration/deceleration pattern) and F08 (Deceleration time 1). Coast-to-stop The inverter immediately shuts down its output.
  • Page 229 Restart after Momentary Power Failure (Restart time) (Refer to F14.) Restart after Momentary Power Failure (Frequency fall rate) (Refer to F14.) Restart after Momentary Power Failure (Continuous running level) (Refer to F14.) Restart after Momentary Power Failure (Allowable momentary power failure time) (Refer to F14.) For how to set these function codes (Restart time, Frequency fall rate, Continuous running level...
  • Page 230 PTC thermistor (Level) (H27) Specifies the detection level for the temperature (expressed in voltage) sensed by PTC thermistor. - Data setting range: 0.00 to 5.00 (V) The temperature at which the overheating protection is to be activated depends on the characteristics of the PTC thermistor.
  • Page 231 Communications Link Function (Mode selection) Refer to y98. H30 and y98 specify the sources of a frequency command and run command--"inverter itself" and "computers or PLCs via the RS485 communications link (standard or extension) or field bus (option)." H30 is for the RS485 communications link; y98 for the field bus. Using the communications link function allows you to monitor the operation information of the inverter and the function code data, set frequency commands, and issue run commands from a remote location.
  • Page 232 Command sources specified by y98 Data for y98 Frequency command Run command Follow H30 data Follow H30 data Via field bus (option) Follow H30 data Follow H30 data Via field bus (option) Via field bus (option) Via field bus (option) Combination of command sources Frequency command source Via RS485...
  • Page 233 Select Starting Characteristics (Auto search time for idling motor's speed) H49 specifies the synchronizing time. - Data setting range: 0.0 to 10.0 (sec.) Non-linear V/f Pattern (Frequency) Refer to F04. Non-linear V/f Pattern (Voltage) Refer to F05. For details of setting the non-linear V/f pattern, refer to the descriptions of function codes F04 and F05.
  • Page 234 Overload Prevention Control H70 specifies the rate of decreasing the output frequency to prevent an overload condition. Under this control, an overload trip is prevented by decreasing the output frequency of the inverter before the inverter trips because of the overheating of the cooling fan or the overloading of the inverter (with an alarm indication of ).
  • Page 235 Light Alarm Selection If the inverter detects a minor abnormal state "light alarm", it can continue the current operation l-al without tripping while displaying the "light alarm" indication on the LED monitor. In addition to l-al the indication , the inverter displays the "L-ALARM" (blinking) on the LCD monitor and outputs the "light alarm"...
  • Page 236 Alarm Auto-resetting (Selection) Alarm Auto-resetting (Times) Alarm Auto-resetting (Reset interval) While the alarm auto-resetting feature is specified, even if the protective function subject to retry is activated and the inverter enters the forced-to-stop state (tripped state), the inverter will automatically attempt to reset the tripped state and restart. If the protection function works in excess of the times specified by H84, the inverter will issue an alarm (for select faults) and not attempt to auto-reset the tripped state.
  • Page 237 Reset interval (H85) - Data setting range: 0.5 to 600.0 (sec.) After the reset interval specified by H85 from when the inverter enters the tripped state, it issues a reset command to auto-reset the tripped state. Refer to the timing scheme diagrams below. When a no alarm state is continued for five minutes, the counter of the automatic reset function is cleared.
  • Page 238 STOP Key Priority / Start Check Function / Run Key Memory The inverter can be operated using a functional combination of "Priority on Key", "Start Check." and "Run Key Memory". Data for H96 STOP key priority Start check function Run key memory Disable Disable Disable...
  • Page 239 Clear Alarm Data H97 deletes the information such as alarm history and data at the time of alarm occurrence, including alarms that have occurred during the check-up or adjustment of the machinery. Data is then brought back to a normal state without an alarm. Deleting the alarm information requires simultaneous keying of keys.
  • Page 240 Judgment on the life of DC link bus capacitors Whether the DC link bus capacitor (reservoir capacitor) has reached its life is determined by measuring the length of time for discharging after power off. The discharging time is determined by the capacitance of the DC link bus capacitor and the load inside the inverter.
  • Page 241 Note that, operating the inverter under the condition that the DC fan is locked for long time may shorten the life of electrolytic capacitors on the printed circuit board due to local high temperature inside the inverter. Be sure to check with the (LIFE) signal etc., and replace the broken fan as soon as possible.
  • Page 242 5.2.6 J codes (Application functions) PID Control 1 (Mode selection) PID Control 1 (Remote process command) PID Control 1 (Gain) PID Control 1 (Integral time) PID Control 1 (Differential time) PID Control 1 (Feedback filter) In PID control 1, the state of control object is detected by a sensor or similar device and is compared with the commanded value (e.g.
  • Page 243 Selection of feedback terminals For feedback control, determine the connection terminal according to the type of the sensor output. • If the sensor is current output type, use the current input terminal [C1] of the inverter. • If the sensor is voltage output type, use the voltage input terminal [12] or [V2] of the inverter. For details, refer to the description of function codes E61 through E63.
  • Page 244 Other than the process command selection by function code J02, the multistep frequency (C08 = 4) specified by the terminal command (SS4) can also be selected as a preset value for the PID process command. Calculate the setting data of the process command using the equation below. Process command data (%) = (Preset multistep frequency) ÷...
  • Page 245 Gain (J03) J03 specifies the gain for the PID processor. - Data setting range: 0.000 to 30.000 (multiple) P (Proportional) action An operation that an MV (manipulated value: output frequency) is proportional to the deviation is called P action, which outputs a manipulated value in proportion to deviation. However, the manipulated variable alone cannot eliminate deviation.
  • Page 246 Differential time (J05) J05 specifies the differential time for the PID processor. - Data setting range: 0.00 to 600.00 (sec.) 0.0 means that the differential component is ineffective. D (Differential) action An operation that the MV (manipulated value: output frequency) is proportional to the differential value of the deviation is called D action that outputs the manipulated value that differentiates the deviation.
