22

CONNECTION OF ADI-611 TO DI-651-1.

Transformer
TF-3 24V DC
Voltage
jumper.
Opening time
1-30sek.
AXCALL Installation manual V1.3
1
2
3
4
5
3334353637
15 161718192021222324
_
+
4. Connection example
Speaker
volume.
_
+
Free red LED connect
to GND to turn on.
Green LED on when B button
is pushed
URMET 1131/20
1
CA
2
6
10
Predrawn wire
RZ
R
+
AP
RÖD
GRÖN
Cancelling buzzer
Free button N.O.
9
