Technical Specifications
National Stock Number Pending
BT Part Number BT-70716BG
Nominal Voltage 10.8V
Maximum Voltage 12.6V
Pulse Discharge 40A ≤ 1 ms
Operating Temperature -30°C to +60°C (-22°F to +140°F)
Recommended Storage Temperature -40°C to +40°C (-40°F to +104°F)
State of Charge Indicator Not Applicable
© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
Length: 2.8 in. (71 mm) Width: 1.6 in.
(41 mm)
Dimensions
Height: 3.4 in. (86 mm)
Weight 0.75 lbs (0.34 kg)
Capacity 6.4Ah
Discharge 6A Max Continuous
Connector Flat Contacts (bottom), Fly Wheel
Connection (top)
Disposal Check local regulations (Contains 0%
Mercury or Cadmium)
