H a l f - s i z e C P U C a r d
H S B - 6 6 8 I
HSB-668I
Onboard VIA Mark CoreFusion CPU
Half-Size Card
Realtek 8100C/8110S Ethernet
AC97 Codec Audio
HSB-668I Manual Rev. A 2nd Ed.
April 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSB-668I and is the answer not in the manual?

Questions and answers

Related Manuals for Aaeon HSB-668I

Summary of Contents for Aaeon HSB-668I

  • Page 1 H a l f - s i z e C P U C a r d H S B - 6 6 8 I HSB-668I Onboard VIA Mark CoreFusion CPU Half-Size Card Realtek 8100C/8110S Ethernet AC97 Codec Audio HSB-668I Manual Rev. A 2nd Ed. April 2008...

  • Page 2: Copyright Notice

    AAEON assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. AAEON reserves the right to make changes in the product design without notice to its users.
  • Page 3 H a l f - s i z e C P U C a r d H S B - 6 6 8 I Acknowledgments All other products’ name or trademarks are properties of their respective owners. Award is a trademark of Award Software International, Inc. VGA is a trademarks of International Business Machines Corporation.

  • Page 4: Packing List

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I Packing List Before you begin installing your card, please make sure that the following materials have been shipped: •...

  • Page 5: Table Of Contents

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I Contents Chapter 1 General Information 1.1 Introduction..............1-2 1.2 Features ..............1-3 1.3 Specifications ............1-4 Chapter 2 Quick Installation Guide 2.1 Safety Precautions ............
  • Page 6 H a l f - s i z e C P U C a r d H S B - 6 6 8 I 2.18 Fan Connector (FAN1) ..........2-12 2.19 AC97 Connector (CN1) ........... 2-12 2.20 ATX Power Control Connector (CN2) ..... 2-13 2.21 LAN LED Connector (CN3/CN4)......

  • Page 7: Chapter 1 General Information

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I Chapter General Information 1- 1 Chapter 1 General Information...

  • Page 8: Introduction

    H S B - 6 6 8 I 1.1 Introduction HSB-668I is a new standard ISA bus half-size CPU Card with onboard VIA Mark CoreFusion 533MHz processor integrating with North Bridge. It supports up to 128MB memory on board and is with one SO-DIMM that memory can support up to 512MB.

  • Page 9: Features

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 1.2 Features • Onboard VIA CoreFusion 533MHz Processor (Fanless) • Onboard Memory supports up to 128MB •...

  • Page 10: Specifications

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 1.3 Specifications System Form Factor ISA Half-size SBC Processor Onboard VIA Mark CoreFusion 533MHz CPU System Memory 1 x 144-pin 3.3V SDR SODIMM Socket up to 512MB (on board...
  • Page 11 H a l f - s i z e C P U C a r d H S B - 6 6 8 I IDE Interface 2 x ATA-100 channel (Support four ATAPI devices) Expansion Interface ISA Interface/PC-104 Watchdog Timer 1~255 Sec.
  • Page 12 H a l f - s i z e C P U C a r d H S B - 6 6 8 I Mouse connector 1 x internal keyboard pin header Universal Serial Bus One USB 1.1 Port One 5x2 pin header for Internal DOC2000 support IR Interface...

  • Page 13: Chapter 2 Quick Installation Guide

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I Chapter Quick Installation Guide Notice: The Quick Installation Guide is derived from Chapter 2 of user manual. For other chapters further installation...

  • Page 14: Safety Precautions

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 2.1 Safety Precaution Always completely disconnect the power cord from your board whenever you are working on it.

  • Page 15: Location Of Connectors And Jumpers

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 2.2 Location of Connectors and Jumpers Component Side Solder Side Chapter 2 Quick Installation Guide 2 - 3...

  • Page 16: Mechanical Drawing

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 2.3 Mechanical Drawing Component Side Solder Side Chapter 2 Quick Installation Guide...

  • Page 17: List Of Jumpers

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 2.4 List of Jumpers The board has a number of jumpers that allow you to configure your system to suit your application.

  • Page 18: List Of Connectors

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 2.5 List of Connectors The board has a number of connectors that allow you to configure your system to suit your application.
  • Page 19 H a l f - s i z e C P U C a r d H S B - 6 6 8 I TTL 18/24BIT Channel Connector TTL 36BIT Channel Connector LVDS Channel Connector PS2 Keyboard/Mouse Connector Internal Keyboard Connector DOC 1 Disk on Chip Socket Chapter 2 Quick Installation Guide...

  • Page 20: Setting Jumpers

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 2.6 Setting Jumpers You configure your card to match the needs of your application by setting jumpers. A jumper is the simplest kind of electric switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 21: Com2 Pin 9 Function (Rib Or +5V ) Selection (Jp1)

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I (JP1) COM2 Pin 9 Function (RIB or +5V ) Selection Function RIB (Default) +5 V 2.8 Clear CMOS (JP2) Function Open (Default) Clear...