  • Page 247 Follow the procedure below to set data to PID control function codes. It is highly recommended that you adjust the PID control value while monitoring the system response waveform with an oscilloscope or equivalent. Repeat the following procedure to determine the optimal solution for each system. - Increase the data of J03 (P (Gain) of PID control) within the range where the feedback signal does not oscillate.
  • Page 248 PID Control 1 (Start stabilize frequency) PID Control 1 (Start stabilize level) PID Control 1 (Start sabilize time) PID Control 1 (Start stabilize acceleration time) The FRN-F1-DY drive can be configured for special functions for dedicated pumping applications. These functions are: Start Stabilize Level (J08) and Start Stabilize Frequency (J07). Some pump systems require the system to be “Start stabilize”...
  • Page 249 (Start stabilize time) Output Frequency (Start stabilize frequency) Feedback value (PV) (Start stabilize level) Run command Cancel start stabilize 『SSC』 Under PID control 『PID-CTL』 signal (Start stabilize time) Output Frequency (Start stabilize frequency) Feedback value (PV) (Start stabilize level) Run command Cancel start stabilize 『SSC』...
  • Page 250 PID Control 1 (Select alarm output) PID Control 1 (Upper limit alarm (AH)) PID Control 1 (Upper alarm delay time) PID Control 1 (Lower limit alarm (AL)) PID Control 1 (Lower alarm delay time) PID Control 1 (Hysteresis level) Two types of alarm signals can be output associated with PID control: absolute-value alarm and deviation alarm.
  • Page 251 PID Control 1 (Upper limit alarm (AH)) (J12) Specifies the upper limit of the alarm (AH) in the PID Display Units (E39) of the process value. PID Control 1 (Lower limit alarm) (AL)) (J14) Specifies the lower limit of the alarm (AL) in the PID Display Units (E39) of the process value. Upper limit alarm (AH) and lower limit alarm (AL) also apply to the following alarms.
  • Page 252 H82 bit 3 = 0 (Disable Light Alarm) Feedback Value (PV) (Upper limit alarm (AH)) J12 (Hysteresis level) (Lower limit alarm (AL)) 『PID-ALM』 signal 『FB1-ALM』 signal LED display f b 1 f b 1 (Lower alarm delay time) (Upper alarm delay time) 『ALM』...
  • Page 253 PID Control 1 (Upper limit of PID process output) PID Control 1 (Lower limit of PID process output) The upper and lower limiter can be specified to the PID output, exclusively used for PID control. The settings are ignored when PID cancel is enabled and the inverter is operated at the reference frequency previously specified.
  • Page 254 PID Control 1 (Slow flowrate level Selection) PID Control 1 (Stop level for slow flowrate) PID Control 1 (Slow flowrate level stop latency) PID Control 1 (Pressurization starting frequency) PID Control 1 (Pressurizing time) PID Control 1 (Starting level Selection for Slow flowrate) PID Control 1 (Starting level for Slow flowrate) PID Control 1 (Starting delay time for Slow flowrate) These function codes specify the data for the slow flowrate stop in pump control, a feature that...
  • Page 255 Output frequency pre-set acceleration time pre-set deceleration time Restart frequency Slow flowrate level stop latency J58 MV increases PID output(MV) again as pressure PV decreases. Starting frequency ： J64 Stop frequency for slow flowrate ： J57 Feedback value(PV) Pressure inside pipe Command(SV) Pressure increases Pressure starts decreasing...
  • Page 256 J63 = 1 (PID process output(MV)) Output Frequency PID Output (MV) J65 (Starting delay time for slow flowrate) (Starting level for slow flowrate) J64 Feedback value (PV) Set Value Run Command J63 = 4 (PID feedback value(PV)) Output Frequency PID Output (MV) Feedback value (PV) J65 (Starting delay time for slow flowrate) Set Value...
  • Page 257 Pressurization before stopping for slow flowrate Specifying J61 (Pressurization starting frequency) and J62 (Pressurizing time) enables pressurization control when the frequency drops below the level specified by J56 (Stop level for slow flowrate) for the period specified by J62 (Pressurizing time). During the pressurization, the PID control is held.
  • Page 258 PID Control 1 (Excessive PID error level) PID Control 1 (Excessive PID error time) When the PID error between the PID 1 process command (SV) and the PID 1 feedback value (PV) has exceeded the excessive PID error level specified by J66 during the period longer than the timer setting specified by J67, the protective function issues a alarm.
  • Page 259 PID Control 1 (Cycling protection for slow flowrate) PID Control 1 (Maximum cycling protection time for slow flowrate) The FRN-F1-DY drive can be configured to allow a maximum number of cycles before initiating a “Run Over Cycle ” alarm. The drive will determine the maximum number of cycles based on the programmed number in the Slow Flowrate Mode: Cycling Protection (J68).
  • Page 260 <Timing scheme for failed retry (No. of retry times: 3)> Operation count on the function of cycling protection is going to be clear when operation command = OFF or passage of time on the function code: J69 from first count-up. Output Frequency Run Command 『PID-CTL』...
  • Page 261 Dew Condensation Prevention (Duty) When the inverter is stopped, dew condensation on the motor can be prevented, by feeding DC power to the motor at regular intervals to keep the temperature of the motor above a certain level. To utilize this feature, you need to assign a terminal command (DWP) (dew condensation prevention) to one of general-purpose digital input terminals (function code data = 39).
  • Page 262 Dynamic rotation of pumps Remarks Item With a fixed inverter-driven With a floating motor inverter-driven motor Maximum number Inverter-driven: 1 Inverter- and commercial Optional relay output card of pumps to drive Commercial power-driven: 4 power-driven: 3 (OPC-F1S-RY) required Applicable motor All pump motors managed by the inverter shall be of the rating same rating.
  • Page 263 Dynamic Rotation of Pump Motors Pump control is effective only when J25 = 1 or 2 and the PID control integrated in the inverter is enabled (J01 ≠ 0, J70 ≠ 0). J25 specifies the configuration of dynamic motor rotation with a fixed inverter-driven motor or with a floating inverter-driven motor.
  • Page 264 With a floating inverter-driven motor In this configuration, all the motors can be driven by the inverter or commercial power. At the start of operation, each motor is driven by the inverter and is controlled for varying speed. When the first motor alone cannot sustain the desired discharge flowrate, it is switched to commercial-power operation, and the inverter drives the second motor.
  • Page 265 Assignment to output terminals In the pump control, contactors (relay outputs) are used to change the configuration of several pump motors or to run/stop them. The following number of contactor control signal lines is required for motor control: Configuration with a fixed inverter-driven motor: Max. 4 output signal lines (4 motors x 1 line/motor) Configuration with a floating inverter-driven motor: Max.
