PARTS REFERENCE

5.4 PLAYFIELD ASSEMBLIES, BOTTOM

1
8
2
1
4
5
6
7
Figure 5.4.1. Major playfield assemblies, Bottom locations.
36
ID Part Number
1 520-7017-72
2 520-8045-00
3 520-8047-00
4 520-8046-00
5 520-8048-00
6 500-5329-03
7 535-5988-01
8 535-6862-05
8
3
6
7
DEADPOOL PRO MANUAL 500-55K1-01
Description
Core-Driver Node Board
LED Lower Board
LED Right Board
LED Left Board
LED Upper Board
Pivot Pin
Edge Slide Bracket
Rail
MARVEL.COM
© MARVEL
Qty
2
1
1
1
1
2
2
2
