CONCRETE PULVERIZERS

ATTACHMENT CONTROLS

The LaBounty concrete pulverizer replaces the bucket of an excavator and operates with the same controls—
no additional hydraulics are required. The bucket dump control opens the attachment and the bucket curl
closes the attachment.
Determine the control for each movement of the attachment before attempting to operate. Practice
the machine movements as described in Getting the Feel of the Attachment section of this manual.
BUCKET DUMP=ATTACHMENT
OPEN
Page 4 Section 4 Introduction to Safety
BUCKET CURL=ATTACHMENT
FIGURE 4-1
CLOSE