  • Page 266 Indication Diagrams for Dynamic Rotation of Pump Motors (1) With a fixed inverter-driven motor 5-153...
  • Page 267 (2) With a floating inverter-driven motor 5-154...
  • Page 268 Motor 1 Mode Motor 2 Mode Motor 3 Mode Motor 4 Mode J26 to J29 allow you to specify the number of pump motors to be controlled and unmount a pump motor(s) from the control system. The combination of J26 to J29 and "Enable pump drive" commands (MEN1) to (MEN4) assigned to the digital input terminals makes it also possible to enable or disable pump control.
  • Page 269 Motor Stop Mode J31 specifies how to stop the pump motors when a Run command (FWD or REV) is turned OFF under pump control. Data Operation The inverter-driven motor decelerates to the stop frequency (F25) during the deceleration time (F08) to stop. As soon as the output of the inverter is shut down, the relays for the inverter-driven motor are turned OFF.
  • Page 270 Periodic Switching Time for Motor Drive The periodic switching time for motor drive is designed to balance the cumulative run time among multiple motors for extending the life of the pump motors and preventing rust. When the number of motors in operation does not change for the specified period, the inverter dynamically swaps the motors in operation.
  • Page 271 Periodic Switching Signaling Period J33 specifies the output timing of the periodic switching early warning signal (MCHG). Assignment of "Periodic switching early warning signal (MCHG) (E20 to E 22, E24, E27, J45 to J47 = 68) When the periodic switching conditions are met, the inverter outputs a periodic switching early warning for the period specified by J33 and then enters actual switching operation.
  • Page 272 The motor mount switching level (J44) serves as an adjuster for ensuring smooth transition (switch-over) and operates at the timing indicated by the following formula: Switching frequency (Hz) = (J44/100%) x (J18 - J19) + J19, where J18 = PID upper limiter and J19 = PID lower limiter. If J44 is set to 999, Depends on the setting of J41.
  • Page 273 It is recommended that the PID upper and lower limiters (J18, J19) be specified wider than the band specified by the threshold frequencies (J34, J36). In this way, the monitoring of the frequency going above or below the frequencies starts before it reaches the PID upper or lower limiter (J18, J19).
  • Page 274 Feedback value (PV) Command (SV) Run command (PID-CTL) Output J44: Motor Mount Switching Level J24:PID Start Frequency (Unmount) frequency J23:PID Start Frequency (Mount) J41: Motor Unmount Switching Level (M1_L) Commercial Power-driven Mounting Unmounting Motors mounting/unmounting process overview (J25=1: Fixed inverter-driven). Feedback value (PV) Command (SV) Run command...
  • Page 275 Contactor Delay Time J38 specifies the contactor delay time or latency (delay in relay or contactor activation) to be incorporated when the motor power source is switched from the inverter to commercial power when a motor is mounted. Switching Motor Mount/Unmount (Dead band) J42 suppresses the mount/unmount of a pump motor when the difference between the PID process command value and the feedback value is smaller than its setting value band.
  • Page 276 Maximum Cumulative Number of Relay ON Times ([Y1A/B/C] to [Y3A/B/C]) Maximum Cumulative Number of Relay ON Times ([Y1],[Y2],[Y3]) Maximum Cumulative Number of Relay ON Times ([Y5A],[30A/B/C]] During pump control, external relays and relays on the relay output card are frequently turned ON or OFF by transistor outputs Y1 to Y3.
  • Page 277 PID Control 2 (Mode selection) Refer to J01 to J65.) The FRN-F1-DY has the function code for PID control by two sets. The relation of the function code of PID control 1 and PID control 2 is as shown in the table below. 2 PID controls can be utilized after selection by customer.
  • Page 278 Auto PID Switch (Switching delay time) Auto PID Switch (Switch feedback value) In the FRN-F1-DY of inverters, switching PID control modes during operation is possible. Switch PID control 2/1 -- (PID2/1) (Function code data of E01 to E05, E98 and E99 = 70) Turning this digital input signal ON and OFF switches the PID control between PID control 1 (J01) and PID control 2 (J70).
  • Page 279 PID control 1 PID control 2 PID control 1 J01 = 1 (nomal operation) J70 = 2 (inverse operation) Output Frequency Feedback Value 1 Set Value 1 Feedback Value 2 Starting level for slow flowrate (J94) Switching feedback level (J99) PID control switching process overview (J01=1, J70=2).
  • Page 280 5.2.7 PID Frequency Command Generator LED Monitor (Speed Monitor Item) Keypad Operation Output Frequency Motor Speed in r/min Frequency Command 1 Load Shaft Speed in r/min [12] Filter Display Speed in % × [12] [C1] Filter Gain Bias "0" C32 C34 F18 C50 Zero Limiter...
  • Page 281 Enable Select Multistep Cancel PID Communications Frequency (Hz/PID) Link via RS485 Control (SS1, 2) or Filed Bus (Option) (LE) Under PID Control Inverter (PID-CTL) (RUN) Frequency Running Limiter (High) Manual Speed Command Communications Link Function Bus Link Drive Jump Function Frequency Frequency Loader Link...
  • Page 282 5.2.8 y codes (Link functions) Up to two ports of RS485 communications link are available, including the terminal block extension as shown below. Port Route Function code Applicable equipment Port 1 Standard RS485 y01 through y10 Multi-function keypad Communications (for PC running FRENIC connection with keypad) via Loader...
  • Page 283 y01 to y20 RS485 Communication (Standard and extension) Station Address (y01 for standard port and y11 for extension port) These function codes specify the station address for the RS485 communications link. The table below lists the protocols and the station address setting ranges. Protocol Station address Broadcast address...
  • Page 284 Transmission speed (y04 and y14) Select the transmission speed for RS485 Data for y04 Transmission speed (bps) communications. and y14 - Setting for FRENIC Loader: Set the same 2400 transmission speed as that specified by 4800 the connected PC. 9600 19200 38400 Data length (y05 and y15)
  • Page 285 Response latency time (y09 and y19) Sets the latency time after the end of receiving a query sent from the host equipment (such as a PC or PLC) to the start of sending the response. This function allows using equipment whose response time is slow while a network requires quick response, enabling the equipment to send a response timely by the latency time setting.
  • Page 286 Loader Link Function (Mode selection) This is a link switching function for FRENIC Loader. Rewriting the data of this function code y99 (= 3) to enable RS485 communications from Loader helps Loader send the inverter the frequency and run commands. Since the data in the function code of the inverter is automatically set by Loader, no keypad operation is required.