  • Page 22: Front Panel Connector (Fp2)

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I Power On Button(-) Reset Switch(-) IDE LED(+) Power LED(+) IDE LED(-) Power LED(-) 2.12 Front Panel Connector (FP2) Signal Signal External Speaker(+)

  • Page 23: Irda Connector (Ir1)

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I RIB / +5V 2.15 IrDA Connector (IR1) Signal IRRX IRTX 2.16 LPT Port Connector (LPT1) Signal Signal #STROBE #AFD...

  • Page 24: Usb Connector (Usb1)

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I SELECT 2.17 USB Connector (USB1) Signal Signal USBD1- USBD1+ USBD2+ USBD2- 2.18 Fan Connector (FAN1) Signal Speed Sense 2.19 AC97 Connector (CN1) Signal...

  • Page 25: Atx Power Control Connector (Cn2)

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 2.20 ATX Power Control Connector (CN2) Signal PS-ON +5VSB AT Power Use: Close Pin 2,3 2.21 LAN LED Connector (CN3/CN4) Signal Signal Link_LED(-)

  • Page 26: 36Bit Ttl Channel Connector (Cn6)

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I GREEN6(24bit), GREEN4(18bit) 24 GREEN7(24bit), GREEN5(18bit) RED0(24bit) ,NC(18bit) 26 RED1(24bit) ,NC(18bit) RED2(24bit), RED0(18bit) 28 RED3(24bit) ,RED1(18bit) RED4(24bit), RED2(18bit) 30 RED5(24bit), RED3(18bit) RED6(24bit), RED4(18bit) 32 RED7(24bit), RED5(18bit)

  • Page 27: Lvds Channel Connector (Cn7)

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I 2.24 LVDS Channel Connector (CN7) Signal Signal BKLEN BKLCTL PPVCC CH1_CLK# CH1_CLK PPVCC CH1_TX0# CH1_TX0 CH1_TX1# CH1_TX1 CH1_TX2# CH1_TX2...

  • Page 28: Internal Keyboard Connector (Cn9)

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I KB_CLK MS_CLK 2.26 Internal Keyboard Connector (CN9) Signal KB_CLK KB_DATA 2-16 Chapter 2 Quick Installation Guide...
  • Page 29 H a l f - s i z e C P U C a r d H S B - 6 6 8 I Below Table for China RoHS Requirements 产品中有毒有害物质或元素名称及含量 AAEON Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅...

  • Page 30: Chapter 3 Award Bios Setup

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I Chapter Award BIOS Setup Chapter 3 Award BIOS Setup...
  • Page 31 3. The CMOS memory has lost power and the configuration information has been erased. The HSB-668I CMOS memory has an integral lithium battery backup for data retention. However, you will need to replace the complete unit when it finally runs down.
  • Page 32 H a l f - s i z e C P U C a r d H S B - 6 6 8 I 3.2 Award BIOS Setup Awards BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off.
  • Page 33 H a l f - s i z e C P U C a r d H S B - 6 6 8 I up, etc.) PnP/PCI Configurations This entry appears if your system supports PnP/PCI. PC Health Status This menu allows you to set the shutdown temperature for your system.

  • Page 34: Exit Without Saving

    H S B - 6 6 8 I Exit Without Saving Abandon all CMOS value changes and exit setup. You can refer to the "AAEON BIOS Item Description.pdf" file in the CD for the meaning of each setting in this chapter.

  • Page 35: Chapter 4 Driver Installation

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I Chapter Driver Installation Chapter 4 Driver Installation...
  • Page 36 H a l f - s i z e C P U C a r d H S B - 6 6 8 I The HSB-668I comes with a CD-ROM that contains all drivers and utilities that meet your needs.
  • Page 37 H S B - 6 6 8 I 4.1 Installation: Insert the HSB-668I CD-ROM into the CD-ROM Drive. Autorun program will run automatically. You also can choose the drivers to install from step 1 to step 3 in order as following instructions.
  • Page 38 H a l f - s i z e C P U C a r d H S B - 6 6 8 I Note: Under the Window OS environment, if the CRT connector is connected to display monitor by the data switch device, the user needs to set the color and resolution from Intel Graphic utility (VGA driver) instead of setting from the control panel in case of the wrong display appearance.

  • Page 39: Appendix A Programming The Watchdog Timer

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I Appendix Programming the Watchdog Timer Appendix A Programming the Watchdog Timer...

  • Page 40: Programming

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I A.1 Programming An onboard watchdog timer reduces the chance of disruptions which CPLD (Compact Programmable Logical Device) interface can cause.

  • Page 41: Appendix B I/O Information

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I Appendix I/O Information Appendix B I/O Information...

  • Page 42: I/O Address Map

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I B.1 I/O Address Map Appendix B I/O Information...

  • Page 43: St Mb Memory Address Map

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I B.2 1 MB Memory Address Map Appendix B I/O Information...

  • Page 44: Irq Mapping Chart

    H a l f - s i z e C P U C a r d H S B - 6 6 8 I B.3 IRQ Mapping Chart B.4 DMA Channel Assignments Appendix B I/O Information...
