Axcall Swu - Axema AXCALL ADI-611 Projecting And Installation Manual

12

AXCALL SWU.

CONNECTION NR.
24 BUTTON 6
23 BUTTON 5
22 BUTTON 4
21 BUTTON 3
20 BUTTON 2
INTERCOM A
19 BUTTON 1
18 OPEN BUT.
17 EARPHONE
16 MIC.
15 GND
BUTTON 6
24
BUTTON 5
23
BUTTON 4
22
21 BUTTON 3
20 BUTTON 2
INTERCOM B
21 BUTTON 1
18 OPEN BUT.
EARPHONE
17
MIC.
16
GND
15
Note! For intercom ADI-611 use input with bold style.
AXCALL Installation manual V1.3
Voltage jumper
12/24V.
Intercom A
Intercom B
URMET 1131
1 CA 2 6
Power consumption
Current
Voltage
max. 167mA
12V
max. 200mA
24V
GND
LED UNIT A
LED UNIT B
INDOOR UNIT
BUTTON 6
BUTTON 5
BUTTON 4
BUTTON 3
BUTTON 2
BUTTON 1
OPEN BUT.
EARPHONE
MIC.
GND
1 0 9
3. Drawings
+
Power supply
12-24V DC
TO INDICATION
UNIT
CA HANDSET 6
CA HANDSET 5
CA HANDSET 4
CA HANDSET 3
CA HANDSET 2
CA HANDSET 1
9
1
TO ALL HANDSET.
2
6