  • Page 287: Chapter 6 Troubleshooting

    "light alarm" indication ( l-al ) is displayed For problems that could be caused by running the inverter on single-phase power Go to Section 6.6. If any problems persist after the above recovery procedure, contact your Fuji Electric representative.

  • Page 288: Motor Is Running Abnormally

    l-al 6.2 If Neither an Alarm Code Nor "Light Alarm" Indication ( ) Appears on the LED Monitor 6.2.1 Motor is running abnormally [ 1 ] The motor does not rotate. Possible Causes What to Check and Suggested Measures (1) No power supplied to the Check the input voltage, output voltage and interphase voltage unbalance.
  • Page 289 Possible Causes What to Check and Suggested Measures (9) The coast-to-stop Check the data of function codes E01, E02, E03, E04, E05, E98 and E99 and the input signal status with Menu #4 "I/O Checking" using the keypad. command was effective. Release the coast-to-stop command setting.
  • Page 290 Possible Causes What to Check and Suggested Measures (6) Overload Measure the output current. Lighten the load. (Adjust the damper of the fan or the value of the pump). (In winter, the load tend to increase.) Check if mechanical brake is working. Release the mechanical brake.
  • Page 291 Possible Causes What to Check and Suggested Measures (2) The external frequency Check that there is no noise in the control signal wires from external sources. command source device Isolate the control signal wires from the main circuit wires as far as was used.
  • Page 292 [ 6 ] The motor does not accelerate and decelerate at the set time. Possible Causes What to Check and Suggested Measures (1) The inverter ran the motor Check the data of function code H07 (Acceleration/deceleration pattern). by S-curve or curvilinear Select the linear pattern (H07 = 0).

  • Page 293: Problems With Inverter Settings

    6.2.2 Problems with inverter settings [ 1 ] Nothing appears on the LED monitor. Possible Causes What to Check and Suggested Measures (1) No power supplied to the Check the input voltage, output voltage and interphase voltage unbalance. inverter (main circuit Connect a molded case circuit breaker, a ground fault circuit interrupter power, auxiliary power for (with overcurrent protection) or a magnetic contactor.

