Installation and Operating Instructions | idOil-20
5.
Connections
Read Section General safety instructions before installation.
Make the connections when the device is de-energised.
The legends for the connection diagrams can be found in the section
following the diagrams.
5.1.
Connection diagrams
5.1.1.
Connection with a single-sensor cable connector
Figure 12. Connection with a single-sensor cable connector
14/34
DOC001600-EN-5
