  • Page 1 BOXER-6639 Fanless Embedded Box PC User’s Manual 1 Last Updated: November 1, 2016...
  • Page 2 AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
  • Page 3 Acknowledgement All other products’ name or trademarks are properties of their respective owners. Microsoft Windows ® is a registered trademark of Microsoft Corp.  Intel ® , Platium ® , Celeron ® , and Xeon ® are registered trademarks of Intel ...
  • Page 4 Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity BOXER-6639  Wallmount bracket  Screw Package  Thermal Pad  Phoenix power connector  Product DVD with User’s Manual (in pdf) and drivers ...
  • Page 5 (if any), its specifications, dimensions, jumper/connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the AAEON.com for the latest version of this document. Preface...
  • Page 6 Safety Precautions Please read the following safety instructions carefully. It is advised that you keep this manual for future references All cautions and warnings on the device should be noted. Make sure the power source matches the power rating of the device. Position the power cord so that people cannot step on it.
  • Page 7 Do NOT disassemble the motherboard so as not to damage the system or void your warranty. If the thermal pad had been damaged, please contact AAEON's salesperson to purchase a new one. Do NOT use those of other brands. The Hex Cylinder Coppers on the front panel are not removable.
  • Page 8 FCC Statement This device complies with Part 15 FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received including interference that may cause undesired operation. Caution: There is a danger of explosion if the battery is incorrectly replaced.
  • Page 9 China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 AAEON Embedded Box PC/ Industrial System 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 ○ ○ ○ ○ ○ ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○...
  • Page 10 China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products AAEON Embedded Box PC/ Industrial System Poisonous or Hazardous Substances or Elements Hexavalent Polybrominated Polybrominated Component Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &...

  • Page 11: Table Of Contents

    Table of Contents Chapter 1 - Product Specifications ..................1 Specifications ......................2 Chapter 2 – Hardware Information ..................4 Dimensions ......................5 Jumpers and Connectors ..................7 List of Jumpers ...................... 10 2.3.1 Auto Power Button (JP19) ..............10 2.3.2 Clear CMOS Jumper (JP24) ..............
  • Page 12 AMI BIOS Setup ....................27 Setup Submenu: Main ..................28 Setup Submenu: Advanced ................29 3.4.1 Advanced: CPU Configuration ............30 3.4.2 Advanced: SATA Configuration ............31 3.4.3 Advanced: PCH-FW Configuration ........... 32 3.4.4 Advanced: SIO Configuration ............34 3.4.4.1 SIO Configuration: Serial Port 1 Configuration ..... 35 3.4.4.2 SIO Configuration: Serial Port 2 Configuration .....
  • Page 13 Watchdog Timer Initial Program ............... 64 Appendix C - I/O Information ....................66 I/O Address Map ....................67 Memory Address Map ..................69 IRQ Mapping Chart ..................... 71 Appendix C - Digital I/O Information ................. 81 DIO Programming ....................82 DIO Register ......................

  • Page 14: Chapter 1 - Product Specifications

    Chapter 1 Chapter 1 - Product Specifications...

  • Page 15: Specifications

    Specifications System Intel® Core™ i7-6700TE, 2.4 GHz Processor  Intel® Core™ i5-6500TE, 2.3 GHz Intel® Core™ i3-6100TE, 2.7 GHz DDR4 1866/2133 SODIMM slot x 2, up to 32 System Memory  GB, ECC or Non-ECC support VGA x 1 Display ...
  • Page 16 DIN rail (optional) 264 mm x 62 mm x 154 mm (10.4” x 2.4” x 6.1”) Dimension (W x H x D)  Gross Weight  3.5 kg (7.7 lb) Net Weight  3.0 kg (6.6 lb) Environmental Ambient with Airflow Operating Temperature ...

  • Page 17: Chapter 2 - Hardware Information

    Chapter 2 Chapter 2 – Hardware Information...

  • Page 18: Dimensions

    Dimensions Chapter 2 – Hardware Information...
  • Page 19 Chapter 2 – Hardware Information...

  • Page 20: Jumpers And Connectors

    Jumpers and Connectors Component Side Chapter 2 – Hardware Information...
  • Page 21 Solder Side Chapter 2 – Hardware Information...
  • Page 22 Chapter 2 – Hardware Information...