  • Page 294: If An Alarm Code Appears On The Led Monitor

    6.3 If an Alarm Code Appears on the LED Monitor Quick reference table of alarm codes Alarm Alarm Name Refer to Name Refer to code code □ Fuse blown 6-13 Instantaneous overcurrent Charger circuit fault 6-13 □= Ground fault Electronic thermal overload relay 6-14 □...
  • Page 295 Possible Causes What to Check and Suggested Measures (4) The value set for torque Check that the output current decreases and the motor does not come to boost (F09) was too large. stall if you set a lower value than the current one for F09. (F37 = 0, 1, 3, or 4) Lower the value for torque boost (F09) if the motor is not going to stall.
  • Page 296 Possible Causes What to Check and Suggested Measures (5) Braking load was too Compare the braking torque of the load with that of the inverter. heavy. Set the rated voltage (at base frequency) (F05) to 0 to improve braking ability. (6) Malfunction caused by Check if the DC link bus voltage was below the protective level when the noise.
  • Page 297 Possible Causes What to Check and Suggested Measures (3) Interphase unbalance rate Measure the input voltage. of three-phase voltage Connect an AC reactor (ACR) to lower the voltage unbalance between was too large. input phases. Raise the inverter capacity. (4) Overload cyclically Measure ripple wave of DC link bus voltage.
  • Page 298 The 208V inverters with a capacity of 50HP or above and the 460V inverters with a capacity of 75HP or above each have a cooling fan/fans for heat sinks and a DC fan for internal air circulation (dispersing the heat generated inside the inverter). For their locations, refer to Chapter 1, Section 1.2 “External View and Terminal Blocks.”...
  • Page 299 Possible Causes What to Check and Suggested Measures (4) The set activation level Check the thermistor specifications and recalculate the detection voltage. (H27) of the PTC Reconsider the data of function code H27. thermistor for motor overheat protection was inadequate. (5) A PTC thermistor and Check the connection and the resistance of the pull-up resistor.
  • Page 300 [ 13 ] Electronic thermal overload relay Problem Electronic thermal function for motor overload detection was activated. Possible Causes What to Check and Suggested Measures (1) The characteristics of Check the motor characteristics. electronic thermal did not Reconsider the data of function codes P99, F10 and F12. match those of the motor Use an external thermal relay.
  • Page 301 This problem was caused by a problem of the printed circuit board (PCB) (on which the CPU is mounted). Contact your Fuji Electric representative. [ 16 ] Keypad communications error Problem A communications error occurred between the remote keypad and the inverter.
  • Page 302 [ 18 ] Option card communications error Problem A communications error occurred between the option card and the inverter. Possible Causes What to Check and Suggested Measures (1) There was a problem with Check whether the connector on the bus option card is properly mating with the connector of the inverter.
  • Page 303 [ 21 ] Tuning error Problem Auto-tuning failed. Possible Causes What to Check and Suggested Measures (1) A phase was missing Properly connect the motor to the inverter. (There was a phase loss) in the connection between the inverter and the motor. (2) V/f or the rated current of Check whether the data of function codes F04, F05, H50, H51, P02, and P03 the motor was not properly...
  • Page 304 Check if occurs each time power is switched on. This problem was caused by a problem of the printed circuit board (PCB) (on which the CPU is mounted). Contact your Fuji Electric representative. [ 24 ] RS-485 communications error Problem A communications error occurred during RS-485 communications.
  • Page 305 (1) The capacity is not set The inverter capacity needs to be modified again. properly on the control Contact your Fuji Electric representative. printed circuit board. (2) The contents of the The power supply printed circuit board needs to be replaced.
  • Page 306 l-al If the "Light Alarm" Indication ( ) Appears on the LED Monitor If the inverter detects a minor abnormal state "light alarm," it can continue the current operation without tripping l-al l-al while displaying the "light alarm" indication on the LED monitor. In addition to the indication , the inverter displays the "L-ALARM"...

  • Page 307: If An Abnormal Pattern Appears On The Led Monitor Except Alarm Codes And "Light Alarm

    6.5 If an Abnormal Pattern Appears on the LED Monitor except Alarm Codes and "Light l-al Alarm" Indication ( [ 1 ] – – – – – (center bar) appears Problem A center bar (– – – – –) has appeared on the LED monitor. Possible Causes What to Check and Suggested Measures (1) When PID control had...

  • Page 308: Chapter 7 Maintenance And Inspection

    Chapter 7 MAINTENANCE AND INSPECTION Perform daily and periodic inspection to avoid trouble and keep reliable operation for a long time. Take care of the following items during work. • Before proceeding to the maintenance/inspection jobs, turn OFF the power and wait more than five minutes for models of 30HP for 208V, 40HP for 460V or below, or ten minutes for models of 40HP for 208V, 50HP for 460V or above.
  • Page 309 Table 7.1 Continued Check part Check item How to inspect Evaluation criteria 1) Abnormal noise and excessive 1) Visual or hearing 1), 2), 3), 4), 5) Structure such vibration inspection as frame and No abnormalities cover 2) Loosen bolts (tightened parts) 2) Retighten.

  • Page 310: List Of Periodical Replacement Parts

    Each part of the product has its own service life that will vary according to the environmental and operating conditions. It is recommended that the following parts be replaced as specified below. When the replacement is necessary, contact your Fuji Electric representative. Table 7.2 Replacement Parts...
  • Page 311 -2 Measuring the capacitance of the DC link bus capacitor (during power-off time under ordinary operating condition) In general, the discharging condition of the DC link bus capacitor during a power-off time under the ordinary operating condition at the end user’s installation is different from that under which the initial measurement is conducted at the time of factory shipment.

