FREESTANDING BATH INSTALLATION INSTRUCTIONS

See next page for installation instructions for Sculpted Finish tubs and additional air bath instructions.
See page 9 for Clawfoot tub instructions.
1. Determine final location of tub. The tub will sit on top of the finished floor, however, the drain will
sit approximately 1/2" - 1 1/2" below the finished floor. Tubs installed on a slab foundation may
require extra effort to gain clearance for the drain.
2. Ensure location is structurally sound, flat and level. See individual specification sheets for tub
weights and water capacity.
3. Remove access panel on rear of tub. Save the screws and screw cap covers for reinstalling later.
4. Roll tub onto front face being careful not to damage the acrylic finish. Use packing blanket or other
suitable material to protect the finish of the tub. NOTE: If you ordered the Madelyn 3 (model # 136)
with a pedestal base, use extreme care when moving tub. Always lift straight up, never drag the tub
along the floor. The pedestal base is very fragile.
5. Install waste and overflow. Use clear silicone to seal. Do not use plumbers putty as it may discolor the
acrylic or drain finish over time. Plumbers putty can dry and crack, leaving open the opportunity for leaking.
COMPLETING INSTALLATION WITH ACCESS FROM BELOW (RECOMMENDED METHOD)
6. Apply a 3/8" bead of construction adhesive or clear silicone to the bottom of the tub to adhere it to
the floor and carefully lower the tub so the drain drops through the floor. The size of the cutout in
the floor must allow for the entire drain to clear.
7. Use care not to allow silicone to get on the outside wall of the tub or surrounding floor area. Wipe
any excess immediately with a soft, damp cloth.
8. From below, connect the drain to the P-trap.
9. Re-install the access panel using the screws and screw caps saved from step 3.
10. Water test to ensure bath is leak free. Allow 24 hours before use.
COMPLETING INSTALLATION WITHOUT ACCESS FROM BELOW
6. Use two 2x4s to elevate the tub above the floor and align the drain with the P-trap. DO NOT LET
THE TUB REST ON THE DRAIN PLUMBING.
7. Apply a 3/8" bead of clear silicone to the underside of the tub to adhere it to the floor. Use care
not to allow silicone to get on the outside wall of the tub or surrounding floor area. Wipe any
excess immediately with a soft, damp cloth.
8. Carefully remove the 2x4 supports and lower the tub so the drain drops into the P-trap adapter. Secure
the adapter and re-install the access cover using the screws and screw covers saved from step 3.
9. Water test to ensure bath is leak free. Allow 24 hours before use.
SCULPTED FINISH INSTALLATION INSTRUCTIONS
1. Secure tub to the floor using a 3/8" bead of clear silicone around the outer perimeter of the bath.
Use care not to allow silicone to get on the outside wall of the tub or surrounding floor area. Wipe
any excess immediately with a soft, damp cloth.
2. If desired, additional construction adhesive may be used under the foam base to adhere the tub to the floor.
3. Install the drain, using clear silicone to seal. Do not use plumbers putty as it may discolor the acrylic or
drain finish over time. Plumbers putty can dry and crack, leaving open the opportunity for leaking.
4. Water test to ensure bath is leak free. Allow 24 hours before use.
NOTE: Please read care & cleaning instructions on page 14.
