USING THE WEB MANAGEMENT INTERFACE: NETWORK VISUALIZATION
Viewing Network Visualization
1
Click the Network Status tab.
2
Scroll to Network Visualization.
3
Select a refresh rate from the drop-down menu. Faster refresh rates will use more bandwidth.
4
Click Network Visualization. A file named node-monitor.kml will download.
5
Open this file in Google Earth to view network visualization.
92
© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
