Step-8; Step-9; Step-10 - Go Rhino DOMINATOR II Series Installation Instructions

#11
Step-8 Align the side step with the vehicle and tighten all nuts and bolts.
Step-9 Driver side front bracket installation.
Measure rearward from the front fender bolt approximately 14" and locate the hole in the body pinch mold and the
8mm threaded insert spot welded in the rocker panel. install a 5/16" U-Nut in the pinch mold and attach one of the
C0921 brackets to the rocker panel using (1) 8mm x 25mm hex bolt, (1) 5/16" lock washer and (1) 5/16" flat
washer and to the pinch mold using the (1) 5/16" x 1" hex bolt, (1) 5/16" lock washer and (1) 5/16" flat washer.
Leave the bolts loose for final adjustment. Photo #13 & #14
#13
Step-10 Driver side center and rear brackets.
Repeat step 5, 6 & 7 to install the driver side center bracket, rear bracket and side step. Align the side step with
the vehicle and tighten all nuts and bolts.
Remember to check and retighten all nuts and bolts periodically.
#12
#14
