Load Dispenser
A: Feed label liner under
guide rod and brush
B: Bend liner around
strip plate
(label will hang
slightly over edge for lifting)
C: Slide lock rod back onto
take-up hub to secure liner
5
Point sensor toward
Adjust Sensor
edge of label.
A
C
A: Loosen wingscrew to adjust sensor plate
B: Point sensor towards edge of label
C: Tighten wingscrew to secure in place
A
B
6
Plug In and Turn On
A
B
A: Assemble power source (2 pieces)
B: Connect A/C power (in back) and to
wall outlet
C: Press power switch (on front) to turn on
Need more help? Download the full manual or contact us
C
B
C
LD2000
®
LD5000
4270 Airborn Dr. Addison, TX 75001, USA
972.248.1999 | tech@startinternational.com
s t a r t i n t e r n a t i o n a l . c o m
Q9.4
Advertisement
Table of Contents
Related Manuals for START International Label LD2000
Summary of Contents for START International Label LD2000
- Page 1 Q9.4 LD2000 Load Dispenser ® A: Feed label liner under guide rod and brush B: Bend liner around strip plate (label will hang slightly over edge for lifting) C: Slide lock rod back onto take-up hub to secure liner LD5000 Point sensor toward Adjust Sensor Plug In and Turn On...
- Page 2 LD2000 Electric Label Dispenser Load Label Roll Reel Guide ITEMS INCLUDED A: Insert core holders into each side A: Slide reel guide onto reel hanger of your label roll bar to secure your label roll B: Slide loaded roll onto the reel hanger bar Dispenser Remove Lock Rod Core Holders (2)
