Show Status Display Description - ZeeVee ZvBox 170 Configuration Manual

Show Status Display Description

Display Lines
Hit + ‐ to scroll Operating instructions
Transmitting Transmitting status:
V‐in Video input:
V‐out Video output:
A‐in Audio input:
A‐out Audio output:
SN Shows serial number of ZvBox
HW Shows hardware version of ZvBox
SW Shows firmware version of ZvBox
Temp Temperature status
Up Uptime = shows how long ZvBox has been running since power on or reboot
CC Closed captioning adaptor status:
®
ZvBox 170 Configuration Manual
www.zeevee.com Rev 1.0
Descriptions of Possible Status Readouts
•
Transmitting = broadcasting normally
•
RF‐power off = RF output power has been turned off
•
Scanning cable = Currently scanning for open and occupied channels
•
Channel conflict = Set to broadcast on an occupied RF channel
•
Not cfg = No video source detected
•
Test‐image 1 = showing internally generated test image 1
•
Test‐image 2 = showing internally generated test image 2
•
1280 x 720 (or other resolution) = resolution of input source
•
Undetected = no incoming video detected
•
Unsupported = unsupported video resolution from input source
•
Power off = RF output is turned off
•
720p (or other resolution) = video resolution currently output from ZvBox
•
Not cfg = No audio source detected (or no video source detected)
•
PCM = audio source is USB, and/or audio input is PCM
•
Undetected = no audio source detected
•
AC3 = audio input is AC3 format
•
DTS = audio input is DTS format, this is not supported
•
Unknown = unknown audio format
•
Power off = RF output is turned off
•
AC3 = an audio source is detected, ZvBox is outputting AC3 audio
•
No output = either no input detected, or unknown audio format from input
source
•
Okay = normal operating temperature
•
Warning = Hotter than normal operating temperature
•
Critical = Unit about to shut down automatically
•
Connected = ZVCC closed captioning adapter connected
•
Not connected = no ZVCC closed captioning adapter connected
