WARNING!:
User MUST refer to the Professional Installer – Compliance Section of this manual for ap-
!
proved antenna types. This warning applies only to RF-2100 with the FCC ID 2AG3J-RF-2100 and RF-5100 with
the FCC ID 2AG3J-RF-5100.
?
How do I tell if my antennas and radio modules are compatible?
Find the part numbers on the antennas. Antenna part numbers are on a sticker wrapped around the base
1
of the antenna.
Find the part number on the radio module. The radio module part number is on a sticker on the back of
2
the radio module.
Each part number will begin with ANT- (antennas) or RF- (radio modules) followed by four (4) digits. The
3
first digit references the radio band of the part. Make sure that the first digit of the antennas and radio
module match.
WARNING!:
DO NOT use mismatched antennas and radio modules. This configuration will result in very
!
poor performance and/or damage to the device. If you do not have matching antennas and radio modules,
contact Persistent Systems.
WARNING!:
DO NOT switch radio modules while device is powered on. Power off device before changing
!
radio modules.
WARNING!:
the MPU5 is not IP68 rated when the radio module is not attached. Ensure you are in a dry,
!
dust-free environment before changing radio modules.
