Syntax
SET CABLE PLAN {standard |HRC | IRC}
You can set the cable plan (Standard, HRC or IRC) to be used. For best results during the scan, connect
ZvBox® to the cable plant using the same coax cabling connection that you would use to connect an
HDTV.
Cable Scan
ZvBox® products contain a very powerful feature to aid the installer– a built‐in cable spectrum analyzer.
When asked, ZvBox® will stop transmitting, analyze every RF channel on the cable and report the result.
The report shows if a channel is open or occupied, and if occupied, if the channel is Analog or Digital.
Syntax
START CABLE‐SCAN
RF frequencies on the coax cabling are scanned from lowest number to highest. The scan cannot be
interrupted once started.
Example: (some results omitted to save space)
START CABLE‐SCAN
Determining cable plan
RF 2: Open
RF 3: Digital
RF 4: Analog
...
RF 135: Open
SCAN COMPLETED ‐ Hit NEXT
Show Last Cable Scan Results
ZvBox® remembers the results of the last cable scan performed. This command shows the results. The
first line shows the cable‐plan type that was determined (standard, HRC, or IRC).
Syntax
SHOW SCAN RESULTS
Example:
SHOW SCAN RESULTS
Hit +‐ to scroll
Cable‐plan STD
Open 2 3 4 5 6 7
Open 8 9 10 11
...
Digital 12 13 14 15
...
Analog 16 17 18 19
®
