PHYSICAL SETUP: SIDE CONNECTORS
Quick Reference:
Part Number Description
CBL-DATA-2001 22-Pin to RJ45 Receptacle
CBL-DATA-2003 22-Pin to USB 2.0 Type A
Female
CBL-DATA-2004 22-Pin to 6-Pin Push Pull
Android™ USB
CBL-DATA-2005 22-Pin to DB9 Serial Socket PTT/EUD,
CBL-DATA-2007 22-Pin to RJ45 Receptacle
and USB 2.0 Type A Male
CBL-DATA-2009 22-Pin to RJ45 Flying Leads DATA
CBL-DATA-2010 22-Pin to RJ45 Flying Leads DATA
CBL-DATA-3002 22-Pin to Audio and Video
Out
CBL-AUD-0001 22-Pin to U-329
38
Side Connec- Uses
tor(s)
DATA Connects to a standard RJ45 Ethernet cable. Use
this cable to connect the unit to a computer for
configuration.
PTT/EUD, Connects USB accessories via a standard USB A
DATA, RoIP port.
PTT/EUD, Connects an Android™ EUD or Screen
DATA, RoIP
Connects serial devices via a DB9 socket
DATA, RoIP
DATA Connects to USB devices via a standard USB A
plug and to a standard RJ45 Ethernet cable
Flying leads for custom Ethernet integration (72")
Flying leads for custom Ethernet integration (18")
PTT/EUD Connects to a standard HDMI cable to display
video on a TV or Monitor and connects to a
speaker box or headset.
RoIP Connect the unit to a Legacy Radio via a U-329
connector.
