#1
Step-2 Locate in front of the urea tank the plastic plug in the body rocker panel. Remove the plug, Install the vinyl
gasket over the threads of the 3/8" T-Bolt and install T-Bolt in the rocker panel as shown. Photo #3 & #4
#3
Step-3 From the front of the urea tank, position the front mounting bracket between the tank and the body pinch
mold. Slide the bracket rearward and align the holes in the bracket with the T-Bolt and U-Nut. Photo #5 & #6
#5
Step-4 Position the hole in the front of the bracket over the T-Bolt and install (1) 3/8" flat washer, (1) 3/8" lock
washer and (1) 3/8" hex nut. Align the hole in the flange of the bracket with the U-Nut and install (1) 5/16" flat
#2
#4
#6
