TERO EQ KIT
ASSEMBLY GUIDE

Advertisement

loading

Related Manuals for Specialized TERO EQ KIT

Summary of Contents for Specialized TERO EQ KIT

  • Page 1 TERO EQ KIT ASSEMBLY GUIDE...

  • Page 2: Warranty

    CAREFULLY AND STORE IN A SAFE PLACE. INFORMATION This user manual is specific to your Specialized Turbo Tero bicycle fenders and racks. This manual should be read in addition to the Tero user manual supplied with your bicycle. The user WARNING! The total maximum load capacity of the rack itself is 27kg (59lbs).
  • Page 3 ASSEMBLY PRE PA RE T H E T E R O . Before starting, remove the battery and place the Tero in a „ stable bicycle stand then remove the wheels. Fig. 1 Power off the Tero on the MasterMind TCD-w (A). „...
  • Page 4 RE MOVE TH E C RA N K A N D M OTO R COVE R Fig. 4 Using an 8 mm hex key, remove the non-driveside „ crank arm. Fig. 5 Using a T20 Torx key, remove the non-driveside motor „...
  • Page 5 AS S EM B L E T H E REA R RAC K & FE NDE R . Fig. 8 The rear rack is pre-assembled to the rear fender. „ Orientate the adjustment washer with the offset hole „ facing toward the front of the Tero. Mount the rack and fender assembly to the mounting „...
  • Page 6 RE MOVE TH E M OTO R B L I N D PLUG S Fig. 10 Remove the blind plugs from the rear and front light „ ports on the motor. Front light Rear light C ON N ECT T HE F R O N T L I G H T C AB L E Fig.
  • Page 7 Fig. 12 Guide the light cable above the battery hook (A) and „ down the downtube. Insert the cable into the cable clips to position the „ cable above the battery (B). Route the cable along the NDS upper side of the „...
  • Page 8 A S S EMB L E T H E C OV ER A N D C RANK INFO: Before replacing the motor cover and crank, check the front and rear light functionality. Fig. 15 Replace the non-drive side motor cover and nuts. „...

  • Page 9: Front Light

    MOTOR CONNECTORS Battery E-bike Blind plug Speed sensor Rear light Front light...
  • Page 10 SPECIALIZED BICYCLE COMPONENTS We may occasionally issue updates and addendums to this document. Please periodically check www.specialized.com or contact Rider Care to make sure you have the 15130 Concord Circle, Morgan Hill, CA 95037 (408) 779-6229 latest information. Info: specialized.com / 877-808-8154...
