UM191812
PN544 C2 User Manual
Rev. 1.2 — 2010-06-16
Document information
Info
Content
Keywords
PN544 C2, Logical Link Control Protocol, Host controller interface, Single
Wire Protocol, NFC 2
the Field
Abstract
This is a user manual for the PN544 C2 NFC IC.
The aim of the document is to describe the PN544 Firmware API enabling
you to design your NFC system.
nd
generation, SIM centered solution, Powered by
User Manual
