2014-2015 Chevrolet Silverado & GMC Sierra 1500 Double Cab
2015 Chevrolet Silverado & GMC Sierra 2500HD, 3500HD Double Cab
Do not attempt to install this product on any vehicle other than the one listed above!
Qty.
Part #
1
3
C0751
2
3
C0752
3
12
4
6
5
6
6
18
7
12
8
12
9
12
10
24
11
12
12
1
D24043D
13
1
D24043P
Tool Required:
13mm & 9/16" Socket
13mm & 9/16" Wrench
Ratchet & Ratchet Extension
Tape Rule
Approximate installation time: 60 min
Installation Instructions
Dominator 2
Side Steps
Parts List
Description
Driver Side Bracket
Passenger Side Bracket
M8-1.25 x 25mm Hex Bolt
M8-1.25 Hex Nut
M8-1.25 U-Nut
5/16" Flat Washer
5/16" Lock Washer
3/8"-16 x 1-1/4" Hex Bolt
3/8" Hex Nut
3/8" Flat Washer
3/8" Lock Washer
Driver Side Step
Passenger Side Step
P art # D24043 (B-PS)
Torque
#1
Driver Side
15 Ft. Lbs.
30 Ft. Lbs.
#2
Passenger
Side
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Go Rhino dominator 2 series
Summary of Contents for Go Rhino dominator 2 series
- Page 1 Installation Instructions Dominator 2 Side Steps P art # D24043 (B-PS) 2014-2015 Chevrolet Silverado & GMC Sierra 1500 Double Cab 2015 Chevrolet Silverado & GMC Sierra 2500HD, 3500HD Double Cab Do not attempt to install this product on any vehicle other than the one listed above! Parts List Qty.
- Page 2 Installation This installation uses three brackets per side. Begin by installing the driver side front bracket. Step-1 Measure from the front fender bolt rearward approximately 14”, (Photo 1) and locate the hole in the body pinch mold and the plastic plug in the rocker panel, (Photo 2). Remove the plastic plug from the rocker panel and install (1) M8 U-Nut in the rocker panel, (Photo 2).
- Page 3 Step-3 Locate the hole in the body pinch mold and the plastic plug in the rocker panel for the center and rear mounting brackets. Measure rearward from the front fender bolt approximately 49 5/8” for the center and 67” for the rear bracket.
