- Page 1 TWR-SER2 User’s Manual Rev. 1.2 Freescale Semiconductor Inc.
-
Page 2: Table Of Contents
3.5.3 Additonal RS232 Interfaces ................................8 3.6 CAN Bus ....................................9 3.7 Elevator Connections ..............................10 4 Configuration Settings .......................... 15 4.1 Switch Settings ................................. 15 4.2 Jumper Settings ................................16 5 Mechanical Form Factor ........................17 TWR-SER2 User’s Manual Page 2 of 17... -
Page 3: Overview
1 Overview The Serial2 Tower Board (TWR-SER2) is a peripheral Tower System Module designed to be used with a compatible MCU/MPU Tower Card. The TWR-SER2 provides additional interfaces that are common to feature rich MPU’s. The TWR-SER2 features the following: Industrial-grade Dual Ethernet PHY Transceiver w/ dual RJ-45 Ethernet Jacks, with integrated magnetics and LED’s... - Page 4 ULPI Selection / Isolation Jumpers RS-232 / RS-485 USB OTG / USB Host RXD/TXD Intersil Intersil SMSC ICL3225 ISL3176 USB3300 (RS-232) (RS-485) RS-232 RS-495 DP/DN RX/TX RX/TX Figure 1 - TWR-SER2 Block Diagram TWR-SER2 User’s Manual Page 4 of 17...
-
Page 5: Reference Documents
DP83849I PHYTER DUAL Industrial Temp Ethernet PHY Transceiver USB3300 Industrial Temp Hi-Speed USB PHY with ULPI Interface TJA1051T/3 High-Speed CAN Transceiver 3 Hardware Features This section provides more details about the features and functionality of the TWR-SER2. TWR-SER2 User’s Manual Page 5 of 17... -
Page 6: Power Supply
3.1 Power Supply It is intended that the TWR-SER2 be powered from a source in an assembled Tower System via the 5.0V and 3.3V supplies on the TWR-ELEV. This includes the functional Tower Elevator USB power connector, a capable MCU/MPU controller module, or other Tower System module capable of providing power to the entire Tower System. -
Page 7: Low/Full-Speed Host Usb
VBUS enable/over-current control to the MCU signals. 3.5 Serial Communications Interface The TWR-SER2 is capable of providing up to four additional SCI’s. The number of accessible SCI’s on the TWR-SER2 will depend on the capabilities and Tower Elevator signals connections of the MCU/MPU Module. -
Page 8: Serial-To-Usb
USB CDC. The driver required for the CDC device is located on the included CD and is also available on the TWR-SER2 webpage found at www.freescale.com/tower. If needed the UART0 transceiver signals can be isolated from the Tower Elevator using J7. -
Page 9: Can Bus
Remove to Isolate UARTx_CTS 3.6 CAN Bus The TWR-SER2 features a Controller Area Network interface using an NXP TJA1051T/3 CAN transceiver. The signals from the transceiver are connected to a 6-pin (2x3) header using the following CAN Bus Pin Out. -
Page 10: Elevator Connections
Remove to Isolate CAN_RX 3.7 Elevator Connections The TWR-SER2 features two expansion card-edge connectors that interface to Elevator boards in a Tower System: the Primary and Secondary Elevator connectors. Table 2 provides the pinout for the Primary and Secondary Elevator Connector. An “X” in the “Used” column indicated that there is a connection from the TWR-MEM to that pin on the Elevator connector. - Page 11 TWR-SER2 Primary Connector Name Usage Used Jmp Name Usage Used I2S0_DOUT_SCK GPIO2 / SDHC_D1 I2S0_DOUT_WS GPIO3 I2S0_DIN0 CLKIN0 RMII_REF_CLK I2S0_DOUT0 CLKOUT1 Ground Ground Ground Ground DAC1 DAC0 TMR3 TMR1 TMR2 TMR0 GPIO4 USB_VBUS_EN GPIO6 USB_VBUS_OC 3.3V 3.3V Power 3.3V 3.3V Power...
- Page 12 TWR-SER2 Primary Connector Name Usage Used Jmp Name Usage Used EBI_AD15 EBI_AD14 EBI_AD16 EBI_AD13 EBI_AD17 EBI_AD12 EBI_AD18 EBI_AD11 EBI_AD19 EBI_AD10 EBI_R/W_b EBI_AD9 EBI_OE_b EBI_AD8 EBI_D7 EBI_AD7 EBI_D6 EBI_AD6 EBI_D5 EBI_AD5 EBI_D4 EBI_AD4 EBI_D3 EBI_AD3 EBI_D2 EBI_AD2 EBI_D1 EBI_AD1 EBI_D0 EBI_AD0...
- Page 13 Table 3 - TWR-SER2 Secondary Elevator Connector Pinout TWR-SER2 Secondary Connector Name Usage Used Name Usage Used Jmp 5.0V Power 5.0V Power Ground Ground 3.3V 3.3V Power 3.3V 3.3V Power ELE_PS_SENSE Elevator Power Sense 3.3V 3.3V Power Ground Ground Ground...
- Page 14 TWR-SER2 Secondary Connector Name Usage Used Name Usage Used Jmp LCD_CONTRAST UART2_RTS / TSI2 UART2_RTS LCD_OE / LCD_P27 UART2_CTS / TSI3 UART2_CTS LCD_D0 / LCD_P0 UART3_RX UART3_RXD / TSI4 LCD_D1 / LCD_P1 UART3_TX UART3_TXD / TSI5 LCD_D2 / LCD_P2 UART3_RTS...
-
Page 15: Configuration Settings
AN0_B - Full-Duplex on PHY B Dip 7 *Off* AN0_B - Half-Duplex on PHY B AN1_B - 100Base-TX on PHY B Dip 8 *Off* AN1_B - 10Base-T on PHY B Figure 3 - TWR-SER2 Switch Settings TWR-SER2 User’s Manual Page 15 of 17... -
Page 16: Jumper Settings
Connects TX to T1IN Connects RX to R1OUT RS232 (UART3) Isolation Connects RTS to T2IN Connects CTS to R2OUT Device Mode (capable of powering Tower USB Device Mode System) Figure 4 - TWR-SER2 Jumper Settings TWR-SER2 User’s Manual Page 16 of 17... -
Page 17: Mechanical Form Factor
5 Mechanical Form Factor The TWR-SER2 is designed for the Freescale Tower System as a side mounting peripheral and complies with the electrical and mechanical specification as described in Freescale Tower Electromechanical Specification. Freescale™ and the Freescale logo are trademarks of Freescale Semiconductor, Inc.
