USING THE WEB MANAGEMENT INTERFACE: NETWORK STATUS

Network Status Tab

The Network Status tab allows you to view information about every node in the network at the
same time. Besides MANET Monitor, Network Visualization, and Channel Plan, each page displays
the same information as its counterpart on the Node Status page, but for every node in the net-
work.
Unit Info: general node information for every node in the network
Neighbor Status: neighbors and SNR for every node in the network
MANET Monitor: number of nodes in the network, serial number, node name, IP address, velocity
and direction, altitude, neighbors, battery percentage remaining, SNR for every node in the network
GPS Status: GPS information for every node in the network
Network Traffic Load: traffic load information for every node in the network
Network Visualization: view the network in Google Earth
Channel Plan: channel setting for each radio
IP Flow List: IP flows on the network
IP Multicast Status: IP Multicast information