  • Page 23: List Of Jumpers

    List of Jumpers Please refer to the table below for all of the system’s jumpers that you can configure for your application Label Function RS-232/ 422/ 485 selection for COM1 port RS-232/ 422/ 485 selection for COM6 port RS-232/ 422/ 485 selection for COM4 port RS-232/ 422/ 485 selection for COM3 port JP17 RS-232/ 422/ 485 selection for COM2 port...

  • Page 24: List Of Connectors

    List of Connectors Please refer to the table below for all of the system’s connectors that you can configure for your application Label Function DB-15 CRT port DC-IN 9~36V DC-IN connector HDMI1 HDMI connector HDMI2 HDMI connector 8- bit Digital Input & Output connector USB 3.0 Port 1~4 USB 3.0 Port USB 2.0 Port 1~2...

  • Page 25: Vga Port

    2.4.1 VGA Port Signal Signal Green Blue VGA_VCC DDC_DATA VGA_HSYNC VGA_VSYNC DDC_CLK 2.4.2 DC-IN Signal Signal PWR_IN 2.4.3 HDMI Port (HDMI1/HDMI2) Signal Signal HDMI_DATA2_P HDMI_DATA2_N HDMI_DATA1_P HDMI_DATA1_N HDMI_DATA0_P HDMI_DATA0_N HDMI_CLK_P Chapter 2 – Hardware Information...

  • Page 26: Dio Port

    Signal Signal HDMI_CLK_N HDMI_SCL HDMI_SDA HDMI_PWR HDMI_HDP 2.4.4 DIO Port Signal Signal DIO1 DIO2 DIO3 DIO4 DIO5 DIO6 DIO7 DIO8 DIO9 DIO10 DIO11 DIO12 DIO13 DIO14 DIO15 DIO16 DIO17 DIO18 DIO19 DIO20 DIO21 DIO22 DIO23 DIO24 DIO25 DIO26 Chapter 2 – Hardware Information...

  • Page 27: Lan + Usb 3.0

    DIO27 DIO28 DIO29 DIO30 DIO31 DIO32 DIO33 DIO34 +3.3V +3.3V +3.3V 2.4.5 LAN + USB 3.0 Signal Signal MDI0- MDI0+ MDI1+ MDI2+ MDI2- MDI1- MDI3+ MDI3- VBUS_1 VBUS_2 Chapter 2 – Hardware Information...

  • Page 28: Remote Power Button

    Signal Signal (A)D- (B)D- (A)D+ (B)D+ (A)SSRX- (B)SSRX- (A)SSRX+ (B)SSRX+ (A)SSTX- (B)SSTX- (A)SSTX+ (B)SSTX+ 2.4.6 Remote Power Button Signal Signal PANSWH# 2.4.7 CFast Signal Signal Chapter 2 – Hardware Information...

  • Page 29: Sata Power Connector 1~2

    Signal Signal +3.3V +3.3V 2.4.8 SATA Power Connector 1~2 Pin Name level +12V 2.4.9 SATA Signal Connector 1~2 Pin 1 Pin 7 Pin name Signal Type Signal Level SATA_TX+ DIFF SATA_TX- DIFF SATA_RX- DIFF SATA_RX+ DIFF Chapter 2 – Hardware Information...

  • Page 30: Com 1/2/3/4/5/6

    2.4.10 COM 1/2/3/4/5/6 RS-232 RS-422 RS-485 DATA- DATA+ 2.4.11 Mini Card Connector with Onboard SIM Signal Signal PCIE_WAKE# +V3.3A +1.5V PCIE_CLK_REQ# UIM_PWR UIM_DATA PCIE_REF_CLK- UIM_CLK PCIE_REF_CLK+ UIM_RST UIM_VPP Chapter 2 – Hardware Information...
  • Page 31 W_DISABLE# PCIE_RST# PCIE_RX- +V3.3A PCIE_RX+ +1.5V SMB_CLK PCIE_TX- SMB_DATA PCIE_TX+ USB_D- USB_D+ +V3.3A +V3.3A +1.5V +V3.3A Chapter 2 – Hardware Information...

  • Page 32: Cpu Installation

    CPU Installation Turn off the system, unplug the power cord and make sure the system is off.  Have Intel SkyLake-S FCLGA1151 Processor (Max. TDP 35W) ready.  Step 1: Remove the screws as instructed below and remove the heatsink. Chapter 2 –...

  • Page 33: Thermal Pad

    Step 2: Install the CPU into the socket and place the thermal pad onto it. Step 3: Place the heatsink back on and fasten the screws as instructed below. Chapter 2 – Hardware Information...

