DISPLAY SETUP

Monitor Setup
Screen Setup
Sweep Speeds
Select Mode
Time and Date
Display Brightness
Install/Service
Main Menu
Return to Main Menu.
100%
– 11 –
Setting up the display
Modes determine how the information is presented (what is
displayed on the screen and trends, etc.) and what the alarm
limits are. Modes are preconfigured.
The monitor starts in startup mode, which is one of your monitor
modes chosen during configuration. To change it:
1. Press the ComWheel and select Monitor Setup.
2. Select Select Mode and choose from the options.
Modifying the display temporarily
1. Press the ComWheel and select Select Mode.
In the corresponding submenu, you can modify waveform and
digit field measurements, minitrend length, and sweep speeds
or choose the split screen option.
2. To make other setup changes, like scale changes:
Return to the Main Menu and select a desired parameter.
or
Press a direct access key and select the setup menu for that
parameter.
Changes are valid until the monitor is turned off (+15 minutes) or
until you reset the case. Only the time and date are stored
permanently.
Modifying the display permanently
You can make permanent changes in the display setup. To find
out about passwords, etc., refer to the "User's Reference Manual".
