ELECTRONIC PINOUTS AND SCHEMATICS

4.10 RIGHT LED BOARD 9B

520-8048-00
ID Type Pin
CN1 .100" 8-Pin Header 1
2
3
4
5
6
7
8
CN2 .100" 7-Pin Header 1
2
3
4
5
6
7
CN3 .100" 9-Pin Header 1
2
3
4
5
6
7
8
9
CN4 .100" 6-Pin Header 1
2
3
4
5
6
30
Description Wire Color
+5 VDC RED
+5 VDC RED
LP-6 Light Return BRN-RED
LP-7 Light Return BRN-BLK
LP-8 Light Return BRN
LP-9 Light Return BRN-ORG
LP-10 Light Return BRN-YEL
LP-11 Light Return -
Ground BLK
MISO Output Data VIO-BLK
MOSI Input Data VIO-BRN
SCK Serial Clock VIO-RED
RCK Register Clock VIO-ORG
n/c -
+5 VDC IN RED
+5 VDC RED
+5 VDC RED
+5 VDC RED
LP-14 Light Return ORG-VIO
LP-15 Light Return ORG-GRY
LP-16 Light Return RED-YEL
LP-17 Light Return GRN-YEL
LP-18 Light Return BLU-YEL
LP-19 Light Return ORG-WHT
Ground -
MISO Output Data -
MOSI Input Data -
SCK Serial Clock -
RCK Register Clock -
V+ -
DEADPOOL PRO MANUAL 500-55K1-01

4.11 BALL LOCK OPTO RECEIVER

520-7064-00
ID Type Pin
CN1 .100" 6-Pin Header 1
2
3
4
5
6

4.12 BALL LOCK OPTO EMITTER

520-7065-00
ID Type Pin
CN1 .100" 3-Pin Header 1
2
3
Description Wire Color
Ground BLK-GRY
MISO Output Data TAN-WHT
MOSI Input Data TAN-VIO
SCK Serial Clock TAN-BLU
RCK Register Clock TAN-GRN
+5 VDC IN RED
Description Wire Color
Ground BLK-GRY
N/C -
+5 VDC IN RED
