Chapter 2
The SmartICE under panel connectors include power, PIN, and line ports.
PIN port
Line port
Battery pack panel
W
ARNING
When using the Mobitex and CDPD version, the user must ensure that the device is not
positioned in such a way as to put the side of the terminal near the antenna and above the credit
card slot less than 3cm (1 1/8") from any part of the body for a period of six minutes or more.
Not complying with this waring may expose the user or customer to levels of elecrtomagnetic
radiation exceeding the FCC guidelines.
2-2
Figure 2-1. SmartICE under panel connectors
SmartICE Hardware and Installation Manual
Power port
