SETUP AND MOVING

1.4 MAINTENANCE

REGULAR MAINTENANCE - (MONTHLY/500
GAMES)
• Remove the playfield glass
• Enter the software diagnostics menu, start lamp test, then
clean and wax the playfield.
• While cleaning the playfield, identify and repair malfunction-
ing lights, loose parts, cracked plastics and worn rubber
parts.
• While in diagnostics, enter the switch test (Select the "SW"
Icon, then "TEST" Icon).
• Use a pinball to actuate all switches and verify the correct
switch registers with the switch test.
• The game will play a sound to confirm the switch.
• Lift the playfield and inspect all assemblies for loose parts,
broken wires or excessive wear. Look at the bottom of the
cabinet for any parts that may have worked loose, then find
the source.
• Check all coin door mechanisms and bill acceptor (if in-
stalled) for proper operation
• Play the game to ensure all coils and features are working
• Check the playfield to ensure it is level and set to the prop-
er pitch using the bubble level on the right side wood rail.
• Check game audits: Replay % and Ball Time and note
abnormal values which can indicate problems.
• Ensure game volume is set appropriately for the location.
• Clean both sides of the playfield glass and reinstall.
• Check and clean pinballs and replace if excessively worn or
scuffed. Dirty pinballs accelerate game wear.
OVERHAUL MAINTENANCE - (5000 GAMES)
• Verify latest game software is installed
• Check flippers for excessive wear. Excessive flipper sloppi-
ness (vertical or horizontal) or weakness indicates a flipper
rebuild is required.
• Clean machine inside and out and check leg levelers for
free operation.
• Visual check for loose or broken playfield and cabinet parts
and repair as necessary.
• Electrical check: Plug into grounded outlet and check for
proper operation through DIAGNOSTICS.
• Replace worn or dirty rubbers.
• Replace pinballs.
• Check all playfield switches with a pinball.
• Check all settings (refer to manual for factory settings).
• Check coin door: With door closed, insert coins to verify
proper operation.
• Check for proper adjustment of the plumb bob tilt.
• Play game: Check for satisfactory operation.
8
COMMON PINBALL TOOLS
• Common nut drivers (¼", 5/16", 11/32", ⅜")
• Phillips screwdriver
• Standard Allen wrench/Hex key set
• ⅝" Socket with ratchet
• Adjustable wrench (5/8" & 9/16")
• 6" Torpedo Level (or use a pinball
• Flashlight or headlamp
• Soldering Iron (60w with flat tip), lead-free solder
• Wire cutter
• Wire stripper
• Long nose ("needle nose") pliers

1.5 MAINTENANCE KITS

Description
Deadpool Maintenance Kit
8 oz pinball playfield wax (Novus # 2) (675-0003-01)
Standard Pinball (260-5000-00)
Cleaning Cloth
All Playfield Rubber Rings
Spare Fuses
Deadpool Deluxe Maintenance Kit
All standard kit items, plus:
Flipper rebuild kits, Left and Right (500-6307-10,-00)
Deadpool Playfield Plastics Kit
Deadpool Playfield Decals Kit
Deadpool Backbox Decal Left
Deadpool Backbox Decal Right
Deadpool Cabinet Decal Left
Deadpool Cabinet Decal Right
Deadpool Cabinet Decal Front
Deadpool Playfield, Bare
Deadpool Translite

1.6 COMMON PARTS

Description
8 oz Pinball Playfield wax (Novus # 2)
Standard Pinball, 1-1/16 in
Flipper Rebuild Kit Left (Standard)
Flipper Base Plate Kit Left
Flipper Rebuild Kit Right
Flipper Base Plate Kit Right
DEADPOOL PRO MANUAL 500-55K1-01
Part Number
502-6002-K1
502-6003-K1
803-5000-K1
802-5000-K1
820-78K1-01
820-78K1-02
820-78K1-03
820-78K1-04
820-78K1-05
830-5100-K1
830-52K1-00
Part Number
675-0003-01
260-5000-00
500-6307-10
515-6617-01
500-6307-00
515-6617-00
