4. Connection example
AR-12 AS SECURITY DEVICE.
Transformer
TF-3 24V DC
+
1 2 3 4 5 33 34 35 36 37
15 1 6 17 18 19 20 21 22 23 24
_
+
Adjustment of
opening time
1-30sek.
Jumper must be in pos:
Opto= Relay controlled by PL 9,10,
Power supply must be on PL1,2.
_
+
AXCALL Installation manual V1.3
URMET 1131/20
1 CA 2 6 10 9
27