  • Page 34: Ddr4 Memory Module Installation

    DDR4 Memory Module Installation Turn off the system, unplug the power cord to make sure the system is power off.  Step 1: Turn the system upside down. Remove the screws as instructed below and the bottom cover. Step 2: Place the thermal pads onto the RAM modules as instructed below.. Chapter 2 –...
  • Page 35 Step 3: After the RAM modules are installed, put the bracket onto the RAM and secure the screws as instructed below. Chapter 2 – Hardware Information...

  • Page 36: Sata Drive Installation

    2.5” SATA Drive Installation Turn off the system, unplug the power cord to make sure the system is power off.  Step 1: Use the HDD screws provided to assemble 2.5” SATA drive with the HDD Bracket Step 2: Assemble the 2.5” HDD Driver kit with bottom case and connect the SATA signal cable and SATA power cable with the 2.5”...

  • Page 37: Power Connector Installation

    Power Connector Installation Step 1: Take out 3-pin green phoenix power connector from the accessory kit Step 2: Refer to below power pin out Chapter 2 – Hardware Information...

  • Page 38: Chapter 3 - Ami Bios Setup

    Chapter 3 Chapter 3 - AMI BIOS Setup...

  • Page 39: System Test And Initialization

    System Test and Initialization The system uses certain routines to perform testing and initialization. If an error, fatal or non-fatal, is encountered, a few short beeps or an error message will be outputted. The board can usually continue the boot up sequence with non-fatal errors. The system configuration verification routines check the current system configuration against the values stored in the CMOS memory.

  • Page 40: Ami Bios Setup

    AMI BIOS Setup The AMI BIOS ROM has a pre-installed Setup program that allows users to modify basic system configurations, which is stored in the battery-backed CMOS RAM and BIOS NVRAM so that the information is retained when the power is turned off. To enter BIOS Setup, press <Del>...

  • Page 41: Setup Submenu: Main

    Setup Submenu: Main Chapter 3 – AMI BIOS Setup...

  • Page 42: Setup Submenu: Advanced

    Setup Submenu: Advanced Chapter 3 – AMI BIOS Setup...

  • Page 43: Advanced: Cpu Configuration

    3.4.1 Advanced: CPU Configuration Options summary: Hyper-threading Disabled Enabled Optimal Default, Failsafe Default Enabled for Windows XP and Linux (OS optimized for Hyper-Threading Technology) and Disabled for other OS (OS not optimized for Hyper-Threading Technology). When Disabled only one thread per enabled core is enabled. Intel Virtualization Disabled Technology...

  • Page 44: Advanced: Sata Configuration

    3.4.2 Advanced: SATA Configuration Options summary: SATA Controller(s) Enabled Optimal Default, Failsafe Default Disabled Enable or Disable SATA Device. SATA Mode IDE Mode Selection AHCI Mode Optimal Default, Failsafe Default Determines how SATA controller(s) operate. Port 0/1/2/3 Enabled Optimal Default, Failsafe Default Disabled Enable or Disable SATA Port.

  • Page 45: Advanced: Pch-Fw Configuration

    3.4.3 Advanced: PCH-FW Configuration Chapter 3 – AMI BIOS Setup...
  • Page 46 Options summary: ME FW Image Re-Flash Enabled Disabled Optimal Default, Failsafe Default Enable or Disable ME FW Image Re-Flash function. Chapter 3 – AMI BIOS Setup...

  • Page 47: Advanced: Sio Configuration

    3.4.4 Advanced: SIO Configuration Chapter 3 – AMI BIOS Setup...

  • Page 48: Sio Configuration: Serial Port 1 Configuration

    3.4.4.1 SIO Configuration: Serial Port 1 Configuration Options summary: Use This Disabled Device Enabled Optimal Default, Failsafe Default Enable or Disable this Logical Device. Possible: Use Automatic Settings Optimal Default, Failsafe Default IO=2F8; IRQ=3; IO=3F8; IRQ=4; Allows user to change Device's Resource settings. New settings will be reflected on This Setup Page after System restarts.

  • Page 49: Sio Configuration: Serial Port 2 Configuration

    3.4.4.2 SIO Configuration: Serial Port 2 Configuration Options summary: Use This Disabled Device Enabled Optimal Default, Failsafe Default Enable or Disable this Logical Device. Possible: Use Automatic Settings Optimal Default, Failsafe Default IO=2F8; IRQ=3; IO=3F8; IRQ=4; Allows user to change Device's Resource settings. New settings will be reflected on This Setup Page after System restarts.