  • Page 312: Measurement Of Electrical Amounts In Main Circuit

    (2) Early warning of lifetime alarm For the components listed in Table 7.3, you can get an early warning of lifetime alarm at one of the transistor output terminals ([Y1] to [Y3]) and the relay contact terminals ([Y5A] - [Y5C], and [30A/B/C]) as soon as any of the conditions listed under the "Judgment level"...

  • Page 313: Insulation Test

    A dielectric strength test will cause breakage of the inverter similarly to the Megger test if the test procedure is wrong. When the dielectric strength test is necessary, contact your Fuji Electric representative. Megger test of main circuit Use a 500 VDC Megger and shut off the main power supply without fail during measurement.

  • Page 314: Inquiries About Product And Guarantee

    7.6 Inquiries about Product and Guarantee When making an inquiry Upon breakage of the product, uncertainties, failure or inquiries, report the following information to your Fuji Electric representative. Inverter type (Refer to Chapter 1, Section 1.1.) SER No. (serial number of equipment) (Refer to Chapter 1, Section 1.1.) Function codes and their data that you changed (Refer to Chapter 3, Section 3.4.3.) ROM version (Refer to Chapter 3, Section 3.4.6.) Date of purchase...

  • Page 315: Chapter 8 Specifications

    Chapter 8 SPECIFICATIONS 8.1 Standard Models 8.1.1 Three-phase 208V Item Specifications Type (FRN F1S-2DY) Nominal applied motor for three phase input * [HP] Rated capacity * [kVA] Three-phase, 200V to 230V Rated voltage * Three-phase, 200V to 240V (With AVR function) (With AVR function) Rated current * 10.6...
  • Page 316 8.1.2 Three-phase 460 V 1 to 75HP Item Specifications Type (FRN F1S-4DY) Nominal applied motor for three phase input * [HP] Rated capacity * [kVA] Rated voltage * Three-phase, 380V to 480V (With AVR function) Rated current * 12.5 16.5 Overload capability 120% of rated current for 1min Rated frequency...
  • Page 317 100 to 900HP Item Specifications Type (FRN F1S-4DY) Nominal applied motor for three phase input * [HP] Rated capacity * [kVA] Rated voltage * Three-phase, 380V to 480V (With AVR function) Rated current * 1040 Overload capability 120% of rated current for 1min Rated frequency 50, 60Hz Main power supply...

  • Page 318: Specifications Of Keypad Related

    8.2 Specifications of Keypad Related 8.2.1 General specifications of keypad Table 8.1 General Specifications Items Specification Remarks Protective structure Front side: IP40, Back (mounting) side: IP20 Site to be installed In door Ambient -10 to 50°C (14 to 122°F) temperature Ambient humidity 5 to 95% RH, no condensation allowed No corrosive gas, no inflammable gas, no dust, and no direct...

  • Page 319: Data Transmission Specifications

    8.2.3 Data transmission specifications Table 8.4 Data Transmission Specification Items Specification Remarks Station address No need to specify. To use any keypad, no setup is needed for RS-485 Communications protocol Modbus-RTU communications related function codes y01 to y10 Synchronization system Asynchronous start-stop system because their data is ignored.

  • Page 320: Common Specifications

    8.3 Common Specifications...

  • Page 322: Terminal Specifications

    (RJ-45)) (Terminal)) 8.4 Terminal Specifications 8.4.1 Terminal functions For details about the main and control circuit terminals, refer to Chapter 2, Section 2.3.6 and Section 2.3.7 (Table 2.10), respectively.

  • Page 323: Running The Inverter With Keypad

    8.4.2 Running the inverter with keypad Power supply Refer to “8.1 Standard Models” for details. (Note 1) When connecting a DC reactor (DCR), first remove the short bar between terminals [P1] and [P+]. A DCR is optional for inverters below 75HP for 208V, 100HP for 460V but standard for inverters of 75HP for 208V, 100HP for 460V or above.

  • Page 324: Running The Inverter By Terminal Commands

    8.4.3 Running the inverter by terminal commands Power supply Refer to “8.1 Standard Models” for details. (Note 1) When connecting a DC reactor (DCR), first remove the short bar between terminals [P1] and [P+]. A DCR is optional for inverters below 75HP for 208V, 100HP for 460V but standard for inverters of 75HP for 208V, 100HP for 460V or above.
  • Page 325 (Note 5) Normally no need to be connected. Use these terminals when the inverter is equipped with a high power factor PWM converter with a regenerative facility. (Note 6) You can select the frequency command source either electronically by supplying a DC voltage signal (within the range of 0 to 10 V, 0 to 5 V, or 1 to 5 V) between terminals [12] and [11], or manually by connecting a frequency command potentiometer to terminals [13], [12], and [11].

