PHYSICAL SETUP: POWER
Connecting Power
If you are using a battery, make
1
sure that the battery is charged.
Align the circular three pin connector on
2
the power source with the circular three
pin connector on the bottom of the MPU5.
28
Push the connectors together. Make sure
3
the connector is seated properly.
© 2010 - 2018 Persistent Systems, LLC – All Rights Reserved