  • Page 50: Sio Configuration: Serial Port 3 Configuration

    3.4.4.3 SIO Configuration: Serial Port 3 Configuration Options summary: Use This Disabled Device Enabled Optimal Default, Failsafe Default Enable or Disable this Logical Device. Possible: Use Automatic Settings Optimal Default, Failsafe Default IO=2F8; IRQ=11; IO=3F8; IRQ=11; Allows user to change Device's Resource settings. New settings will be reflected on This Setup Page after System restarts.

  • Page 51: Sio Configuration: Serial Port 4 Configuration

    3.4.4.4 SIO Configuration: Serial Port 4 Configuration Options summary: Use This Disabled Device Enabled Optimal Default, Failsafe Default Enable or Disable this Logical Device. Possible: Use Automatic Settings Optimal Default, Failsafe Default IO=2F8; IRQ=11; IO=3F8; IRQ=11; Allows user to change Device's Resource settings. New settings will be reflected on This Setup Page after System restarts.

  • Page 52: Sio Configuration: Serial Port 5 Configuration

    3.4.4.5 SIO Configuration: Serial Port 5 Configuration Options summary: Use This Disabled Device Enabled Optimal Default, Failsafe Default Enable or Disable this Logical Device. Possible: Use Automatic Settings Optimal Default, Failsafe Default IO=2D0; IRQ=11; IO=2C0; IRQ=11; Allows user to change Device's Resource settings. New settings will be reflected on This Setup Page after System restarts.

  • Page 53: Sio Configuration: Serial Port 6 Configuration

    3.4.4.6 SIO Configuration: Serial Port 6 Configuration Options summary: Use This Disabled Device Enabled Optimal Default, Failsafe Default Enable or Disable this Logical Device. Possible: Use Automatic Settings Optimal Default, Failsafe Default IO=2D0; IRQ=11; IO=2C0; IRQ=11; Allows user to change Device's Resource settings. New settings will be reflected on This Setup Page after System restarts.

  • Page 54: Advanced: Hardware Monitor

    3.4.5 Advanced: Hardware Monitor Chapter 3 – AMI BIOS Setup...

  • Page 55: Advanced: Usb Configuration

    3.4.6 Advanced: USB Configuration Options summary: Legacy USB Support Enabled Optimal Default, Failsafe Default Disabled Auto Enables Legacy USB support. AUTO option disables legacy support if no USB devices are connected. DISABLE option will keep USB devices available only for EFI applications. Chapter 3 –...

  • Page 56: Advanced: Digital Io Port Configuration

    3.4.7 Advanced: Digital IO Port Configuration Chapter 3 – AMI BIOS Setup...
  • Page 57 Chapter 3 – AMI BIOS Setup...
  • Page 58 Chapter 3 – AMI BIOS Setup...
  • Page 59 Chapter 3 – AMI BIOS Setup...
  • Page 60 Options summary: DIO Type Output Optimal Default, Failsafe Default Input DIO Direction Type Setting DIO Data High Optimal Default, Failsafe Default DIO Output High/Low Setting Chapter 3 – AMI BIOS Setup...

  • Page 61: Advanced: Power Management

    3.4.8 Advanced: Power Management Options summary: Power Mode ATX Type Optimal Default, Failsafe Default AT Type Select power supply mode. AC Power Loss Last State Optimal Default, Failsafe Default Power On Power Off Select power state when power is re-applied after a power failure. Optimal Default, Failsafe Default RTC wake system Disabled...

  • Page 62: Setup Submenu: Chipset

    Setup submenu: Chipset Chapter 3 – AMI BIOS Setup...

  • Page 63: Chipset: System Agent (Sa) Configuration

    3.5.1 Chipset: System Agent (SA) Configuration Options summary: Max TOLUD Dynamic Optimal Default, Failsafe Default 1 GB 1.25 GB 1.5 GB 1.75 GB 2 GB 2.25 GB 2.5 GB 2.75 GB 3 GB 3.25 GB Maximum Value of TOLUD (Top of Low Usable DRAM)\nDynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller.\nChanging this value may cause side effect, if reserved memory is lesser than MMIO required.

  • Page 64: System Agent (Sa) Configuration: Graphics Configuration

    3.5.1.1 System Agent (SA) Configuration: Graphics Configuration Options summary: Primary Display Auto Optimal Default, Failsafe Default IGFX PCIE Primary IGFX Boot VBIOS default Optimal Default, Failsafe Default Display HDMI 1 HDMI 2 Secondary IGFX Boot Disable Optimal Default, Failsafe Default Display HDMI 1 HDMI 2...

