Specifications - Acon On Call Plus User Manual

Feature
Measurement Range
Result Calibration
Sample
Minimum Sample Size
Test Time
Power Source
Battery Life
Glucose Units of Measure
Memory
Meter Size
Display Size
Weight
Operating Temperature
Operating Relative Humidity
Hematocrit Range
Data Port

Specifications

20 to 600 mg/dL
Plasma-equivalent
Fresh capillary whole blood
1 µL
10 seconds
One (1) CR 2032 3.0 V coin cell battery
12 months or approximately 1,000 tests
The meter is pre-set to either millimoles per liter
(mmol/L) or milligrams per deciliter (mg/dL)
depending on the standard of your country. The
meter will be set to mg/dL by default when sold in
the United States.
Up to 300 records with date and time
85 mm × 54 mm × 20.5 mm
35 mm × 32.5 mm
Approximately 49.5 g (with battery installed)
41-113°F (5-45°C)
20-90% (non-condensing)
30-55%
9600 baud, 8 data bits, 1 stop bit, no parity
34
Specification
