USING THE WEB MANAGEMENT INTERFACE: CONFIGURATION FILES

Loading Settings from a Configuration File

Click the Node Configuration
1
tab.
Configure Node Name and Management IP configuration (IP, Netmask, Gateway) source.
4
Keep Current Settings: Node Name, Management IP, Netmask, and Gateway will not
change after the configuration file is loaded.
Pull from Config File: Node Name, Management IP, Netmask, and Gateway will be set to
the values in the Config File you are loading.
Quick Setup: A box will appear that will allow you to enter a Node Name and Manage-
ment IP Address to be set when the Config File is loaded.
Configure Push to Managed Node List.
5
No: The configuration file will be loaded on this node only.
Yes, Require All: The configuration file will be loaded on every node in the Managed
Node List if and only if all nodes in the Managed Node List are able to be contacted. If at
least one node in the Managed Node List is not able to be contacted, the configuration
file will not be loaded onto any nodes.
Yes, Any Available: The configuration file will be loaded onto any node in the Managed
Node List that is able to be contacted. The configuration file will not be loaded on any
nodes in the Node List that are not able to be contacted.
84
Click the Config Manage-
2
ment button.
© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
3
Click Load File.
