2011-12 Chevrolet Silverado / GMC Sierra 2500HD, 3500HD Crew Cab P/U 2/4WD (Diesel)
Do not attempt to install this product on any vehicle other than the one it is designed for and listed above!
Qty
Part Description
1
8mm x 25mm Hex Bolt
10
5/16" U-Nut
10
5/16" x 1" Hex Bolt
11
5/16" Flat Washer
11
5/16" Lock Washer
1
3/8" T-Bolt
12
3/8" x 1 ¼" Hex Bolt
13
3/8" Lock Washer
Tool Required:
½", 9/16" & 13mm Socket
½", 9/16" & 13mm Wrench
3/16" Hex Key
Ratchet & Ratchet Extension
Read the installation instructions completely and verify that all of the parts listed are accounted for.
Step-1 This installation uses three mounting brackets per side. Begin by installing the passenger side front
bracket. Measure from the front fender bolt rearward approximately 14", locate the hole in the body pinch mold
and install (1) 5/16" U-Nut as shown. Photo #1 & #2
INSTALLATION INSTRUCTIONS
DOMINATOR II Series SideSteps Part Number D24051 (B-PS)
Parts List
Qty
25
13
1
2
3
1
1
1
Approximate installation time: 45min
Installation
Part Description
3/8" Flat Washer
3/8" Hex Nut
C0912 Passenger Front Bracket
C0922 Passenger Center & Rear Bracket
C0921 Driver Front, Center & Rear Bracket
Vinyl Gasket
D24050P Passenger Side Step
D24050D Driver Side Step
Advertisement
Table of Contents
Related Manuals for Go Rhino DOMINATOR II Series
Summary of Contents for Go Rhino DOMINATOR II Series
- Page 1 INSTALLATION INSTRUCTIONS DOMINATOR II Series SideSteps Part Number D24051 (B-PS) 2011-12 Chevrolet Silverado / GMC Sierra 2500HD, 3500HD Crew Cab P/U 2/4WD (Diesel) Do not attempt to install this product on any vehicle other than the one it is designed for and listed above!
- Page 2 Step-2 Locate in front of the urea tank the plastic plug in the body rocker panel. Remove the plug, Install the vinyl gasket over the threads of the 3/8” T-Bolt and install T-Bolt in the rocker panel as shown. Photo #3 & #4 Step-3 From the front of the urea tank, position the front mounting bracket between the tank and the body pinch mold.
- Page 3 washer, (1) 5/16” lock washer and (1) 5/16” x 1” hex bolt. Leave the nut and bolt loose for final adjustment. Photo #7 & #8 Step-5 Passenger side Center bracket installation. Measure from the front fender bolt reward approximately 58 7/8” and locate the hole in the body pinch mold and the plastic plug in the rocker panel.
- Page 4 Step-8 Align the side step with the vehicle and tighten all nuts and bolts. Step-9 Driver side front bracket installation. Measure rearward from the front fender bolt approximately 14” and locate the hole in the body pinch mold and the 8mm threaded insert spot welded in the rocker panel.
- Page 5 Features and Benefits: Dominator II (one piece) • Application specific installation brackets make for faster, easier installation • Patented step and mounting system allow easier, safer entry and exit • No drilling required on most models and body lift kit compatible •...
