MOUNTING THE FIREBALLS COMP
Your FireBalls Comp is designed to be
mounted on your handlebars or on
your helmet. Use a 3mm hex-wrench
and the screws provided to install either
the handlebar mounts or the helmet
mount to the lamp housing.
HANDLEBAR – Attach your FireBalls
Comp securely to the handlebars with
the quick-release handlebar mounts.
The lamp housing should straddle the
stem and may be mounted above or
below the handlebars. Always use
BOTH quick-release mounts. Slide the battery pack and electronics housing into one of
your water-bottle cages. Use the long Velcro strap to secure the battery into the cage
by wrapping it completely around the frame tube Secure the power cable to your frame
with the two short Velcro straps. Be sure to leave enough slack in the power cable so
that it will not hinder the rotation of your handlebars. Plug in the electrical connector
between the battery and lamp housing. Make sure the power cable cannot become
entangled in any of the moving components of your bicycle.
HELMET – Attach your FireBalls Comp securely to your helmet by looping the Velcro
strap through the vents. The angle of the helmet mount is adjustable. FireBalls Comp
can be positioned on top or towards the front of your helmet. Secure the power cable
to the back of your helmet with the two short Velcro straps. Drop the battery pack into
the backpack. Be sure the fuel gauge lights can be seen through the slot in the back-
pack. Put on the backpack and make sure all of the straps are secure and cannot
become entangled in any of the moving components of your bicycle. For the most com-
fortable fit use both the waist strap and the sternum strap.

BATTERY PACK

the pack is very low and should be charged as soon as possible.
Use extreme care to avoid a short-circuit across the battery
contacts. Never allow any metal objects to touch the contacts on the
battery. In the event of a short-circuit, an Internal fuse will be
tripped to avoid damage to the battery. The fuse will reset itself
automatically when the short circuit is removed.

CHARGING THE BATTERY

The FireBalls Comp features the most advanced charging system ever offered in a
bicycle lighting system. The charge cycle is controlled by the fuel gauge located within
the battery pack. The system is designed to allow the battery to be left on the charger
indefinitely, without the risk of overcharging the battery. When the battery is fully
charged, the fuel gauge will signal the charger to stop charging. In order to counteract
Your FireBalls Comp battery pack features an integrated fuel
gauge that monitors the condition of the battery during use, while
charging and in storage. Because it is located inside the battery
housing, the FireBalls Fuel gauge will always give an accurate
representation of the battery capacity. The five LED indicators show
battery capacity in 20% increments. The lights will illuminate auto-
matically when the light is in use and when the battery is charg-
ing. To check the capacity when the battery is
in storage simply press the button on the bat-
tery. When the battery capacity is below 10%
the first LED will blink. This is an indication that
