Aaeon COM-690T Manual

Com express module. amd turion/ sempron (s1 socket) processors up to 24-bit dual-channel lvds two ddrii 667/ 800 sodimm high definition audio
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
C O M E x p r e s s M o d u l e
C O M - 6 9 0 T / C O M - 6 9 0 E
COM-690T/ COM-690E
AMD Turion/ Sempron
(S1 Socket) Processors
Up to 24-bit Dual-channel LVDS
Two DDRII 667/ 800 SODIMM
High Definition Audio
COM-690T/ COM-690E Manual Rev.A 2nd Ed.
November 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COM-690T and is the answer not in the manual?

Questions and answers

Related Manuals for Aaeon COM-690T

Summary of Contents for Aaeon COM-690T

  • Page 1 C O M - 6 9 0 T / C O M - 6 9 0 E COM-690T/ COM-690E AMD Turion/ Sempron (S1 Socket) Processors Up to 24-bit Dual-channel LVDS Two DDRII 667/ 800 SODIMM High Definition Audio COM-690T/ COM-690E Manual Rev.A 2nd Ed. November 2008...
  • Page 2 AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
  • Page 3 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Acknowledgments All other products’ name or trademarks are properties of their respective owners.
  • Page 4 Packing List Before you begin installing your card, please make sure that the following materials have been shipped: • 1 COM-690T or COM-690E CPU module • 1 CD-ROM for manual (in PDF format) and drivers • 5 M2.5 x 4mm screws If any of these items should be missing or damaged, please contact your distributor or sales representative immediately.
  • Page 5 APM mode due to the chipset limitation. So, if you use the AT power input, COM-690T/ COM-690E will run ACPI mode only. (AAEON uses a H/W method to emulate AT power input as ATX power input in Windows OS.) 2.

  • Page 6: Table Of Contents

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Contents Chapter 1 General Information 1.1 Introduction..............1-2 1.2 Features ..............
  • Page 7 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E A.4 F7511 Watchdog Timer Initial Program ....A-5 Appendix B I/O Information B.1 I/O Address Map ............B-2 B.2 Memory Address Map..........B-3...

  • Page 8: Chapter 1 General Information

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Chapter General Information 1- 1 Chapter 1 General Information...

  • Page 9: Introduction

    1.1 Introduction To accommodate fast growing marketing segments, AAEON has developed a brand new COM (Computer-on-module) Express CPU Module. The COM-690T/ COM-690E, and its accompanying carrier board-ECB-916M, adopts AMD Turion/ Sempron (S1 socket) processor and AMD M690T/E + SB600 chipset, offering high speed PCI-Express bus interface and serial ATA for your high performance applications requiring high-speed and greater stability.

  • Page 10: Features

    AMD Turion/ Sempron (S1 Socket) Processors AMD M690T/E + SB600 Chipset Non-ECC Dual-channel DDRII 667/800 Memory, Up To 4GB CRT/ Up to 24-bit Dual-channel LVDS LCD/ TV (COM-690T) Gigabit Ethernet High Definition Audio Interface Wide DC Input Range, +8.5V DC to +19V DC...

  • Page 11: Specifications

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E 1.3 Specifications System AMD Turion/ Sempron (S1 Socket) Processors System Memory DDRII SODIMM x 2, supports...
  • Page 12 32-bit XP Pro/ Windows 64-bit XP Pro/ Windows XP Embedded/ WinCE 6.0/ Linux: 2.4 and 2.6 kernel Display: Supports LCD/CRT, LCD/DVI, CRT/DVI (LCD/TV, TV/DVI: COM-690T only) Simultaneous/ Dual View Displays Chipset AMD M690T/E integrated System Memory Shared system memory (no...
  • Page 13 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E HDTV supports: 480i/ 480p/ 576i/ 576p/ 720p/ 1080i; Supports Composite Video, S-Video and Component Video (YPbPr) on carrier board...

  • Page 14: Chapter 2 Quick Installation Guide

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Chapter Quick Installation Guide Chapter 2 Quick Installation Guide...

  • Page 15: Safety Precautions

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E 2.1 Safety Precautions Always completely disconnect the power cord from your board whenever you are working on it.

  • Page 16: Drawings

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E 2.2 Location of Connectors/ Jumpers & Mechanical Drawings Component Side 2 - 3 Chapter 2 Quick Installation Guide...
  • Page 17 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Solder Side 2 - 4 Chapter 2 Quick Installation Guide...