  • Page 326: External Dimensions

    8.5 External Dimensions 8.5.1 Standard models Unit: inch (mm) Power supply Type voltage Three-phase 208V FRN001F1S-2DY FRN002F1S-2DY FRN003F1S-2DY FRN005F1S-2DY Three-phase 460V FRN001F1S-4DY FRN002F1S-4DY FRN003F1S-4DY FRN005F1S-4DY FRN007F1S-4DY 8-12...
  • Page 327 Unit: inch (mm) Power Dimensions [inch（mm）] supply Type φA φB voltage FRN007F1S-2DY 5.58 0.63 1.10 1.38 FRN010F1S-2DY 8.66 7.72 2.50 1.83 1.83 10.2 9.37 (141.7) (16) 4.67 3.80 (28) (35) (220) (196) (63.5) (46.5) (46.5) (260) (238) (118.5) (96.5) 5.38 0.83 1.34 1.65...
  • Page 328 Unit: inch(mm) Power Dimensions [inch（mm）] supply Type voltage 12.6 9.45 21.7 20.9 10.0 5.51 FRN040F1S-2DY (320) (240) (550) (530) (255) (140) FRN050F1S-2DY 24.2 23.4 4.53 0.18 2xφ0.39 0.39 Three- (615) (595) (115) (4.5) (2xφ10) (10) FRN060F1S-2DY 14.0 10.8 10.6 6.10 phase (355) (275)

  • Page 329: Dc Reactor

    8.5.2 DC reactor Dimension [inch (mm)] Power Mass Mounting Terminal supply Inverter type Reactor [lbs(kg)] through through voltage hole for: hole for: 10.0 ± 0.39 4.17 ± 0.08 2.09 ± 0.04 8.86 3.39 5.71 5.71 FRN075F1S-2DY DCR2-75C Three- FRN100F1S-2DY (255 ± 10) (106 ±...

  • Page 330: Keypad

    8.5.3 Keypad Unit: inch(mm) 8-16...

  • Page 331: Panel Cut Out

    8.5.4 Panel cut out 208V 3-phase inch (mm) FRN001F1S-2DY, FRN002F1S-2DY FRN007F1S-2DY, FRN010F1S-2DY FRN003F1S-2DY, FRN005F1S-2DY FRN015F1S-2DY FRN020F1S-2DY, FRN025F1S-2DY FRN040F1S-2DY FRN030F1S-2DY 8-17...
  • Page 332 208V 3-phase inch (mm) FRN050F1S-2DY, FRN060F1S-2DY FRN075F1S-2DY, FRN100F1S-2DY FRN125F1S-2DY 8-18...
  • Page 333 460V 3-phase inch (mm) FRN001F1S-4DY, FRN002F1S-4DY FRN010F1S-4DY, FRN015F1S-4DY FRN003F1S-4DY, FRN005F1S-4DY FRN020F1S-4DY FRN007F1S-4DY FRN025F1S-4DY, FRN030F1S-4DY FRN050F1S-4DY, FRN060F1S-4DY FRN040F1S-4DY 8-19...
  • Page 334 460V 3-phase inch (mm) FRN075F1S-4DY FRN100F1S-4DY FRN125F1S-4DY, FRN150F1S-4DY FRN200F1S-4DY 8-20...
  • Page 335 460V 3-phase inch (mm) FRN250F1S-4DY, FRN300F1S-4DY FRN400F1S-4DY, FRN450F1S-4DY FRN350F1S-4DY FRN500F1S-4DY, FRN600F1S-4DY FRN700F1S-4DY, FRN800F1S-4DY FRN900F1S-4DY 8-21...

  • Page 336: Protective Functions

    8.6 Protective Functions Alarm monitor output Name Description displays [30A/B/C] Overcurrent Stops the inverter output to protect the inverter from an During protection overcurrent resulting from overload. acceleration Short-circuit Stops the inverter output to protect the inverter from protection overcurrent due to a short-circuiting in the output circuit. During deceleration Ground fault...

  • Page 337: Options

    Alarm Name Description monitor output displays [30A/B/C] Ffus Blown fuse Upon detection of a fuse blown in the inverter’s main circuit, this function stops the inverter output. (Applicable to 125HP or above (for both 3-phase 208 V and 3- phase 460 V)) Abnormal Upon detection of an abnormal condition in the charger circuit inside the inverter, condition in...
  • Page 338 Alarm Name Description monitor output displays [30A/B/C] Operation Start The inverter prohibits any run operations and displays on the error detection check 7-segment LED monitor if any run command is present when: function - Powering up - An alarm is released (the key is turned ON or an alarm reset (RST) is input.) - "Enable communications link (LE)"...
  • Page 339 Inverter type source /Ground fault (HP) (3-phase) w/ DCR w/o DCR circuit interrupter (GFCI) FRN001F1S-2DY FRN002F1S-2DY * with overcurrent FRN003F1S-2DY protection FRN005F1S-2DY FRN007F1S-2DY FRN010F1S-2DY FRN015F1S-2DY FRN020F1S-2DY 208 V FRN025F1S-2DY FRN030F1S-2DY FRN040F1S-2DY FRN050F1S-2DY FRN060F1S-2DY FRN075F1S-2DY FRN100F1S-2DY FRN125F1S-2DY FRN001F1S-4DY FRN002F1S-4DY...
  • Page 340 Name of peripheral Function and application equipment Molded case circuit breaker Ground fault When connecting the inverter to the power supply, add a recommended molded case circuit interrupter circuit breaker and ground fault circuit interrupter in the path of power supply. Do not use * with overcurrent the devices with the rated current out of the recommenced range.
  • Page 341 In case the inter-phase unbalance factor of the commercial power supply exceeds 3%, you would need to take other measures such as increasing the capacity of the inverter. Contact your Fuji Electric representative. • In a DC link bus system (using terminals [P (+)] and [N (-)]), the AC reactor protects the...
  • Page 342 Name of option Function and application External An external potentiometer may be used to set the drive frequency. Connect the potentiometer potentiometer for to control signal terminals 11 to 13 of the inverter. frequency commands Extension cable The extension cable connects the RS-485 communications port (RJ-45) with a keypad or an for remote RS-485-USB converter.

