LD2000
Electric Label Dispenser
ITEMS INCLUDED
Dispenser
Core Holders (2)
Reel Guide (1)
Power Bar and Cord (2 Pieces)
1
Load Label Roll
A: Insert core holders
into each side
(2)
of your label roll
B: Slide loaded roll onto the reel hanger bar
3
Remove Lock Rod
A: Slide lock rod off of take-up hub
2
Reel Guide
A
A
B
A: Slide reel guide onto reel hanger
bar to secure your label roll
A
Advertisement
Table of Contents
Related Manuals for START International THE LABEL DISPENSER LD2000
Summary of Contents for START International THE LABEL DISPENSER LD2000
- Page 1 LD2000 Electric Label Dispenser Load Label Roll Reel Guide ITEMS INCLUDED A: Insert core holders into each side A: Slide reel guide onto reel hanger of your label roll bar to secure your label roll B: Slide loaded roll onto the reel hanger bar Dispenser Remove Lock Rod Core Holders (2)
- Page 2 Q8.2 LD2000 Load Dispenser A: Feed label liner under guide rod and brush B: Bend liner around strip plate (label will hang slightly over edge for lifting) C: Slide lock rod back onto take-up hub to secure liner LD5000 Point sensor toward Adjust Sensor Plug In and Turn On edge of label.