  • Page 18: List Of Connectors

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E 2.3 List of Connectors There are a number of connectors in the board that allow you to configure your system to suit your application.
  • Page 19 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E 2.5 COM Express A/B Port Connector (J3) Row A Row B GND (FIXED)
  • Page 20 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E SATA2_TX+ SATA3_TX+ SATA2_TX- SATA3_TX- SUS_S5# PWR_OK SATA2_RX+ SATA3_RX+ SATA2_RX- SATA3_RX-...
  • Page 21 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E USB0+ USB1+ VCC_RTC EXCD1_PERST# EXCD0_PERST# EXCD1_CPPE# EXCD0_CPPE# SYS_RESET# LPC_SERIRQ CB_RESET#...
  • Page 22 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E GND (FIXED) GND (FIXED) LVDS_A0+ LVDS_B0+ LVDS_A0- LVDS_B0- LVDS_A1+ LVDS_B1+...

  • Page 23: Com Express C/D Port Connector (J4)

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E RSVD VGA_VSYNC RSVD VGA_I2C_CK VGA_I2C_DAT VCC_12V TV_DAC_A VCC_12V TV_DAC_B VCC_12V...
  • Page 24 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E IDE_D15 IDE_D12 IDE_D8 IDE_D4 IDE_D9 IDE_D0 IDE_D2 IDE_REQ IDE_D13 IDE_IOW#...
  • Page 25 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E PCI_AD10 PCI_AD13 PCI_AD12 PCI_AD15 GND (FIXED) GND (FIXED) PCI_AD14 PCI_PAR PCI_C/BE1#...
  • Page 26 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E PEG_RX0- PEG_TX0- TYPE0# PEG_LANE_RV# PEG_RX1+ PEG_TX1+ PEG_RX1- PEG_TX1- TYPE1# TYPE2#...
  • Page 27 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E RSVD IDE_CBLID# N.C. N.C. N.C. N.C. GND (FIXED) GND (FIXED) N.C.
  • Page 28 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E C101 N.C. D101 N.C. C102 N.C. D102 N.C.
  • Page 29 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅...
  • Page 30 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Chapter Award BIOS Setup Chapter 3 Award BIOS Setup 3-1...
  • Page 31 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E 3.1 System Test and Initialization These routines test and initialize board hardware. If the routines encounter an error during the tests, you will either hear a few short beeps or see an error message on the screen.

  • Page 32: Chapter 3 Award Bios Setup

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E 3.2 Award BIOS Setup Awards BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration.

  • Page 33: Award Bios Setup

    Save CMOS value changes to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup. You can refer to the "AAEON BIOS Item Description.pdf" file in the CD for the meaning of each setting in this chapter. Chapter 3 Award BIOS Setup 3-4...

  • Page 34: Chapter 4 Driver Installation

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Chapter Driver Installation 4 -1 Chapter 4 Driver Installation...
  • Page 35 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E The COM-690T/ COM-690E comes with an AutoRun CD-ROM that contains all drivers and utilities that can help you to install the driver automatically.
  • Page 36 C O M - 6 9 0 T / C O M - 6 9 0 E 4.1 Installation: Insert the COM-690T/ COM-690E CD-ROM into the CD-ROM drive. And install the drivers from Step 1 to Step 7 in order.
  • Page 37 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Step 3 –Install ATI HDMI Audio Device 1.
  • Page 38 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E 3264-Bit RAID Driver in terms of the operating system to floppy root directory 2.

  • Page 39: Appendix A Programming The Watchdog Timer

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Appendix Programming the Watchdog Timer Appendix A Programming the Watchdog Timer A-1...

  • Page 40: General Information

    C O M - 6 9 0 T / C O M - 6 9 0 E A.1 General Information The COM-690T/COM-690E utilizes Fintek F75111 chipset as its watchdog timer Controller. The other Watchdog timer is set to second or minute and the range is 0 to 256 seconds or minutes.

  • Page 41: Registers Description

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E A.3 Registers Description Configuration and Control Register – Index 01h Power-on default [7:0] =0000_1000b Name Description...
  • Page 42 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E WDTOUT10# output level inverting. WDTOUT10_OINV When write 1, the output pin will be inverted.

  • Page 43: F7511 Watchdog Timer Initial Program

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E A.4 F75111 Watchdog Timer Initial Program . .MODEL SMALL .CODE Main: push cx...
  • Page 44 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E push ax push cx dx,SMBus_Port +04h ;SMBus_Port(0B00h) al,ch ;ID cmd(Write) dx,al...
  • Page 45 C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E call Delay5ms cx, 100h newiodelay loop short @B Ct_I2CWriteByte Endp CALL Check_Chip Appendix A Programming the Watchdog Timer A-7...

  • Page 46: Appendix B I/O Information

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E Appendix I/O Information Appendix B I/O Information B-1...

  • Page 47: I/O Address Map

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E B.1 I/O Address Map Appendix B I/O Information B-2...

  • Page 48: Memory Address Map

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E B.2 Memory Address Map Appendix B I/O Information B-3...

  • Page 49: Irq Mapping Chart

    C O M E x p r e s s M o d u l e C O M - 6 9 0 T / C O M - 6 9 0 E B.3 IRQ Mapping Chart B.4 DMA Channel Assignments Appendix B I/O Information B-4...