  • Page 343: Chapter 10 Conformity With Standards

    Chapter 10 CONFORMITY WITH STANDARDS 10.1 Conformity with UL Standards and Canadian Standards (cUL-listed for Canada) 10.1.1 General The UL standards, originally established by Underwriters Laboratories, Inc. of U.S., are now a set of standards authorized in the U.S. for preventing fire and accidents, thereby protecting operators, service personnel, and ordinary citizens.

  • Page 344: Harmonic Component Regulation In The Eu

    10.4 Harmonic Component Regulation in the EU 10.4.1 General When a general-purpose industrial inverter is to be used in the EU, the harmonics emitted from the inverter to power lines are strictly regulated as stated below. When an inverter whose rated input is 1kW or below is connected to a public low-voltage power supply, it is subject to the harmonics emission regulations (users A and B below), except when the inverter is connected to an industrial low-voltage power supply (user C below).

  • Page 345: Conformity With The Emc Directive In The Eu

    10.5 Conformity with the EMC Directive in the EU 10.5.1 General The CE Marking on inverters does not ensure that the entire equipment including CE-marked products is compliant with the EMC Directive. Therefore, it is the responsibility of the equipment manufacturer to ensure that the equipment including the product (inverter) or connected with it actually complies with the standard and to put a CE Marking as the equipment.
  • Page 346 Leakage current (mA) * EMC-compliant supply Inverter type Installation style filter model voltage Normal condition Worst condition FRN001F1S-2DY FRN002F1S-2DY EFL-4.0E11-2 2.96 2.96 FRN003F1S-2DY FRN005F1S-2DY FRN007F1S-2DY EFL-7.5E11-2 10.6 10.6 FRN010F1S-2DY 20.0 23.0 EFL-15SP-2 FRN015F1S-2DY Split style FRN020F1S-2DY 3-phase 20.0 23.0 See Figure 10.2 (B).

  • Page 347: Recommended Installation Of Emc-Compliant Filter

    10.5.3 Recommended installation of EMC-compliant filter This section shows how to install an EMC-compliant filter. In the footmount style, mount the inverter on the EMC-compliant filter. In the split style, mount the filter beside or under the inverter. For the footmount style, inverters with ratings of 460 V 7.5HP and 20HP require a panel-mount adapter (option) as listed below.

  • Page 348: Emc-Compliant Environment And Class

    The EMC-compliant filter and the inverter should be connected with each other according to the procedure given below. The wiring on the inverter and motor should be performed by an authorized electrical engineer. In order to ensure compliance with the EMC Directive, this procedure should be followed as closely as possible. Basic connection procedure 1) Install the inverter and the EMC-compliant filter on a grounded metal plate.
  • Page 349 FRN150F1S-4DY 1) Remove the front cover. (Refer to Chapter 2, Section 2.3 "Wiring.") 2) Change wiring at points A and B shown in the internal location diagram below. Figure 10.4 Internal Location Diagram (FRN150F1S-4DY) Point A As shown below, remove the screw (M4) to release the wire end terminal and secure the terminal to the support with the screw removed.
  • Page 350 FRN200F1S-4DY 1) Remove the front cover. Refer to Chapter 2, Section 2.3 "Wiring." 2) Change wiring at points A and B shown in the internal location diagram below. Figure 10.7 Internal Location Diagram (FRN200F1S-4DY) Point A As shown below, remove the screw (M4) to release the wire end terminal and secure the terminal to the support with the screw removed.
  • Page 351 FRN250F1S-4DY to FRN350F1S-4DY 1) Remove the front cover. Refer to Chapter 2, Section 2.3 "Wiring." 2) Change wiring at points A and B shown in the internal location diagram below. Figure 10.10 Internal Location Diagram (FRN250F1S-4DY to FRN350F1S-4DY) Point A As shown below, remove the screw (M4) to release the wire end terminal and secure the terminal to the support with the screw removed.
  • Page 352 Normal condition Worst condition FRN150F1S-4DY FS5536-250-28 FRN200F1S-4DY 3-phase 460 V 108.0 464.0 FRN250F1S-4DY FRN300F1S-4DY FS5536-400-99-1 FRN350F1S-4DY For improvement in EMC compliance for 3-phase 208 V types of inverters, consult your Fuji Electric representative for improving EMC-compliant level. 10-10...
  • Page 353 App. Inverter Generating Loss FRENIC-Eco Watts Loss Watts Loss [W] Model Low carrier High carrier frequency frequency FRN001F1S-2DY 100*1 FRN002F1S-2DY 140*1 FRN003F1S-2DY 170*1 FRN005F1S-2DY 240*1 FRN007F1S-2DY 390*1 FRN010F1S-2DY 470*1 FRN015F1S-2DY 620*1 FRN020F1S-2DY 880*1 FRN025F1S-2DY 950*1 FRN030F1S-2DY 1020 1120*1 FRN040F1S-2DY 1380...
  • Page 354 MEMO...
  • Page 355 In no event will Fuji Electric Co., Ltd. be liable for any direct or indirect damages resulting from the application of the information in this manual.
  • Page 356 Fuji Electric Co., Ltd. Fuji Electric Corp. of America 2011-4 (D11/K07) 10CM...
