4.13 KATANA BALL LOCK LED
BOARD
520-8041-00
ID Type Pin
CN1 .100" 8-Pin Header 1
2
3
4
5
6
7
8

4.14 3-BANK LED BOARD

520-7092-00
ID Type Pin
CN1 .100" 4-Pin Header 1
2
3
4
MARVEL.COM
© MARVEL
Description Wire Color
+5 VDC RED
LED 1 GRN-BRN
LED 2 GRN-RED
LED 3 GRN-ORG
LED 4 GRN-YEL
LED 5 GRN
LED 6 GRN-BLU
LED 7 GRN-VIO
Description Wire Color
+5 VDC RED
LED 1 BLU-VIO
LED 2 BLU-GRY
LED 3 BLU-WHT
DEADPOOL PRO MANUAL 500-55K1-01
ELECTRONIC PINOUTS AND SCHEMATICS

4.15 MAIN POWER SUPPLY

011-5003-00
LED
+V ADJ.
9
8
7
6
5
4
3
2
1
ID Type Pin Description
CN1 Screw Terminal 1 AC Line Hot In
2 AC Line Neutral In
3 Earth Ground In
4 DC Ground
5 DC Ground
6 DC Ground
7 +48 V System Power
8 +48 V System Power
9 +48 V System Power
Wire Color
BLK
WHT
GRN
BLK
BLK
BLK
GRY
GRY
GRY