  • Page 65: Chipset: Pch-Io Configuration

    3.5.2 Chipset: PCH-IO Configuration Options summary: HD Audio Disabled Enabled Auto Optimal Default, Failsafe Default Control Detection of the HD-Audio device.\n\nDisabled = HDA will be unconditionally disabled\n\nEnabled = HDA will be unconditionally enabled\n\nAuto = HDA will be enabled if present, disabled otherwise. Mini-Card 1 Gen Auto Optimal Default, Failsafe Default...
  • Page 66 Select PCI Express port speed PCIe x4 Gen Speed Auto Optimal Default, Failsafe Default Gen1 Gen2 Gen3 Select PCI Express port speed Chapter 3 – AMI BIOS Setup...

  • Page 67: Setup Submenu: Security

    Setup submenu: Security Change User/Administrator Password You can set a User Password once an Administrator Password is set. The password will be required during boot up, or when the user enters the Setup utility. Please Note that a User Password does not provide access to many of the features in the Setup utility. Select the password you wish to set, press Enter to open a dialog box to enter your password (you can enter no more than six letters or numbers).

  • Page 68: Setup Submenu: Boot

    Setup submenu: Boot Options summary: Quiet Boot Disabled Enabled Optimal Default, Failsafe Default Enables or disables Quiet Boot option. Launch PXE OpROM Disabled Optimal Default, Failsafe Default Enabled Controls the execution of UEFI and Legacy PXE OpROM. Chapter 3 – AMI BIOS Setup...

  • Page 69: Boot: Bbs Priorities

    3.7.1 Boot: BBS Priorities Chapter 3 – AMI BIOS Setup...

  • Page 70: Setup Submenu: Save & Exit

    Setup submenu: Save & Exit Chapter 3 – AMI BIOS Setup...

  • Page 71: Chapter 4 - Drivers Installation

    Chapter 4 Chapter 4 – Drivers Installation...

  • Page 72: Product Cd/Dvd

    Product CD/DVD The BOXER-6639 comes with a product DVD that contains all the drivers and utilities you need to setup your product. Insert the DVD and follow the steps in the autorun program to install the drivers. In case the program does not start, follow the sequence below to install the drivers.
  • Page 73 Step 4 – Install Audio Driver Open the Step4 - Audio folder and select your OS followed by the .exe file in the folder Follow the instructions Drivers will be installed automatically Step 5 – Install USB3.0 Driver Open the Step5 – USB3.0 folder and select your OS Open the .exe file in the folder Follow the instructions Drivers will be installed automatically...
  • Page 74 Step 7 – Install Serial Port Driver (Optional) For Windows 7: Change User Account Control settings to Never notify Reboot and log in as administrator Chapter 4 – iX Developer...
  • Page 75 Run patch.bat as administrator For Windows 8 and Windows 10: Open the Step 7 - Serial Port Driver (Optional) folder and select your OS Open the Setup.exe file in the folder Follow the instructions Drivers will be installed automatically Chapter 4 – iX Developer...

  • Page 76: Appendix A - Watchdog Timer Programming

    Appendix A Appendix A - Watchdog Timer Programming...

  • Page 77: Watchdog Timer Initial Program

    A.1 Watchdog Timer Initial Program Table 1 : SuperIO relative register table Default Value Note SIO MB PnP Mode Index Register Index 0x2E(Note1) 0x2E or 0x4E SIO MB PnP Mode Data Register Data 0x2F(Note2) 0x2F or 0x4F Table 2 : Watchdog relative register table Register BitNum Value...
  • Page 78 ************************************************************************************ // SuperIO relative definition (Please reference to Table 1) #define byte SIOIndex //This parameter is represented from Note1 #define byte SIOData //This parameter is represented from Note2 #define void IOWriteByte(byte IOPort, byte Value); #define byte IOReadByte(byte IOPort); // Watch Dog relative definition (Please reference to Table 2) #define byte TimerLDN //This parameter is represented from Note3 #define byte TimerReg //This parameter is represented from Note4 #define byte TimerVal // This parameter is represented from Note24...

  • Page 79: Appendix C - I/O Information

    Appendix B Appendix C - I/O Information...

  • Page 80: I/O Address Map

    I/O Address Map Appendix B – I/O Information...
  • Page 81 Appendix B – I/O Information...

