Operating Instructions

Webasto BlueCool C-Series
Chilled Water Marine Air-Conditioning Systems

General information

Dear Webasto Customer!
These operating Instructions provide an overview about how to use the chilled water air-
conditioning system and its control panels.
An extensive documentation and description can be found in the Installation and Service
Instructions.
To ensure safe use of the appliance, ALWAYS read and follow all instructions
in this manual. It is very important that an authorized Webasto dealer carries
out any repair or maintenance not described in this manual.

Safety notes

In general, all Webasto BlueCool C-Series air-conditioning systems are running on 230 Volt AC.
For all work at any of the components like pumps, compressor, blowers or electronics, the power
connection has to be interrupted. All work at the electric wiring must be performed by specialized
installers.
Before starting the Chiller unit, check the following points:
• The closing valve at the sea water valve is open!
• The sea water strainer is clean and filled with water!
• The boat has enough water under the body and the sea water inlet is not blocked!
• All supply and return air grilles are open and not blocked by luggage, clothing or anything
else!
• After turning the system on, water comes out of the over-board discharge. If not, switch
off the system and check the sea water circuit again!
Designated Control Panels
The Chiller unit is operated and controlled by the digital Chiller control panel.
Directly connected air handlers for one cabin are also operated by this control panel.
Other cabins with indirectly connected air handlers are controlled by separate digital cabin
control panels.
The system must be started with the digital Chiller control panel prior to normal
functionality of the air handlers in other cabins.
Digital Chiller control panel:
1
08/2018

Advertisement

Table of Contents
loading

Related Manuals for Webasto BlueCool C-Series

Summary of Contents for Webasto BlueCool C-Series

  • Page 1: Operating Instructions

    Safety notes In general, all Webasto BlueCool C-Series air-conditioning systems are running on 230 Volt AC. For all work at any of the components like pumps, compressor, blowers or electronics, the power connection has to be interrupted.

  • Page 2: Digital Chiller Control Panel For Chiller Units And Directly Connected Air Handlers

    • Switching the Chiller unit on and off • Programming and setup of the Chiller unit • Setup of directly connected air handlers • Selection of operation mode (Automatic, Cooling, Heating) • Switching the Chiller unit on and off • Programming and setup of the Chiller unit •...

  • Page 3: Operating The Chiller Control Panel

    Operating the Chiller control panel When the air-conditioning system is connected with the electrical power, the system initializes itself. The display shows Init and afterwards the frequency, e.g. Starting Press once the button. is displayed and after appr. 5 sec. the current room temperature, e.g. 28.5 (°C) is shown.

  • Page 4: Digital Cabin Control Panel For Indirectly Connected Air Handlers

    Digital cabin control panel for indirectly connected air handlers Illustration see section "Digital Chiller control panel for Chiller units and directly connected air handlers". The digital cabin control panel ist factory pre-programmed. The secondary commands are code-protected. Starting Press once the button.

  • Page 5: Error Code Display And Actions For The Digital Chiller And Cabin Control Panel

    Error code display and actions for the digital Chiller and cabin control panel The following malfunctions will be displayed directly on the digital control panel by a code or emitted as LED flash code directly on the Chiller controller card. It will be followed by a system halt.
  • Page 6 Temperature sensor at chilled water circuit defective or absent. Low pressure cut-out compressor 5 (causes see A01) High pressure cut-out compressor 5 (causes see A02) Low pressure cut-out compressor 6 (causes see A01) High pressure cut-out compressor 6 (causes see A02) 5 seconds after switch-on of chilled water pump, flow monitor detects insufficient chilled water volume flow CA11...

  • Page 7: Warranty Claims

    Warranty claims Failure to follow the Installation Instructions and the information, recommendations and descriptions therein will void all warranties. The same applies if repairs are carried out incorrectly, with the use of non-genuine parts or by unauthorized personnel. Warranty claims are only valid if the claimant can verify that he has complied with the maintenance and safety instructions.
