5
Check Tape
A
A: Press FEED button to dispense one piece
of tape and ensure tape is loaded correctly
6
Clean Brushes
A: Remove brushes and wash with clean,
warm water.
B: Replace brushes. Brushes must be angled
toward the front of the dispenser.
7
Fill Water Tank
A: Fill water tank with clean water
B: To avoid spilling, place finger over fill hole
when returning full water tank to its holder
8
Dispense Tape
A
A: Press desired tape length button
Need more help? Download the full manual or contact us
TDH
A
B
LD5000
A
4270 Airborn Dr. Addison, TX 75001, USA
972.248.1999 | tech@startinternational.com
s t a r t i n t e r n a t i o n a l . c o m
O5
2
®
Q9.4
Advertisement
Table of Contents
Related Manuals for START International Tape TDH2O5
Summary of Contents for START International Tape TDH2O5
- Page 1 Q9.4 Fill Water Tank Check Tape ® A: Fill water tank with clean water A: Press FEED button to dispense one piece B: To avoid spilling, place finger over fill hole of tape and ensure tape is loaded correctly when returning full water tank to its holder LD5000 Dispense Tape Clean Brushes...
- Page 2 Electric Feed Tape Adjust Guides FRONT Gummed “Water Activated” BACK Tape Dispenser ITEMS INCLUDED A: Raise front cover and continue feeding A: Open rear cover tape under the upper tape plate B: Adjust reel guides to fit the tape roll B: Close cover all the way down Plug In + Power On Insert Tape...