  • Page 82: Memory Address Map

    Memory Address Map Appendix B – I/O Information...
  • Page 83 Appendix B – I/O Information...

  • Page 84: Irq Mapping Chart

    IRQ Mapping Chart Appendix B – I/O Information...
  • Page 85 Appendix B – I/O Information...
  • Page 86 Appendix B – I/O Information...
  • Page 87 Appendix B – I/O Information...
  • Page 88 Appendix B – I/O Information...
  • Page 89 Appendix B – I/O Information...
  • Page 90 Appendix B – I/O Information...
  • Page 91 Appendix B – I/O Information...
  • Page 92 Appendix B – I/O Information...
  • Page 93 Appendix B – I/O Information...

  • Page 94: Appendix C - Digital I/O Information

    Appendix C Appendix C - Digital I/O Information...

  • Page 95: Dio Programming

    DIO Programming BOXER-6639 utilizes FINTEK F75113 chipset as its Digital I/O controller. Below are the procedures to complete its configuration which you can develop customized program to fit your application. Appendix C – Digital I/O Information...

  • Page 96: Dio Register

    DIO Register Table 1 : SuperIO relative register table Default Value Note SIO MB PnP Mode Index Register Index 0x2E(Note1) 0x2E or 0x4E SIO MB PnP Mode Data Register Data 0x2F(Note2) 0x2F or 0x4F 0x07(Note3) Table 2 : Digital I/O relative register table Register Input Register BitNum...
  • Page 97 DIO-25 Pin 0x42 0x43 GPIO30 DIO-26 Pin 0x42 0x43 GPIO31 DIO-27 Pin 0x42 0x43 GPIO32 DIO-28 Pin 0x42 0x43 GPIO33 DIO-29 Pin 0x42 0x43 GPIO34 DIO-30 Pin 0x42 0x43 GPIO35 DIO-31 Pin 0x42 0x43 GPIO36 DIO-32 Pin 0x42 0x43 GPIO37 DIO-33 Pin 0x72 0x73...

  • Page 98: Dio Sample Program

    DIO Sample Program ************************************************************************************ // SuperIO relative definition (Please reference to Table 1) #define byte SIOIndex //This parameter is represented from Note1 #define byte SIOData //This parameter is represented from Note2 #define void IOWriteByte(byte IOPort, byte Value); #define byte IOReadByte(byte IOPort); // Digital Input Status relative definition (Please reference to Table 2) #define byte DInputLDN // This parameter is represented from Note3 #define byte DInputReg // This parameter is represented from Note4...
  • Page 99 ************************************************************************************ AaeonReadPinStatus(byte LDN, byte Register, byte BitNum) Boolean Boolean PinStatus ; PinStatus = SIOBitRead(LDN, Register, BitNum); Return PinStatus ; AaeonSetOutputLevel(byte LDN, byte Register, byte BitNum, byte Value) VOID ConfigToOutputMode(LDN, Register, BitNum); SIOBitSet(LDN, Register, BitNum, Value); ************************************************************************************ Appendix C – Digital I/O Information...
  • Page 100 ************************************************************************************ SIOEnterMBPnPMode() VOID IOWriteByte(SIOIndex, 0x87); IOWriteByte(SIOIndex, 0x87); SIOExitMBPnPMode() VOID IOWriteByte(SIOIndex, 0xAA); SIOSelectLDN(byte LDN) VOID IOWriteByte(SIOIndex, 0x07); // SIO LDN Register Offset = 0x07 IOWriteByte(SIOData, SIOBitSet(byte LDN, byte Register, byte BitNum, byte Value) VOID Byte TmpValue; SIOEnterMBPnPMode(); SIOSelectLDN(byte IOWriteByte(SIOIndex, Register); TmpValue = IOReadByte(SIOData); TmpValue &= ~(1 <<...
  • Page 101 ************************************************************************************ SIOBitRead(byte LDN, byte Register, byte BitNum) Boolean Byte TmpValue; SIOEnterMBPnPMode(); SIOSelectLDN(LDN); IOWriteByte(SIOIndex, Register); TmpValue = IOReadByte(SIOData); TmpValue &= (1 << BitNum); SIOExitMBPnPMode(); If(TmpValue == 0) Return 0; Return 1; ConfigToOutputMode(byte LDN, byte Register, byte BitNum) VOID Byte TmpValue, OutputEnableReg; OutputEnableReg = Register-1;...
