MTI DESIGNER COLLECTION Installation And Operation Manual page 16

FUNCTIONS
ON/OFF FOR RADIANCE SYSTEM:1
2nd Press: Turns off Radiance system. Light will be off.
ON/OFF FOR AIR SYSTEM
1st Press: The blower turns on at 30% power. Use the up and down arrows to increase or decrease
the speed. Please note: 20% is the minimum. If the lights for the up & down arrows go off, they can
be reactivated by gently pressing the on/off button
2nd Press: The blower turns off.
PULSATION MODE
1st Press: Standard wave. Speed will vary gradually from minimum to maximum.
2nd Press: Standard pulse. Speed will go quickly, alternating from minimum to maximum.
3rd Press: Blower returns to maximum speed.
4th Press: Returns to pulsation mode.
ON/OFF FOR LED LIGHTS
1st Press: Turns lights on to basic color mode, starting with white. Use the up and down arrows to
move light through the basic colors.
2nd Press: Slow rainbow cycle - Use up and down arrows to increase or decrease the speed of the cycle.
3rd Press: Slow aqua-blue-green cycle. Use the up and down arrows to increase or decrease the
speed of the cylcle.
Press and hold light button at any time to turn light off.
AUTOMATICALLY STOPS AFTER 20 MINUTES
NOTE: The air blower will turn on by itself approximately 7 minutes after tub is completely drained.
See below for more information.
AUTOMATIC PURGE / DRYING CYCLE FOR AIR SYSTEMS
Each MTI air system is equipped with sensors on the floor of the bath near the drain. Every time water is
introduced to the bath and drained, either by showering, bathing or cleaning or the air bath is activated, the
sensors will activate the purge/drying cycle. The cycle will start approximately 7 minutes after the bath is
drained and run for 1-2 minutes. The purge cycle will activate even when the air bath has not been turned
on. To cancel the purge, simply press the on/off button for the air system. This will delay the purge for 7
minutes. Pressing the on/off button to delay the purge a second time will cancel the purge until the next
use.
24 hour purge cycle option - If desired, the purge cycle may be set to activate once every 24 hours at the
time the cycle is first activated (for example, if you activate the purge cycle at 10:00 am, the bath will purge
each day at 10:00 am).
Activate by pressing the "+" button or "up" arrow on the keypad for 5 seconds. To deactivate, simply press
the button again for 5 seconds and the normal purge cycle will resume.
Manual stop: if the blower button is pressed during the 1 minute drying cycle, the cycle will stop and will
restart 24 hours later at the programmed time.
In the event of a power failure, the program will be automatically deactivated.
In case there is water in the tub when the 24 hour purge is supposed to start, the purge will not come on
and disturb the bather. 7 minutes after water has drained, the normal purge will begin. After the purge cycle,
the system reverts back to 24 hour purge.
# 4 AIR SYSTEM WITH LED LIGHT
AND RADIANCE
R4
st Press: Turns on both heated zones. Light on keypad will be on.
