OPERATING INSTRUCTIONS - KEYPAD & TUB CONTROL
FUNCTIONS FOR AIR BATHS
Keypads and functions will vary depending on specific model and/or options purchased. Use the photos on
the following pages to locate your keypad and simply follow the step by step instructions.
FUNCTIONS
ON/OFF:
1st Press: The blower starts. LED light on. 2nd Press: The blower stops. LED light off.
BLOWER SPEED INCREASE
Press & hold to increase the blower speed. Release pressure at the desired speed.
Note: The blower initially starts at half speed.
BLOWER SPEED DECREASE
Press & hold to decrease the blower speed. Release pressure at the desired speed.
PULSATION MODES
1st Press: Wave - Speed will vary gradually from maximum to minimum. LED light on.
2nd Press: Pulse - Speed will go directly to minimum and then straight back to maximum. LED light will flash.
3rd Press: Returns to maximum speed. LED light off. Press button #3 to decrease blower speed.
AUTOMATICALLY STOPS AFTER 20 MINUTES
NOTE: Blower will automatically turn on approx. 7 minutes after tub is completely drained. See p. 13 for more information.
FUNCTIONS
ON/OFF FOR RADIANCE SYSTEM:1
2nd Press: Turns off Radiance system. Light will be off.
ON/OFF:
1st Press: The blower starts. LED light on. 2nd Press: The blower stops. LED light off.
BLOWER SPEED INCREASE
Press & hold to increase the blower speed. Release pressure at the desired speed.
Note: The blower initially starts at half speed.
BLOWER SPEED DECREASE
Press & hold to decrease the blower speed. Release pressure at the desired speed.
PULSATION MODES
1st Press: Wave - Speed will vary gradually from maximum to minimum. LED light on.
2nd Press: Pulse - Speed will go directly to minimum and then straight back to maximum. LED light will flash.
3rd Press: Returns to maximum speed. LED light off. Press button #3 to decrease blower speed.
AUTOMATICALLY STOPS AFTER 20 MINUTES
NOTE: Blower will automatically turn on approx. 7 minutes after tub is completely drained. See p. 13 for more information.
#1 STANDARD AIR SYSTEM
#1 STANDARD AIR SYSTEM
WITH RADIANCE
R1
st Press: Turns on both heated zones. Light on keypad will be on.
11
