Summary of Contents for Specialized Speedzone Comp

  • Page 1 Printable manuals available at: www.specialized.com (click on: support tab)

  • Page 2: Table Of Contents

    Table of contents Components of the Speedzone Comp Setting power zones (auto or manual) Installing Computer Mounts Replacing the battery Installing speed & cadence transmitter Specifications and ranges Speedzone Comp user interface Speedzone Comp Terminology Easy set-up and resetting Troubleshooting...

  • Page 3: Components Of The Speedzone Comp

    Components of the Speedzone Comp Speedzone cyclo- Cadence sensor computer head unit Spoke magnet Cadence magnet Zip ties Handlebar bracket Base mount Steerer tube bracket Speed transmitter...

  • Page 4: Installing Computer Mounts

    Installing Computer Mounts • Install the steerer tube bracket base assembly on the steerer tube. Re-install the steerer tube top cap. • Place handlebar bracket on handlebar, attach the base mount to the handlebar bracket with the included bolt. • Adjust base to desired angle with bolt adjustment. handlebar bracket steerer tube bracket...

  • Page 5: Installing Speed & Cadence Transmitter

    Installing speed & cadence transmitter • Adjust spoke magnet so path of rotation passes along the groove area inside the sensor. IMPORTANT: Placing magnet outside the groove path may cause improper reading. • Attach the cadence magnet with self adhesive pad to the crank arm, and position the sensor’s raised line within the magnet’s rotation path.

  • Page 6: Speedzone Comp User Interface

    Speedzone Comp user interface Average speed comparator Bike #1 indicator Battery low indicator Bike #2 indicator Digital Speed Display Miles (English)/KM (metric) Speed (10ths) *Power indicator Power(watts)/Heartrate(BPM) *Heartrate indicator (when power is not paired) Secondary function display *Heartrate signal Secondary function indicator...

  • Page 7: Easy Set-Up And Resetting

    Easy set-up and resetting Wake from shipping mode Reset and all clear Hold “start/stop” Press reset button for 2 seconds to to enter easy set up. initiate easy setup; this is only required Blank screen to wake unit from indicates shipping mode shipping mode (first purchased).
  • Page 8 Language selection & clock setting From initial start-up: select language select 12/24 hr select hour Setup...
  • Page 9 ...continued clock and date setting select minute select year select month Setup...
  • Page 10 Wheel and tire size selection (To manually set wheel size see page 20) bicycle #1 bicycle #2 scroll through scroll through scroll through scroll through select day wheel sizes wheel sizes wheel sizes for wheel sizes for bike #1 bike #2 Setup...
  • Page 11 Metric (km) or English (mi) & odometer km or miles select km / miles select digit select digit Setup...
  • Page 12 Heart rate / normal power / power zone • Max heart rate guideline: 220 minus your age • Normal power (N-PWR) = power (watts) sustained for 20-40 minutes of riding auto To set manually see page 28 enter normal enter max HR power Setup...
  • Page 13 Pairing digital ANT+™ wireless device Head unit is searching for Speed, Cadence, Heart, and Power transmission signal from ANT+ digital transmitters. Clock Speed / Cadence / head unit is begin signal pairing searching for Heartrate / Power sequence... digital signals PAIRED Setup...
  • Page 14 Calibrating power devices When “CALIB” is flashing follow instruction for calibrating your specific power meter. Calibration mode will only activate when paired with power device (see page 13). 2 sec. Clock head unit is Power device is searching for calibrated begin calibrating...

  • Page 15: Using Your Speedzone Comp (Keyflow)

    Using your Speedzone Comp (keyflow) Press to access major functions Press to access sub functions...

  • Page 16: Re-Entering The Pairing Sequence

    Re-entering the pairing sequence Scroll to AVGSPD mode, and hold “set” key for 2 seconds. Every wireless device must be ANT+ compatible device to transmit data. S - Speed C - Cadence H - Heart Rate P - Power Head unit is searching for 2 sec.

  • Page 17: Re-Entering Calibration Sequence

    Re-entering calibration sequence Scroll to AVGPWR mode, and hold “set” key for 2 seconds begin calibrating... 2 sec. (see page 14)

  • Page 18: Clearing Trip/Atm (Auto Timer)

    Clearing TRIP/ATM (Auto Timer) In “TRIP“ or “ATM“ mode, press “mode“ key for two seconds. Resetting “TRIP“ will only clear ride shown data only and PC download data is saved. 2 sec.

