3. Drawings

AXCALL ADI-608.

Voltage
jumper
12/24V.
1
2
3
4
5
25 26
27
2829 30 3132
Power consumption
ADI-608
Voltage
max. 139mA
12V
max. 163mA
24V
Connections to ADI-611,616
Power supply
12-24V AC/DC
Calling signal in
GND
Connection to
handset.
Button 8
Button 7
Button 6
Button 5
Button 4
Button 3
Button 2
Button 1
1
AXCALL Installation manual V1.3
PL1:1
PL1:2
PL3:33
PL3:34
Urmet 1131
Handset.
CA unit. 8
CA unit. 7
CA unit. 6
CA unit. 5
CA unit. 4
CA unit. 3
CA unit. 2
CA unit. 1
URMET 1131
CA
2
6
10
9
11