  • Page 19: Selecting Bike #1 - #2 Setting

    Selecting Bike #1 - #2 setting When in “TRIP“ mode, press “set“ key for two seconds. Devices (ANT+ transmitters) must be “paired” for second (bike #2) setting. *bicycle #2 *bicycle #1 2 sec. proceeds to AVGSPD function...

  • Page 20: Re-Setting The Wheel/Tire Size

    Re-setting the wheel/tire size • In “ODO” mode, press “mode” key for two seconds • Select desired wheel/tire size (see earlier section for details) *bicycle #2 *bicycle #1 scroll through scroll through 2 sec sizes or manually sizes or manually set size in mm set size in mm activates wheel/...

  • Page 21: Manually Setting Wheel/Tire Size

    Manually setting wheel/tire size (See wheel circumference calculation page 22) select digit select digit 2 sec activate 1st digit...
  • Page 22 Calculating wheel circumference • Mark your tire and the ground where TIRE SIZE SIZE/MM they meet. Roll bike forward full revolu- 26X1.0 1943 26X1.25 1949 tion and mark the point on the floor. 26X1.95 2055 • Measure the distance in millimeters 26X2.0 2060 26X2.1...

  • Page 23: Using The Timer

    Using the timer Timer function (Stopwatch/Lap timer). Press “mode” to “ATM” screen then press “set” to “TIMER” screen. Timer continues press to start Set button starts until start/stop Lap function is pressed again...
  • Page 24 ...continued use of timer Lap timer function (Stopwatch/Lap timer) Lap time data press to stop 2 sec can be reviewed using set key reset Lap timer...
  • Page 25 Using the interval timer • When in “INTRVL” mode, press “set” key for two seconds. • Set target interval time using “mode” and “set” keys. select digit press to start 2 sec.

  • Page 26: Re-Setting The Clock And Language

    Re-setting the clock and language • In “CLOCK” mode, press “set” key for two seconds. • Set time and date by using “mode” and “set” keys. • Press “mode” for two seconds to set language. 2 sec. select 12/24 hr select day...

  • Page 27: Heart Rate Zone Setup

    Max heart rate setup • Max heart rate guideline: 220 minus your age. • Heart rate zones table on page 32. return to % of max heart rate enter max HR 2 sec. zone view...

  • Page 28: Setting Power Zones (Auto Or Manual)

    Setting power zones (auto or manual) Setting “N-PWR” (normal power) will automatically set 5 (five) training zones. Auto power zones table on page 32. Power function requires ANT+ compatible power devices. auto enter normal Proceed to 2 sec. power manually set...
  • Page 29 Manual power zone setting Press “mode” from “ZONE AUTO” low range (% of N-PWR) upper range (% of N-PWR) Set upper range value in % of normal power...

  • Page 30: Replacing The Battery

    Replacing the battery Rotate battery cover quarter turn to remove battery. Speed/cadence sensor headunit CR2032 battery...

  • Page 31: Specifications And Ranges

    Specifications and ranges Time of day Stopwatch chronograph • 24 hours with one minute resolution • 9h 59m 59s individual timing session • Function in either 12 or 24 hour formats • 1 second resolution • Default value + 12:00.00 PM January 1, •...
  • Page 32 Tables appendix Heart rate Zones Power Zones “1ZHRT” = Heart rate zone 1 “PWRZN1” = Power Zone 1 HR Zone % of Max HR Power Zone % of N-PWR Zone 1 0% - 60% Zone 1 0% - 80% Zone 2 61% - 90% Zone 2 80% - 90%...

  • Page 33: Speedzone Comp Terminology

    Speedzone Comp Terminology PC LINK AVGHRT Computer Link Average Heart Rate CLOCK MAXHRT Clock Maximum Heart Rate YEAR Year HRZN1 Heart Rate Zone #(1) MONTH Month N-PWR Normal(Threshold)Power PWR% % of Normal Power DATE AVGPWR Date Average Power TRIP MAXPWR...

  • Page 34: Troubleshooting

    • Speedzone computer is intended for use on bicycle only and should not be used on motorized vehicles. • See your authorized Specialized dealer if you have trouble installing or operating the computer.

  • Page 35: Warranty Information

    (2) years from the date of original purchase from an authorized Specialized retailer. If this product is found to be defective in material or workmanship within two (2) years from the date of original...
  • Page 36 FCC ID: O4GSPPRO MADE IN CHINA This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions: this device may not cause harmful interference, and this device must accept any interference received, including interference that may cause undesired operation.
